DATA SHEET
SLI 50 I
NVERTER SERIES, 5000 W
FEATURES
Compact design: 2U height, 19" rack mountable
Front panel LCD Display Unit to monitor and set main parameters
or LED Unit for visual indication available
High efficiency: up to 93%
True sine wave output
RS485 serial link
Input reflected ripple current <150 mArms @ maximum load
Advanced cooling system to optimize fan life and minimize noise
Parallelable output
2-position subrack availability
DESCRIPTION
The
SLI 50 Series
of “Slim Line” inverters provide an ideal solution for telecom,
IT and industrial applications. Due to innovative technology solutions like the
patent-pending “Compact Coil", the SLI 50 Series inverters pack 5000 watts of
power into a compact package that is 19” rack mountable and only two rack
units high. Electrical performance of the SLI Series inverter products is at the
top of the market with efficiency that peaks at 93% and a patent-pending control
algorithm that compensates current harmonics on the DC side without using
bulky and expensive filters. The inverter includes an on-board powerful Digital
Signal Processor (DSP) that allows easy programmability of the main parame-
ters on the front panel LCD display and keypad. The SLI Series inverters can be
interfaced with RS485.
BCD.00296_AA May-17-2013
1
APPLICATIONS
o
o
o
FEATURES
TELECOM
IT
INDUSTRIAL
www.power-one.com
DATA SHEET
TECHNICAL DATA:
PARAMETER
DESCRIPTION / CONDITION
MIN
40
ETSI EN 300 132-2; Ver, 2.12, Clause 4.7
5000
7000
240
30
63
93
5500
1
3
+0.5
0
0
<0.5
W
VA
VAC
Arms
Hz
%
Wmin
%
%
%
A
VDC
VDC
NOM
48
MAX
60
150
UNIT
VDC
ADC
INPUT
Input Voltage
Input Current
Inrush Current
OUTPUT
Output Power
Output Voltage
Output Current
Frequency
Efficiency
Overload
Load Power Factor
Crest Factor
Load Regulation
Line regulation
Output Noise & Ripple
Total Harmonic Distortion
200
Adjustable
@ 40 VDC
Lagging or leading
47
0.33
-0.5
-6
-8,5
On Resistive Load
230
50
PROTECTION
Input Overcurrent Protection
Input Overvoltage Protection
Input Undervoltage Protection
Overvoltage Protection
Undervoltage Protection
Safety Overcurrent Protection
Short-Circuit Protection
Overcurrent Protection
Overtemperature Protection
Protection Restore Modes
LCD Display Unit
LED Unit
General Alarm Signal
Agency Approvals
Insulation
@ 48 VDC
150
@ 48 VDC
65
@ 48 VDC
36
260 VAC ± 2%
195 VAC ± 2%
By safety fuse; 230 VAC Models: 30A
Yes; Ipk 95A ± 5% for 1 sec
30 A (factory default) to 15 A selectable with I2T curve (see spec.)
Tamb > 67 ºC and Tint > 110 ºC (Visual indication 5 ºC before shutdown)
The restore mode of each protection can be individually selected to "latch" or "auto-restart".
128 x 128 pixel graphic with keypad used for monitoring
and setting the main parameters.
Standard for visual indication of the main parameters
By a form C signal relay
IEC 60950-1: 2001, 1st edition; EN 60950-1: 2001 + A11: 2004; UL 60950-1, 1st edition; CAN/CSA-C22.2
No.60950-1-03, 1st edition; CE according to Low Voltage Directive and EMC Directive; Kema; CB Report
Approval;
Primary-to-Secondary:
3000
Vrms
Primary-to-Ground:
500
VDC
Secondary-to-Ground:
1500
Vrms
Signal-to-Ground:
500
VDC
Emission: EN 61000-6-4: 2001; EN 55022: 1998 A1:2000 + A2:2003 (Class B)
Immunity: EN 61000-6-2: 1999; EN 61000-4-2: 1995 + A1:1998 + A2: 2001 (Crit. A); EN 61000-4-3: 2006
(Crit. A); EN 61000-4-4: 2004 (Crit. A); EN 61000-4-5: 2006 (Crit. A); EN 61000-4-6. 1996 + A1:2001 (Crit.
A); EN 61000-4-8: 1993 + A1:2001 (Crit. A); ETSI EN 300-132-2 (Crit. A)
Operating:
Non-Operating:
@ full load; Power derating: 150 W/ ºC; +55 ºC to +65 ºC
0 – 90 %, non-condensing
0.02 % per ºC within rated load
482 x 88 x 400 mm
14.5 kg
13000
40000
+55
+85
ft
°C
°C
INTERFACE & CONTROL SIGNALS
LED Indicators for both units:
GREEN - Power ON
YELLOW - Fan Failure, Addresses
RED
- Overtemperature, Faulty Condition
SAFETY, REGULATORY AND EMC SPECIFICATIONS
EMC
ENVIRONMENTAL SPECIFICATIONS
Altitude
Operating Temperature
Storage Temperature
Humidity
Output Voltage Temp. Coefficient
Dimensions (W x H x D)
Weight
-25
-40
MECHANICAL SPECIFICATIONS
NUCLEAR AND MEDICAL APPLICATIONS
- Power-One products are not designed, intended for use in, or authorized for use as critical components in life support systems,
equipment used in hazardous environments, or nuclear control systems without the express written consent of the respective divisional president of Power-One, Inc.
TECHNICAL REVISIONS
- The appearance of products, including safety agency certifications pictured on labels, may change depending on the date manufactured. Specifi-
cations are subject to change without notice.
SLI 50 Inverter Series
2
