FSA2259 — Low-Voltage, Dual-SPDT (0.8Ω) Analog Switch with 16kV ESD
November 2010
FSA2259 Low-Voltage, Dual-SPDT (0.8Ω) Analog
Switch with 16kV ESD
Features
0.8Ω Typical On Resistance (R
ON
) for +3.0V Supply
0.40Ω Maximum R
ON
Flatness for +3.0V Supply
-3db Bandwidth: > 50MHz
Low I
CCT
Current Over an Expanded Control Input
Range
Packaged in 10-Lead UMLP (1.4 x 1.8mm)
Power-Off Protection on Common Ports
Broad V
CC
Operating Range: 1.65 to 4.4V
ESD HBM JEDEC: JESD22-A114
-
I/O to GND: 8.5kV
-
Power to GND: 16.0kV
Description
The FSA2259 is a high-performance, dual, Single Pole
Double Throw (SPDT) analog switch that features low
R
ON
of 0.8Ω (typical) at 3.0V V
CC
. The FSA2259 operates
over a wide V
CC
range of 1.65V to 4.4V and is designed
for break-before-make operation. The select input is TTL-
level compatible.
The FSA2259 features very low quiescent current even
when the control voltage is lower than the V
CC
supply.
This feature suits mobile handset applications by
allowing direct interface with baseband processor
general-purpose I/Os with minimal battery consumption.
