133167 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> 133167

133167: DescriptionTelecom and Datacom Connector, 8 Contact(s), Female, Right Angle, Solder Terminal, Locking, Jack, ROHS COMPLIANT; CategoryThe connector The connector; File Size649KB，1 Pages; ManufacturerERNI; Websitehttp://www.erni.com; Environmental Compliance

Download Datasheet Parametric View All

133167 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	133167	-	-	View	Buy Now

133167 Overview

Telecom and Datacom Connector, 8 Contact(s), Female, Right Angle, Solder Terminal, Locking, Jack, ROHS COMPLIANT

133167 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
package instruction	ROHS COMPLIANT
Reach Compliance Code	compli
ECCN code	EAR99
Other features	PANEL MOUNTABLE
Board mount options	SPLIT BOARD LOCK
body width	0.537 inch
subject depth	0.85 inch
body length	0.625 inch
Body/casing type	JACK
Connector type	TELECOM AND DATACOM CONNECTOR
Contact to complete cooperation	GOLD (30) OVER NICKEL
Contact completed and terminated	Matte Tin (Sn) - with Nickel (Ni) barrie
Contact point gender	FEMALE
Contact material	NOT SPECIFIED
Contact resistance	30 mΩ
Contact style	TELCOM, MODULAR
DIN compliance	NO
Dielectric withstand voltage	1000VAC V
Durability	1000 Cycles
empty shell	NO
Filter function	NO
IEC compliance	NO
maximum insertion force	20.016 N
Insulation resistance	500000000 Ω
Insulator color	BLACK
insulator material	POLYBUTYLENE TEREPHTHALATE
JESD-609 code	e3
MIL compliance	NO
Manufacturer's serial number	133167
Mixed contacts	NO
Installation option 1	LOCKING
Installation option 2	MOUNTING FLANGE
Installation method	RIGHT ANGLE
Installation type	BOARD AND PANEL
Number of ports	1
Maximum operating temperature	70 °C
Minimum operating temperature
Options	GENERAL PURPOSE
PCB contact pattern	STAGGERED
Plating thickness	30u inch
Rated current (signal)	1.5 A
Guideline	UL
reliability	COMMERCIAL
Shell surface	NICKEL
Shell material	COPPER ALLOY
Terminal length	0.126 inch
Terminal pitch	2.54 mm
Termination type	SOLDER
Total number of contacts	8
UL Flammability Code	94V-0
Base Number Matches	1

Preview

Download Datasheet

View All

RECOMMENDED PANEL CUTOUT

EMPFOHLENER FRONTPLATTEN-AUSSCHNITT

MAX

16,66 0,656

0,38

±0,10

0,015

±0,004

RECOMMENDED PCB LAYOUT (COMPONENT SIDE VIEW)

EMPFOHLENES LEITERPLATTEN-LAYOUT (BESTUECKUNGSSEITE)

TOL. 0.05 [0.002] UNLESS NOTED

1,27 0,050

0,635 0,025

21,59 0,850

14,72 0,580

PCB EDGE

0,89

±0,

2,54 0,100

0,03

±0,

003

1,60

0,07

0,06

3,25

±0

±0,

003

,07

0,128

0,003

15,88 0,625

3,05 0,120

3,20

±0,20

0,126

±0,008

2,54 0,100

8,89 0,350

1:1

13,63 0,537

IMPROVED CONTACT DESIGN

(PRE BEND)

11,43 0,450

15,49 0,610

11,43

±0,13

0,450

±0,005

10,89 0,429

NOTE 1: SIDE SHIELD TABS IN REAR 3.05 mm

NOTE 2: PANEL GROUND FLANGES BOTH SIDES AND TOP (GF5)

NOTE 3: RoHS COMPLIANT

TRANSMISSION

REQUIREMENT

ÜBERTRAGUNGS-

ANFORDERUNG

CATEGORY 5,

DUAL TWIST

PCB HOLE

NUMBERING

LP BOHRUNGS-

NUMERIERUNG

2 4 6 8

1 3 5 7

PART NO.

IDENT. NR.

T e chnical sp e cif icat io ns

Mate ri al s & F i n i sh

T e st D ata

Stan d ard ap p l i c . Val u e

Insulation body

Standard description PBT 30%

Me c h ani c al p ro p e rti e s

Standard de scriptio n C5210 (acc. JIS)

Inse rti o n/withdrawal fo rce IEC 603-7

Co ntact mate ri al

max. 20 N

Contact finish, mating zone

Thickness of plating 30 µin Au over 50 µin Ni

Mechanical operations

IEC 512-5, 9a

min. 1.000

Contact finish termination zone Thickness of plating 80 µin matte Sn over 50 µin Ni

Effectiveness of connector

co upli ng de vice IEC 512-8, 15f

50 N

She ll/shi e ld mate ri al

Standard de scriptio n C2680 (acc. JIS)

Shell/shield plating

Thickness of plating 50 µin Ni

El e c tri c al p ro p e rti e s

Cre e p ag e / c l e aran c e d i stan c e s

A sse mb l y p ro c e ss

a) Contact - contact

IEC 807-3

0,52 mm

P ackagi ng

b) Co ntact - she ll

min. 1, 0 mm

T ray

IEC 807-3

So lde r te mpe rature

235°C at 3-5s

Vo l tag e p ro o f (Di e l e c tri c Wi thstan d Vo l tag e )

Suitable asse mbly pro ce ss

wave

IEC 512-2, 4a

mi n. 1. 000 V AC/ DC

a) Co ntact - co ntact

b) Contact - shell/testpanel IEC 512-2, 4a

min. 1.500 V AC/DC

A p p ro v al s

Current carrying capacity

IEC 512-3, 5b

1,5 A @ 25° C

UL i nsulatio n bo dy

Co ntact re sistance

IEC 512-2, 2a

max. 30 mOhm

UL 94

UL Fi le N o .

Insulati o n re sistance

IEC 512-2, 3a

E145613

mi n. 500 MOhm

Ro HS co mpli ant

Yes

En v i ro n me n tal p ro p e rti e s

Ope rati o n te mpe rature

0 - 70° C

133167

Proprietary notice pursuant to ISO 16016 to be observed.

Information:

Tolerances

All Dimensions

in mm[in]

Scale

2:1

Designation

Only for Information.

To insure that this is the latest

version of this drawing, please

contact one of the ERNI companies

before using.

Index

05.07.2007

Date

Class

Subject to modification without

prior notice.

Drawing will not be updated.

MOD JACK - MJR

8P8C, 1X1, CAT 5

www.ERNI.com

133703

I (1/1)
