Surface Mount PIN Photodiode
OPR5910/T, OPR5913
Features:
Surface mountable
High temperature operation
Circular active area (OPR5910)
Large area photodiode (OPR5913)
880 nm peak responsivity offers maximum coupling with OPTEK’s GaAIAs
LEDs (OPR5910)
Description:
Each OPR5910, OPR5913 and OP5915 device is a silicon PIN photodiode enclosed in a compact polyamide chip carrier and is
designed for open air communications and ambient light detection circuits.
The custom opaque package shields the photodiodes from stray light and can withstand multiple exposures to the most
demanding soldering conditions, while the wraparound gold-plated solder pads offer exceptional storage and wetting
characteristics.
See Application Bulletin 237 for Handling Instructions.
Applications:
Encoder applications
Control applications
Part
Number
OPR5910
OPR5910T
OPR5913
Receiver
Type
Photodiode
# of
Elements
1
Ordering Information
Responsivity
(mA/mW) Min.
0.45
0.45
0.40
Reverse Voltage
Min.
35
35
10
Active Area
(mm
2
)
0.75
0.75
26.00
Packaging
Chip Tray
Tape & Reel
Chip Tray
Warning:
Front
Window is pressure
sensitive. Do not
apply pressure or
high vacuum to win-
dow.
OPR5910
Pin #
1
2
3
4
Description
Cathode
Anode
NC
NC
OPR5913
Pin #
1
2
3
4
Description
Anode
Cathode
Cathode
NC
Pin #
5
6
7
8
Description
NC
Cathode
Cathode
NC
General Note
TT Electronics reserves the right to make changes in product specification without
notice or liability. All information is subject to TT Electronics’ own data and is
considered accurate at time of going to print.
© TT electronics plc
TT Electronics | Optek Technology, Inc.
1645 Wallace Drive, Ste. 130, Carrollton, TX USA 75006 |Ph: +1 972 323 2200
www.ttelectronics.com | sensors@ttelectronics.com
Issue B
11/2016
Page 1
Surface Mount PIN Photodiode
OPR5910/T, OPR5913
Electrical Specifications
Absolute Maximum Ratings
(T
A
= 25° C unless otherwise noted)
Storage and Operating Temperature
Reverse Breakdown Voltage
OPR5910, OPR5915
OPR5913
Solder reflow time within 5°C of peak temperature is 20 to 40 seconds
(1)
-55° C to +125° C
35 V / minute
10 V / minute
250° C
Electrical Characteristics
(T
A
= 25° C unless otherwise noted)
SYMBOL
R
PARAMETER
Responsivity
OPR5910, OPR5915
OPR5913
Reverse Breakdown Voltage
OPR5910, OPR5915
OPR5913
Reverse Dark Current
OPR5910, OPR5915
OPR5913
Capacitance
OPR5910
OPR5913
OPR5913
OPR5915
Active Area
OPR5910
OPR5913
OPR5915
MIN
0.45
0.40
35
10
-
-
-
-
-
-
-
-
-
TYP
-
-
-
-
-
-
25
1000
250
125
0.75
26
7.8
MAX
-
-
-
-
30
100
-
-
-
-
-
-
-
UNITS
A/W
TEST CONDITIONS
E
e
= 10 µW, λ = 890 nm, V = 0 V
V
BR
V
I
R
= 100 µA
I
D
nA
V
R
= 10 V
V
R
= 0.5 V
V
R
= 0 V
V
R
= 0 V
V
R
= 10 V
V
R
= 0 V
(0.86 mm x 0.86 mm)
(5.1 mm x 5.1 mm)
(2.8 mm x 2.8 mm)
C
T
pf
Lx W
mm
2
Notes:
(1) Solder time less than 5 seconds at temperature extreme.
Spectral Responsivity
100
80
60
40
20
0
.4
.5
.6
.7
.8
.9
1.0
1.1
Relative Response (%)
Wavelength (µm)
General Note
TT Electronics reserves the right to make changes in product specification without
notice or liability. All information is subject to TT Electronics’ own data and is
considered accurate at time of going to print.
© TT electronics plc
TT Electronics | Optek Technology, Inc.
1645 Wallace Drive, Ste. 130, Carrollton, TX USA 75006 |Ph: +1 972 323 2200
www.ttelectronics.com | sensors@ttelectronics.com
Issue B
11/2016
Page 2
