MULTILAYER CERAMIC CAPACITORS
MULTILAYER CERAMIC CAPACITORS
REFLOW
REFLOW
AEC-Q200
AEC- Q200
■PART
NUMBER
J M K
① ② ③
①Rated voltage
Code
A
J
L
E
T
G
U
H
Q
S
②Series name
Code
M
V
W
3
1 6
④
△
⑤
B
⑥
J
1
0 6
⑦
M L H T △
⑧ ⑨ ⑩ ⑪ ⑫
△＝Blank space
Rated voltage［VDC½
4
6.3
10
16
25
35
50
100
250
630
③End termination
Code
End termination
K
Plated
J
Soft Termination
S
Cu Internal Electrodes (For High Frequency)
F
High Reliability Application
④Dimension（L×W）
Dimensions
（L×W）［mm½
063
0.6 × 0.3
1.0 × 0.5
105
0.52× 1.0 ※
1.6 × 0.8
107
0.8 × 1.6 ※
2.0 × 1.25
212
1.25× 2.0 ※
316
3.2 × 1.6
325
3.2 × 2.5
432
4.5 × 3.2
Note : ※LW reverse type（□WK） only
Type
W［mm½
Standard
0.3±0.05
0.5±0.10
0.8＋0.15/－0.05
1.25＋0.15/－0.05
1.6±0.20
2.5±0.30
0.5＋0.15/－0.05
0.8＋0.20/－0
1.25＋0.20/－0
1.6±0.30
0.5＋0.20/－0
0.8＋0.25/－0
1.25＋0.25/－0
1.25±0.15
1.6±0.20
EIA（inch）
0201
0402
0204
0603
0306
0805
0508
1206
1210
1812
CERAMIC CAPACITORS
18
Series name
Multilayer ceramic capacitor
Multilayer ceramic capacitor for high frequency
LW reverse type multilayer capacitor
⑤Dimension tolerance
Code
Type
△
ALL
063
105
107
A
212
316
325
105
107
B
212
316
105
107
212
212
316
325
L［mm½
Standard
0.6±0.05
1.0±0.10
1.6＋0.15/－0.05
2.0＋0.15/－0.05
3.2±0.20
3.2±0.30
1.0＋0.15/－0.05
1.6＋0.20/－0
2.0＋0.20/－0
3.2±0.30
1.0＋0.20/－0
1.6＋0.25/－0
2.0＋0.25/－0
2.0±0.15
3.2±0.20
T［mm½
Standard
0.3±0.05
0.5±0.10
0.8＋0.15/－0.05
0.85±0.10
1.25＋0.15/－0.05
1.6±0.20
2.5±0.30
0.5＋0.15/－0.05
0.8＋0.20/－0
0.85±0.10
1.25＋0.20/－0
1.6±0.30
0.5＋0.20/－0
0.8＋0.25/－0
1.25＋0.25/－0
0.85±0.15
1.15±0.20
1.6±0.20
2.5±0.30
△= Blank space
C
K
3.2±0.50
2.5±0.30
Note: ½½. STANDARD EXTERNAL DIMENSIONS
⑥Temperature characteristics code
■High dielectric type
Applicable
Temperature
Code
standard
range［℃½
BJ
C6
B7
C7
D7
EIA
EIA
EIA
EIA
EIA
X5R
X6S
X7R
X7S
X7T
－55½＋ 85
－55½＋105
－55½＋125
－55½＋125
－55½＋125
Ref. Temp.［℃½
25
25
25
25
25
Capacitance change
±15％
±22％
±15％
±22％
＋22％/－33％
Capacitance
tolerance
±10％
±20％
±10％
±20％
±10％
±20％
±10％
±20％
±10％
±20％
Tolerance
code
K
M
K
M
K
M
K
M
K
M
