DDC144TH
NPN PRE-BIASED SMALL SIGNAL DUAL SURFACE MOUNT TRANSISTOR
Features
Epitaxial Planar Die Construction
Nominal 47kΩ Built-In Biasing Resistor
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free "Green" Device (Note 3)
Mechanical Data
Case: SOT563
Case Material: Molded Plastic, “Green” Molding Compound;
UL Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminals: Finish – Matte Tin Plated Leads, Solderable per
MIL-STD-202, Method 208
Weight: 0.015 grams (Approximate)
SOT563
6
5
R
1
R
1
4
1
2
3
Top View
Device Schematic
Ordering Information
(Notes 3 & 4)
Product
DDC144TH-7-F
Notes:
Compliance
Standard
Marking
N21
Reel size (inches)
7
Tape width (mm)
8
Quantity per reel
3,000
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"
and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
4. For packaging details, go to our website at http://www.diodes.com/products/packages.html.
Marking Information
N21 = Product Type Marking Code
YM = Date Code Marking
Y = Year (ex: B = 2014)
M = Month (ex: 9 = September)
Date Code Key
Year
Code
Month
Code
2014
B
Jan
1
Feb
2
2015
C
Mar
3
2016
D
Apr
4
May
5
2017
E
Jun
6
2018
F
Jul
7
Aug
8
2019
G
Sep
9
2020
H
Oct
O
Nov
N
2021
I
Dec
D
DDC144TH
Document number: DS37170 Rev. 1 - 2
1 of 5
www.diodes.com
December 2014
© Diodes Incorporated
DDC144TH
Absolute Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Supply Voltage
Input Voltage
Output Current
Symbol
V
CC
V
IN
I
C(MAX)
Value
50
-10 to +40
100
Unit
V
V
mA
Thermal Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Power Dissipation (Notes 5 & 6)
Thermal Resistance, Junction to Ambient Air (Note 5)
Operating and Storage Temperature Range
Symbol
P
D
R
JA
T
J
, T
STG
Value
150
833
-55 to +150
Unit
mW
°C/W
°C
Electrical Characteristics
Characteristic
Collector-Base Breakdown Voltage
Collector-Emitter Breakdown Voltage
Emitter-Base Breakdown Voltage
Collector Cutoff Current
Emitter Cutoff Current
Collector-Emitter Saturation Voltage
DC Current Transfer Ratio
Input Resistor (R1)
Gain-Bandwidth Product (Note 7)
Notes:
(@T
A
= +25°C, unless otherwise specified.)
Symbol
BV
CBO
BV
CEO
BV
EBO
I
CBO
I
EBO
V
CE(sat)
h
FE
R
1
f
T
Min
50
50
5
100
32.9
Typ
250
47Ω
250
Max
0.5
0.5
0.3
600
61.1
Unit
V
V
V
μA
μA
V
kΩ
MHz
Test Condition
I
C
= 50μA
I
C
= 1mA
I
E
= 50μA
V
CB
= 50V
V
EB
= 4V
I
C
/I
B
= 1mA / 0.1mA
I
C
= 1mA, V
CE
= 5V
V
CE
= 10V, I
E
= -5mA, f = 100MHz
5. Mounted on FR4 PC Board with minimum recommended pad layout.
6. 200mW per element must not be exceeded.
7. Transistor - For Reference Only
