TL77-2F-10

Description
PCB PLUG-IN TRANSFORMER
File Size184KB,3 Pages
ManufacturerDBLECTRO
Websitehttp://www.dblectro.com
Download Datasheet View All

TL77-2F-10 Overview

PCB PLUG-IN TRANSFORMER

PCB PLUG-IN
TRANSFORMER
PCB PLUG-IN TRANSFORMER
TL77 Series
Power – 1.1VA to 36VA
Dielectric Strength – 2500Vrms (P – S)
Primary – Dual primary (115V/230V
50/60Hz) or Single primary
Secondary – Series or parallel
Insulation Class – Class F (155°C)
Safety
Approvals
– UL506, CSA C22.2
#66
Product
Series
1.1 (VA)
2.4 (VA)
6.0 (VA)
12 (VA)
20 (VA)
36 (VA)
Tolerance (mm)
A
35.0
35.0
41.0
48.0
57.0
66.0
±1.0
B
29.0
29.0
33.0
40.0
47.5
55.0
±1.0
C
24.0
30.2
33.3
35.8
35.8
39.6
±1.0
D
5.0
5.0
5.0
5.0
5.0
5.0
±1.0
Dimension (mm)
E
F
G
0.5×0.8 6.35
0.5×0.8 6.35
0.5×0.8 6.35
0.5×0.8 7.62
0.5×0.8 7.62
0.5×0.8 10.16
±0.2
±0.3
6.35
6.35
8.90
10.16
10.16
10.16
±0.3
H
30.5
30.5
32.5
35.8
40.6
47.0
±0.5
I
--
--
--
--
--
56.0
±0.5
J
--
--
27.0
32.0
38.0
44.0
±0.5
K
--
--
2.5
3.0
3.5
4.0
max.
Note : Dimension “E” is pin size, and dimension “K” is the maximum allowable screw size.
