COMPONENTS / ACCESSORIES
Horizontal rails
z rail for connector
iec 60 603-2 (F)
With 84 x M2.5 threaded holes.
material:
Extruded aluminum section
surface finish:
Clear-chromated
Usable width (HP)
4
8
20
40
42
63
84
84
Packs of
1
1
1
1
1
1
1
2
order no.
3684.597
3684.598
3684.599
3684.965
3684.600
3684.601
3684.602
3685.271
!
3
also required:
Assembly screws M2.5 x 6,
packs of 100, order no. 3654.340,
see page 164
8.25
1
threaded insert (i)
With M2.5 threaded holes on an HP pitch pattern.
For sliding into the horizontal rail. There are two
threaded insert versions, which are distinguished
by their height.
material:
Sheet steel, zinc-plated
order no.
Usable
width
(HP)
6 x 2 mm
Packs of
Type
A, A1, B, B1,
B2, C3
1
1
1
1
1
1
1
1
1
1
3684.603
3684.604
3684.605
3684.606
3684.607
3686.149
3684.966
3684.608
3684.609
3684.610
5 x 2 mm
Type
A2, C5,
C6, D4
–
–
–
–
–
–
–
–
–
9901.816
for horizontal rails
21.5
4
8
12
16
20
21
40
42
63
84
identification strip (J)
To identify the slots on the subrack, self-adhesive.
The following versions are available:
4 mm wide:
•
for front horizontal rails
•
for rear horizontal rails
2 mm wide:
•
for front horizontal rails (channel on front face)
For
horizontal
rail
Front
Rear
Front
Front
Width
mm
4
4
4
2
Label
1 ... 84
1 ... 168
84 ... 1
1 ... 84
Packs of
order no.
1
1
1
1
3687.575
3687.577
3687.574
3687.576
