5102161-9 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> 5102161-9

5102161-9: DescriptionCONNECTOR, 40 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SOLDER, ROHS COMPLIANT; CategoryThe connector The connector; File Size105KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric View All

5102161-9 Overview

CONNECTOR, 40 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SOLDER, ROHS COMPLIANT

5102161-9 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
package instruction	ROHS COMPLIANT
Reach Compliance Code	unknow
Other features	POLARIZED, SHROUDED
Connector type	BOARD CONNECTOR
Contact to complete cooperation	NOT SPECIFIED
Contact completed and terminated	TIN OVER NICKEL
Contact point gender	MALE
Contact material	PHOSPHOR BRONZE
DIN compliance	NO
Filter function	NO
IEC compliance	NO
JESD-609 code	e3
MIL compliance	NO
Manufacturer's serial number	5102161
Mixed contacts	NO
Installation method	RIGHT ANGLE
Installation type	BOARD
Number of rows loaded	2
Options	GENERAL PURPOSE
Terminal pitch	2.54 mm
Termination type	SOLDER
Total number of contacts	40
UL Flammability Code	94V-0
Base Number Matches	1

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Ribbon and Flat Flex Wire C onnectors - Ribbon C able

Product Feature Selector

> Product Details

5102161-9 Product Details

Live Product Chat

Product Photo

Pin and Pinless Headers (AMP-LATCH)

Always EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

5102161-9

T E I nternal N umber: 5 1 0 2 1 6 1 - 9

Product Highlights:

C onnector Type = Universal Ejection Pin Headers

Standard Profile

Number of Positions = 40

2.54 x 2.54 mm C enterline, Matrix

PC B Mount Angle = Right Angle

View all Features

Obsolete

C ontact Product Information C enter

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

HEADER ASSY, UNIVERSAL, AMP-LATC H

(PDF, English)

Catalog Pages/Data Sheets:

None Available

Product Specifications:

AMP-LATC H* and IDC Header C onnectors, .100 x .100 In...

(PDF, English)

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

C onnector Type

= Universal Ejection Pin Headers

Profile

= Standard

Number of Positions

= 40

PC B Mount Angle

= Right Angle

PC B Retention Feature

= No

Mating Polarization Type

= C enter, Dual Polarizing Bar, Military

Mating C onnector Lock

= Without

Housing Style

= 4-Sided

Ejection Latches

= Without

Post Size (mm [in]) = 0.64 [.025]

Shrouded = Yes

PC B Thickness (mm [in]) = 3.18 [0.125]

Mating Polarization = With

Termination Related Features:

Termination Post Length (mm [in])

= 3.94 [0.155]

Solder Tail C ontact Plating = Tin over Nickel

Body Related Features:

C enterline, Matrix (mm [in])

= 2.54 x 2.54 [.100 x .100]

Contact Related Features:

C ontact Mating Area Plating Material

= Gold (15), Gold Flash over

Palladium Nickel

C ontact Shape = Square

C ontact Base Material = Phosphor Bronze

Housing Related Features:

Housing Material = Thermoplastic

Housing Flammability Rating = UL 94V-0

Housing C olor = Black

Industry Standards:

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

Lead Free Solder Processes

= Wave solder capable to 240?C , Wave

solder capable to 260?C , Wave solder capable to 265?C

RoHS/ELV C ompliance History = Always was RoHS compliant

Conditions for Usage:

Temperature Rating

= Standard

Other:

Brand = AMP

Additional Information:

Product Line Information
