2016-09-13
DURIS
®
E 3
Datasheet
Version 1.5
GW JCLMS1.EC
The DURIS
®
E 3 combines high efficacy and a wide
beam angle into a compact format (3.0 mm x 1.4 mm).
This is key to homogeneous illumination applications
where the DURIS
®
E 3 never fails to impress with its
performance on system level.
The DURIS
®
E 3 combines high efficacy and a wide
beam angle into a compact format (3.0 mm x 1.4 mm).
This is key to homogeneous illumination applications
where the DURIS
®
E 3 never fails to impress with its
performance on system level.
Features:
•
Package:
white SMT package, colored diffused
silicone resin
•
Viewing angle at 50 % I
V
:
110°
•
Color:
2700 K - 6500 K (warm, neutral and cool
white)
•
CRI:
min. 80 ( typ. 85 )
•
Luminous Flux:
typ. 27 lm @ 5000 K
•
Luminous efficacy:
typ. 134 lm/W @ 5000 K
Applications
•
Indoor General Lighting
•
Linear lights
•
Retrofits and fixtures
•
Task lights
Besondere Merkmale:
•
Gehäusetyp:
weißes SMT Gehäuse, farbiger
diffuser Silikon-Verguss
•
Abstrahlwinkel bei 50 % I
V
:
110°
•
Farbe:
2700 K - 6500 K (warm, neutral and cool
white)
•
CRI:
min. 80 ( typ. 85 )
•
Lichtstrom:
typ. 27 lm @ 5000 K
•
Lichtausbeute:
typ. 134 lm/W @ 5000 K
Anwendungen
•
Innen-Allgemeinbeleuchtung
•
Linearbeleuchtung
•
Retrofits
•
Schreibtischleuchten
2016-09-13
1
Version 1.5
Ordering Information
Bestellinformation
Type:
Typ:
Color
Temperature
Farbtemperatur
Luminous Flux
1)
page 25
GW JCLMS1.EC
Ordering Code
Bestellnummer
Lichtstrom
1)
Seite 25
I
F
= 65 mA
[K]
GW JCLMS1.EC-GSGU-5U8X-L1N2
GW JCLMS1.EC-GTHP-5U8X-L1N2
GW JCLMS1.EC-GSGU-5R8T-L1N2
GW JCLMS1.EC-GTHP-5R8T-L1N2
GW JCLMS1.EC-GTHP-5O8Q-L1N2
GW JCLMS1.EC-GUHQ-5O8Q-L1N2
GW JCLMS1.EC-GTHP-5L7N-L1N2
GW JCLMS1.EC-GUHQ-5L7N-L1N2
GW JCLMS1.EC-GTHP-5H7I-L1N2
GW JCLMS1.EC-GUHQ-5H7I-L1N2
GW JCLMS1.EC-GTHP-5F7G-L1N2
GW JCLMS1.EC-GUHQ-5F7G-L1N2
GW JCLMS1.EC-GTHP-5C7E-L1N2
GW JCLMS1.EC-GUHQ-5C7E-L1N2
Note:
Φ
V
[lm]
22.4 ... 28
24 ... 30.4
22.4 ... 28
24 ... 30.4
24 ... 30.4
25.9 ... 33
24 ... 30.4
25.9 ... 33
24 ... 30.4
25.9 ... 33
24 ... 30.4
25.9 ... 33
24 ... 30.4
25.9 ... 33
Q65111A7115
Q65111A7108
Q65111A7116
Q65111A7109
Q65111A7110
Q65111A7103
Q65111A7111
Q65111A7104
Q65111A7112
Q65111A7105
Q65111A7113
Q65111A7106
Q65111A7114
Q65111A7107
2700
2700
3000
3000
3500
3500
4000
4000
5000
5000
5700
5700
6500
6500
The above Type Numbers represent the order groups which include only a few brightness groups (see page 5). Only one group will
be shipped on each packing unit (there will be no mixing of two groups on each packing unit). E. g. GW
JCLMS1.EC-GTHP-5U8X-L1N2 means that only one group GT, GU, HP will be shippable for any packing unit.
In a similar manner for colors where color chromaticity coordinate groups are measured and binned, single groups will be shipped on
any one packing unit. GW JCLMS1.EC-GTHP-5U8X-L1N2 means that the device will be shipped within the specified limits.
In a similar manner for colors where forward voltage groups are measured and binned, single forward voltage groups will be shipped
on any packing unit. E. g. GW JCLMS1.EC-GTHP-5U8X-L1N2 means that only one forward voltage group L1,L2,M1,M2,N1,N2 will
be shippable.
Anm.:
Die oben genannten Typbezeichnungen umfassen die bestellbaren Selektionen. Diese bestehen aus wenigen Helligkeitsgruppen
(siehe Seite 5). Es wird nur eine einzige Helligkeitsgruppe pro Verpackungseinheit geliefert. Z. B. GW
JCLMS1.EC-GTHP-5U8X-L1N2 bedeutet, dass in einer Verpackungseinheit nur eine der Helligkeitsgruppen GT, GU, HP enhalten
ist.
Gleiches gilt für die Farben, bei denen Farbortgruppen gemessen und gruppiert werden. Pro Verpackungseinheit wird nur eine
Farbortgruppe geliefert. Z.B. GW JCLMS1.EC-GTHP-5U8X-L1N2 bedeutet, dass in einer Verpackungseinheit nur eine der
Farbortgruppen enthalten ist. GW JCLMS1.EC-GTHP-5U8X-L1N2 bedeutet, dass das Bauteil innerhalb der spezifizierten Grenzen
geliefert wird.
Gleiches gilt für die LEDs, bei denen die Durchlassspannungsgruppen gemessen und gruppiert werden. Pro Verpackungseinheit
wird nur eine Durchlassspannungsgruppe geliefert. Z. B. GW JCLMS1.EC-GTHP-5U8X-L1N2 bedeutet, dass nach
Durchlassspannungsgruppen gruppiert wird. In einer Verpackungseinheit ist nur eine der Durchlassspannungsgruppen
L1,L2,M1,M2,N1,N2 enthalten (siehe Seite 5).
