CHASSIS MOUNT
TRANSFORMER
TL94 Series
•
•
•
•
•
Power – 25VA to 175VA
Dielectric Strength – 4000Vrms
Primary – Dual primary (115V/230V 50/60Hz)
Secondary – Series or parallel
Terminal – Solder lug / quick-connect
type
terminal
•
Insulation Class – Class F (155°C)
•
Flammability Rating – UL94V-0 (bobbin)
•
Safety Approvals – UL506, CSA
C22.2
#66 , TUV / EN60950 & CE
A
C
E
D
A
C
E
D
#6
#5
B
#2
#1
#12
#11
#8
#7
#6
#5
#4
B
#3
#2
#1
#12
#11
#10
#9
#8
#7
#6
115V
50/60 Hz
SEC 2
#12
#11
#8
115V
50/60 Hz
SEC 1
F
#6
115V
50/60 Hz
SEC 2
#12
#11
#8
115V
50/60 Hz
SEC 1
F
#5
#2
#1
G
#5
#2
#1
G
#7
#7
H
MOUNTING STYLE A
Product
Series
25 (VA)
43 (VA)
80 (VA)
130 (VA)
175 (VA)
Note:
Dimensions (mm)
D
E
28.6
28.6
35.5
41.5
41.5
7.9
7.9
7.9
9.5
9.5
MOUNTING STYLE B
Mtg.
Style
A
A
B
B
B
A
49.8
57.2
63.5
71.5
80.0
B
60.0
69.2
76.2
85.8
96.0
C
47.6
52.3
60.3
73.0
79.0
F
4.75
4.75
4.75
6.35
6.35
G
60.3
71.4
50.8
57.2
64.0
H
--
--
55.5
63.5
64.0
Mtg.
Screw
#6
#6
#6
#8
#8
1) The Mtg. Screw size is the maximum allowable screw size.
2) Unused terminals are omitted for standard parts. Unused terminals can be provided on request.
3) For 25VA & 43VA series, maximum 10 terminals are available.
4) For 80VA to 175VA series, maximum 12 terminals are available.
