DATASHEET
2.7V 50F ULTRACAPACITOR CELL
FEATURES AND BENEFITS
• High performance product with low
ESR
• Exceptional shock and vibration
resistance
BCAP0050 P270 S01
ESHSR-0050C0-002R7
TYPICAL APPLICATIONS
• Actuators
• Emergency Lighting
• Telematics
• Automotive
• Backup System
• Smoke Detectors
• Advanced Metering
• Long lifetimes with up to 500,000
duty cycles*
• Compliant with UL, RoHS and
REACH requirements
• Security Equipment
PRODUCT SPECIFICATIONS
ELECTRICAL
Rated Voltage, V
R
Surge Voltage
1
Rated Capacitance, C
3
2.7 VDC
50 F
TYPICAL CHARACTERISTICS
THERMAL
Typical Thermal Resistance
(R
th
, Housing)
8
25°C/W
11 J/°C
6.1 A
10.0 A
2.85 VDC
45 F / 60 F
3
Typical Thermal Capacitance (C
th
)
Usable Continuous Current (BOL)
(∆T = 15 °C)
8,10
Usable Continuous Current (BOL)
(∆T = 40 °C)
8,10
Min. / Max. Capacitance,
Initial
Typical Capacitance, Initial
2,3
Rated (Max.) ESR
DC
, Initial
Typical ESR
DC
, Initial
2,3
16 mΩ
10 mΩ
16 mΩ
73 μA
37 A
12.2 g
Extended (-40°C to
85°C) at 2.3 V
36.7 mWh
3.0 Wh/kg
3.2 kW/kg
6.7 kW/kg
RoHS, REACH,
UL 810A
54.5 F
LIFE*
Typical ESR
DC
, Initial, 5 sec
2,3
Maximum Leakage Current
4
Maximum Peak Current,
Non-repetitive
5
Projected DC Life at Room
Temperature
(At rated voltage and 25°C, EOL )
10
10 years
1,500 hours
1,500 hours
DC Life at High Temperature
(At rated voltage and 65°C, EOL
10
)
PHYSICAL
Nominal Mass
DC Life at De-rated Voltage & Higher
Temperature
(At 2.3V and 85°C, EOL )
10
POWER & ENERGY
Operating Temp.
Range
Maximum Stored
Energy, E
max6,9
Gravimetric
Specific Energy
6
Usable Specific
Power
6
Standard (-40°C
to 65°C) at 2.7 V
50.6 mWh
4.1 Wh/kg
4.4 kW/kg
9.3 kW/kg
Projected Cycle Life at Room
Temperature
7
Shelf Life
(Constant current charge-discharge from V
R
to
1/2V
R
at 25°C, EOL
10
)
(Stored uncharged at 25°C, ≤ 50% RH)
500,000 cycles
4 years
SAFETY
Impedance Match
Specific Power
6
Certifications
*Results may vary. Additional terms and conditions, including the limited warranty, apply at the time of purchase. See the warranty details for applicable operating and use requirements.
Page 1
Document number: 3001980-EN.3
maxwell.com
Datasheet: 2.7V 50F ULTRACAPACITOR CELL
1.
2.
3.
Surge Voltage
Absolute maximum voltage, non-repetitive. Duration not to exceed 1 second.
“Typical” values represent mean values of production sample.
Rated Capacitance & ESR
DC
(measure method)
• Capacitance: Constant current charge (10 mA/F) to V
R
, 5 min hold at V
R
,
constant current discharge 10 mA/F to 0.1V.
e.g. in case of 2.7V 50F cell, 10 * 50 = 500 mA
• ESR
DC
: Constant current charge (10 mA/F) to V
R
, 5 min hold at V
R
, constant
current discharge (40 * C * V
R
[mA]) to 0.1 V.
e.g. in case of 2.7V 50F cell, charge with 10 * 50 = 500 mA and discharge with
40 * 50 * 2.7 = 5,400 mA
I=
½V
R
∆t / C + ESR
DC
where Δt is the discharge time (sec); Δt = 1 sec in this case.
• The stated maximum peak current should not be used in normal operation
and is only provided as a reference value.
6.
Energy & Power (Based on IEC 62391-2)
• Maximum Stored Energy, E
max
(Wh) =
½CV
R2
3,600
E
max
• Gravimetric Specific Energy (Wh/kg) =
• Usable Specific Power (W/kg) =
mass
0.12V
R2
ESR
DC
x mass
0.25V
R2
• Impedance Match Specific Power (W/kg) =
ESR
DC
x mass
• Presented Power and Energy values are calculated based on Rated
Capacitance & Rated (Max.) ESR
DC
, Initial values.
7.
C=
I x (t
2
-t
1
)
V
1
-V
2
ESR
DC
=
ΔV
I
Cycle Life Test Profile
Cycle life varies depending upon application-specific characteristics. Actual
results will vary.
Temperature Rise at Constant Current
• ∆T=I
RMS2
x ESR
DC
x R
th
where ∆T: Temperature rise over ambient (°C)
I
RMS
: Maximum continuous or RMS current (A)
R
th
: Thermal resistance, cell to ambient (°C/W)
ESR
DC
: Rated (Max.) ESR
DC
(Ω).
(Note: Design should consider EOL ESR
DC
for application temperature rise
evaluation.)
where C is the capacitance (F);
I is the absolute value of the discharge current (A);
V
R
is the rated voltage (V);
V
1
is the measurement start voltage, 0.8ⅹV
R
(V);
V
2
is the measurement end voltage, 0.4ⅹV
R
(V);
t
1
is the time from start of discharge to reach V
1
(s);
t
2
is the time from start of discharge to reach V
2
(s);
ESR
DC
is the DC-ESR (Ω);
ΔV is the voltage drop during first 10ms of discharge (V).
8.
Typical ESR
DC
, Initial, 5 sec tested per Maxwell Application Note, “Test Procedures
for Capacitance, ESR, Leakage Current and Self-Discharge Characterizations of
Ultracapacitors” available at www.maxwell.com.
9.
4.
Maximum Leakage Current
• Current measured after 72 hrs at rated voltage and 25°C. Initial leakage current
can be higher.
• If applicable, module leakage current is the sum of cell and balancing circuit
leakage currents.
Maximum Peak Current
• Current needed to discharge cell/module from rated voltage to half-rated
voltage in 1 second.
Per United Nations material classification UN3499, all Maxwell ultracapacitors
have less than 10 Wh capacity to meet the requirements of Special Provisions
361. Both individual ultracapacitors and modules composed of those
ultracapacitors shipped by Maxwell can be transported without being treated as
dangerous goods (hazardous materials) under transportation regulations.
®
10.
5.
BOL: Beginning of Life, rated initial product performance
EOL: End of Life criteria.
• Capacitance: 80% of min. BOL rating
• ESR
DC
: 2x max. BOL rating
BCAP0050 P270 S01
Part Description
BCAP0050 P270 S01
L
(±1.0)
41.0
D
(+0.5)
18.0
Dimensions (mm)
d
H1
(±0.05)
(min.)
0.80
15.0
H2
(min.)
19.0
A
(±0.5)
7.5
When ordering, please reference the Maxwell Model Number below.
Maxwell Model Number:
BCAP0050 P270 S01
Maxwell Part Number:
133520
Alternate Model Number:
ESHSR-0050C0-002R7
