CAT 5E CABLE
COMPLIANT
ROHS
High reliability Cat 5e Ethernet cable & cordsets
General construction
A 4 pair, 24 AWG, 100 Ohm SFTP round patch cable, designed to the ISO / IEC 11801 Category
5e requirements (cat 5e on 76m). The cable contains 4 twisted pairs, cabled, double shielded
with kevlar reinforcement strands, jacketed in black UV resistant Polyurethane HFFR.
Designed for fixed or portable applications in harsh environments.
HFFR: Halogen Free Flame Retardant
Jacket compound specification:
- Halogen free flame retardant polyether-based polyurethane
- Excellent hydrolysis resistance
- Resistance to microbial/fungus growth acc. IEC60068-2-10
Environmental Testing – Test J degree of mould growth 1
- Glossy finish
- UV resistant
- High flexibility
Applications
n
Robotics
n
Motion control
n
Railways
n
CNC machines
n
Battelfield communication
n
Industrial process control
or
Datas f
e only
ble alon lug)
the ca
p
t RJ45
(withou
Electrical characteristics
(at 20°C - 68°F)
DC Resistance
96 Ohms/Km
100 +/- 15 Ohms
N.E.X.T.
(Near-End Crosstalk Loss)
64 dB min.
62 dB min.
53 dB min.
47 dB min.
42 dB min.
40 dB min.
35 dB min.
32 dB min.
46nF/km nom.
43 dB min. @ 64 KHz
3.4 pF/m max. @ 1KHz
(wire to ground)
150 M Ohm min.
230 VMS
VAC/1 min - 700 V/Min
5.2 ns/m max.
20 ns/100m max. @ 1-100
MHz
3% max.
23db/100m min.
3 KV
67% nom.
44 dB min.
Impedance
(1-100 MHz)
Insertion loss
(dB/100m)
2.70 dB
3.15 dB
6.45 dB
9.90 dB
12.3 dB
13.8 dB
17.7 dB
25.6 dB
33 dB
Physical characteristics
CONDUCTORS
INSULATION
ASSEMBLY
SHIELDS
24 AWG (0,25 mm²) tinned
copper, 7x0.20 mm
Color coded 568-B, linear low
Density Polyethylene,
Nom. Dia. 0,039” (1mm)
Pairs cabled with Kevlar strength
members and separation tape
wrapped
Inner: aluminium mylar
100% coverage
Outer: tinned copper braid
80% coverage
Black, special PUR compound
40 lbs / mft (59 kg/km)
0.28” (7.1 mm) nom.
67.5mm (9x O. D.)
37.5mm (5 x O.D.)
Passes IEC 61156-6 requirements
Transport and fixed installation :
-50°C
(-58°F)
up to + 85°C
(185°F)
Installation and flexible use :
-40°C
(-40°F)
up to + 85°C
(185°F)
Frequency
772 KHz
1 MHz
4 MHz
10 MHz
16 MHz
20 MHz
31.25 MHz
62.5 MHz
100 MHz
JACKET
WEIGHT
OUTSIDE DIAM.
MIN BEND RADIUS
(During installation)
MIN BEND RADIUS
(During operation)
MIN FLEXES TO FAILURE
TEMPERATURE
Capacitance
(1 kHz)
LCL
Capacitance unbalance
Insulation resistance
Voltage rating
Dielectric strength
Propagation delay (100 MHz)
Delay skew
Resistance unbalance
Structural return loss (1-20
MHz)
Spark test (tested during
production)
Velocity of propagation
Cordsets with a RJ45 plug overmolded on each end
Length (m/ft)
0,76 m / 2,5 ft
1,00 m / 3.28 ft
1,52 m / 5 ft
3,05 m / 10 ft
4,57 m / 15 ft
5,00 m / 16.4 ft
6,00 m / 19.68 ft
6,24 m / 20.46 ft
7,62 m / 25 ft
8,00 m / 26.24 ft
10,00 m / 32.78 ft
14,00 m / 45.92 ft
15,25 m / 50 ft
22,87 m / 75 ft
30,5 m / 100 ft
45,75 m / 150 ft
50,00 m / 164 ft
61,00 m / 200.08 ft
Part number
RJF SFTP 5E 0076
RJF SFTP 5E 0100
RJF SFTP 5E 0152
RJF SFTP 5E 0305
RJF SFTP 5E 0457
RJF SFTP 5E 0500
RJF SFTP 5E 0600
RJF SFTP 5E 0624
RJF SFTP 5E 0762
RJF SFTP 5E 0800
RJF SFTP 5E 1000
RJF SFTP 5E 1400
RJF SFTP 5E 1525
RJF SFTP 5E 2287
RJF SFTP 5E 3050
RJF SFTP 5E 4575
RJF SFTP 5E 5000
RJF SFTP 5E 6100
Reel of cable
(without RJ45 plug on ends)
Length (m / ft)
100 m / ~328 ft
300 m / ~984 ft
Part number
190-038045-00
190-038045-01
41
Amphenol
