FZ2400R17KE3NOSA1

Description
IGBT MODULE 1700V 2400A
CategoryDiscrete semiconductor    The transistor
File Size398KB,8 Pages
ManufacturerInfineon
Websitehttp://www.infineon.com/
Download Datasheet Parametric Compare View All

FZ2400R17KE3NOSA1 Overview

IGBT MODULE 1700V 2400A

FZ2400R17KE3NOSA1 Parametric

Parameter NameAttribute value
Is it lead-free?Contains lead
Is it Rohs certified?incompatible
MakerInfineon
Parts packaging codeMODULE
package instructionFLANGE MOUNT, R-XUFM-X7
Contacts7
Reach Compliance Codecompliant
ECCN codeEAR99
Shell connectionISOLATED
Maximum collector current (IC)3200 A
Collector-emitter maximum voltage1700 V
ConfigurationPARALLEL, 2 ELEMENTS WITH BUILT-IN DIODE
JESD-30 codeR-XUFM-X7
Number of components2
Number of terminals7
Maximum operating temperature150 °C
Package body materialUNSPECIFIED
Package shapeRECTANGULAR
Package formFLANGE MOUNT
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Polarity/channel typeN-CHANNEL
Certification statusNot Qualified
surface mountNO
Terminal formUNSPECIFIED
Terminal locationUPPER
Maximum time at peak reflow temperatureNOT SPECIFIED
Transistor component materialsSILICON
Nominal off time (toff)1890 ns
Nominal on time (ton)850 ns
Base Number Matches1
