CLT-119-02-F-D-BE-A datasheet, PDF

Datasheet> All Categories > The connector> The connector> CLT-119-02-F-D-BE-A

CLT-119-02-F-D-BE-A: Description2MM SOCKET STRIPS; CategoryThe connector The connector; File Size171KB，1 Pages; ManufacturerSAMTEC; Websitehttp://www.samtec.com/; Environmental Compliance

Download Datasheet Parametric View All

CLT-119-02-F-D-BE-A Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	CLT-119-02-F-D-BE-A	-	-	View	Buy Now

CLT-119-02-F-D-BE-A Overview

2MM SOCKET STRIPS

CLT-119-02-F-D-BE-A Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
package instruction	ROHS COMPLIANT
Reach Compliance Code	not_compliant
Factory Lead Time	2 weeks
Other features	BOTTOM ENTRY, E.L.P., LOW PROFILE, TIGER CLAW CONTACT
Board mount options	POSITIONING PIN
body width	0.157 inch
subject depth	0.084 inch
body length	1.496 inch
Body/casing type	SOCKET
Connector type	BOARD CONNECTOR
Contact to complete cooperation	GOLD FLASH OVER NICKEL (50)
Contact completed and terminated	Tin (Sn) - with Nickel (Ni) barrier
Contact point gender	FEMALE
Contact material	PHOSPHOR BRONZE
contact mode	RECTANGULAR
Contact resistance	10 mΩ
Contact style	SQ PIN-SKT
DIN compliance	NO
Durability	100 Cycles
Filter function	NO
IEC compliance	NO
maximum insertion force	.5004 N
Insulator color	BLACK
insulator material	LIQUID CRYSTAL POLYMER (LCP)
JESD-609 code	e3
MIL compliance	NO
Manufacturer's serial number	CLT
Plug contact pitch	0.079 inch
Match contact row spacing	0.079 inch
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation method	STRAIGHT
Installation type	BOARD
Number of connectors	ONE
PCB row number	2
Number of rows loaded	2
Maximum operating temperature	125 °C
Minimum operating temperature	-65 °C
Options	GENERAL PURPOSE
PCB contact pattern	RECTANGULAR
PCB contact row spacing	4.5212 mm
Plating thickness	FLASH inch
Rated current (signal)	2 A
Guideline	UL
reliability	COMMERCIAL
Terminal length
Terminal pitch	2 mm
Termination type	SURFACE MOUNT
Total number of contacts	38
Evacuation force-minimum value	.1668 N
Base Number Matches	1

Preview

Download Datasheet

View All

F-218 (Rev

10OCT17)

CLT–115–02–F–D–A–K–BE

EXTENDED LIFE

PRODUCT

HIGH MATING

CYCLES

10 YEAR MFG

WITH 30 µ" GOLD

CLT–125–02–L–D

CLT–105–02–F–D

(2.00 mm) .0787"

CLT SERIES

LOW-PROFILE DUAL WIPE SOCKET

SPECIFICATIONS

For complete specifications and

recommended PCB layouts

see www.samtec.com?CLT

Insulator Material:

Black Liquid Crystal Polymer

Contact Material:

Phosphor Bronze

Plating:

Sn or Au over

50 µ" (1.27 µm) Ni

Current Rating (TMMH/CLT):

4.1 A per pin

(2 pins powered)

Operating Temp Range:

-55 °C to +125 °C

Insertion Depth:

Top Entry=

(1.40 mm) .055" minimum

Bottom Entry=

(2.57 mm) .101" minimum

(add board thickness for

correct post OAL)

Max Cycles:

100 with 10 µ" (0.25 µm) Au

RoHS Compliant:

Yes

Mates with:

TMM, TMMH, MTMM,

MMT, TW, TSH

Available with optional

Pick & Place Pads

Tiger Claw

contacts

Low-profile

(2.21 mm)

.087"

Suitable for

pass-through

applications

APPLICATION

(2.00 mm)

.0787" pitch

Pass-Thru

ALSO AVAILABLE

(MOQ Required)

• Other platings

Contact Samtec.

PROCESSING

Lead–Free Solderable:

Yes

SMT Lead Coplanarity:

(0.10 mm) .004" max (02-25)

(0.15 mm) .006" max (26-34)*

(0.20 mm) .008" max (35-50)*

*(.004" stencil solution

may be available; contact

IPG@samtec.com)

CLT

NO. PINS

PER ROW

LEAD

STYLE

PLATING

OPTION

OTHER

OPTIONS

RECOGNITIONS

For complete scope of

recognitions see

www.samtec.com/quality

FILE NO. E111594

02 thru 50

= Through-

hole

–01

–02

–03

= Gold flash

on contact,

Matte Tin on tail

–F

–L

All options require

Style –02

= Surface

Mount

= 10 µ" (0.25 µm)

Gold on contact,

Matte Tin on tail

= Bottom Entry

(Required for bottom

entry applications)

–BE

–A

LEAD

STYLE

(2.16) .085

(2.95) .116

= Through-

hole

–01

–03

= 10 µ" (0.25 µm)

Gold on contact,

Gold flash on tail

–G

= Alignment Pin

(3 positions minimum)

Metal or plastic at

Samtec’s discretion

No. of positions x

(2.00) .0787

(4.00)

.157

(0.51)

.020

(5.08)

.200

(5.71)

.225

(2.00)

.0787

–P

= (5.00 mm) .197" DIA

Polyimide Film

Pick & Place Pad

(04 thru 50 only)

–K

(2.13)

.084

(2.27)

.090

(0.81)

.032

(5.16)

.203

–02

(0.64)

.025

DIA

–A

= Pick & Place Pad

(4 positions minimum)

(Not always necessary

for auto placement.)

–P

Note:

Some lengths, styles and

options are non-standard,

non-returnable.

(3.02)

.119

–01 or –03

= Tape & Reel

Packaging

(36 positions max)

–TR

(0.51)

.020

Due to technical progress, all designs, specifications and components are subject to change without notice.

All parts within this catalog are built to Samtec’s specifications.

Customer specific requirements must be approved by Samtec and identified in a Samtec customer-specific drawing to apply.

WWW.SAMTEC.COM
