AP7350
150mA ULTRA-LOW QUIESCENT CURRENT LDO with ENABLE
Description
NEW PRODUCT
ADVANCED INFORMATION
The AP7350 is a low dropout regulator with high output voltage
accuracy. The AP7350 includes a voltage reference, error amplifier,
current limit circuit and an enable input to turn it on/off. With the
integrated resistor network, fixed output voltage versions can be
delivered.
Pad Assignments
WL-CSP
1: EN
4: V
IN
4:V
IN
1: EN
With its ultra-low quiescent current and miniature package
dimensions, the AP7350 is well suited for low-power handheld,
wearable devices, and other battery-operated devices requiring an
extended time period until new battery replacement.
2 : GND
Top View
Bump View
3 : V
OUT
The AP7350 is available in the wafer level chip scale WLB0606-4
package. This part is one of the smallest LDO footprints in the
industry allowing for the use of a bare minimum of board space within
the application.
3 :V
OUT
2 : GND
Features
Low V
IN
and Wide V
IN
Range: 2.0 V to 5.25V
Guarantee Output Current, 150mA
Output Voltage Range: 1.2 to 4.5V
V
OUT
Accuracy: ±1%
Quiescent Current as Low as 0.25µA
Typical Standby Current 0.02µA
ESD Protection Exceeds JESD 22
Exceeds 4000-V Human Body Model (A114)
Exceeds 400-V Machine Model (A115)
Latch-Up Exceeds 400mA per JESD 78, Class I
Totally Lead-Free & and Fully RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Note 3)
Applications
Wearable Electronics
Sensor Module for Internet-of-Things (IoT)
Wireless Communication Module
Battery-Operated Device
Camera
Image Sensor
Typical Applications Circuit
(Notes 4 & 5)
V
IN
V
IN
V
OUT
AP7350
V
OUT
C
IN
0.1uF
EN
C
OUT
0.1uF
GND
Notes:
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green" ,
and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl)
and <1000ppm antimony compounds.
4. X5R- and X7R-type capacitors are suggested due to their minimal variation in value and ESR over temperature.
5. Avoid light exposure of the chip scale package to maintain the expected electrical performance and functionality of the AP7350.
AP7350
Document number: DS38432 Rev. 2 - 2
1 of 13
www.diodes.com
January 2018
© Diodes Incorporated
AP7350
Functional Block Diagram
V
IN
V
OUT
-
+
VREF
Current Limit
V
IN
-
+
VREF
Current Limit
V
OUT
NEW PRODUCT
ADVANCED INFORMATION
EN
GND
EN
GND
AP7350 (without discharge)
AP7350D (with discharge)
Absolute Maximum Ratings
(Note 6)
Symbol
ESD HBM
ESD MM
V
IN
V
EN
V
OUT
T
A
T
J
T
STG
P
D
Notes:
Parameter
Human Body Model ESD Protection
Machine Model ESD Protection
Input Voltage
Input Voltage at EN pad
Output Voltage to GND
Operating Ambient Temperature
Maximum Junction Temperature
Storage Temperature
Power Dissipation (Note 7)
Rating
4
400
6.0
6.0
-0.3 to V
IN
+0.3
-40 to +85
+125
-55 to +125
315
Unit
kV
V
V
V
V
°C
°C
°C
mW
6. Stresses beyond those listed under Absolute Maximum Ratings may cause permanent damage to the device. These are stress ratings only and
functional operation of the device at these conditions is not implied. Exposure to absolute-maximum-rated conditions for extended periods may affect
device reliability
7. This is based on an application temperature of 40°C. Derate 3.75 mW per °C for each degree above 40°C.
Recommended Operating Conditions
Symbol
V
IN
I
OUT
T
A
Input Voltage
Output Current
Operating Ambient Temperature
Parameter
Min
2.0
0
-40
Max
5.25
150
+85
Unit
V
mA
°C
AP7350
Document number: DS38432 Rev. 2 - 2
3 of 13
www.diodes.com
January 2018
© Diodes Incorporated
AP7350
Electrical Characteristics
(@T
A
= +25°C, V
EN
= V
IN
= 5.0V (V
OUT
> 4.0V), V
EN
= V
IN
= V
OUT
+1V (1.5V < V
OUT
≤ 4.0V ), V
EN
= V
IN
=
2.5V (V
OUT
≤ 1.5V), I
OUT
= 1mA, C
IN
= C
OUT
= 0.1µF, unless otherwise specified.)
Parameter
Conditions
T
A
= -40°C to +85°C
V
OUT
> 2.0V
I
OUT
= 1mA
T
A
= +25°C
T
A
= -40°C to +85°C
T
A
= +25°C
T
A
= -40°C to +85°C
Min
2.0
-1
-2
-40
-80
Typ
–
–
–
-
-
Max
5.25
+1
Unit
V
NEW PRODUCT
ADVANCED INFORMATION
Input Voltage
%
+2
40
mV
80
Output Voltage Accuracy
V
OUT
≤
2.0V
I
OUT
= 1mA
Line Regulation (∆V
OUT
/∆V
IN
/V
OUT
)
MAX (V
OUT
+ 1.0V, 2.5V)
≤
V
IN
≤
5.0V
–
0.02
0.1
%/V
Load Regulation (∆V
OUT
)
Short Circuit Current Limit (Note 8)
Quiescent Current (Note 9)
I
STANDBY
Output Current
1 mA ≤ I
OUT
≤ 150 mA (all versions except 4.5V)
1 mA ≤ I
OUT
≤ 150 mA (applicable to 4.5V version)
V
OUT
= 0V
I
OUT
= 0 mA
Set EN low, No load
Vin ≥ V
OUT
+ V
DROPOUT
V
OUT
= 1.2V
V
OUT
= 1.5V
V
OUT
= 1.8V
V
OUT
=1.85V
T
A
= +25°C
T
A
= -40°C to +85°C
-25
-45
-
-
-
-
150
-
-
-
-
-
-
-
-
-
-
-
-
1.0
-
-
-
60
0.25
-
0.02
-
0.60
0.43
0.33
0.32
0.22
0.21
0.19
0.18
0. 16
0.14
267
-
-
35
25
45
-
0.4
0.7
0.2
-
0.90
0.75
0.60
0.58
0.48
0.44
0.40
0.35
0.35
0.35
-
0.4
5.25
-
mV
mV
mA
µA
µA
µA
mA
Dropout Voltage (Note 10)
I
OUT
= 150 mA
V
OUT
= 2.5V
V
OUT
=2.7V
V
OUT
=2.8V
V
OUT
=3.0V
V
OUT
=3.3V
V
Θ
JA
(Note 11)
EN Input Low Voltage
EN Input High Voltage
V
OUT
=4.5V
Thermal Resistance Junction-to-Ambient
Package : X2-WLB0606-4
–
–
°C/W
V
V
Ω
Active Output Discharge Resistance
V
IN
= 4.0V, V
EN
= 0V
(Note
Notes:
12)
8. Short circuit current is measured with V
OUT
pulled to GND.
9. Quiescent current defined here is the difference in current between the input and the output.
10 Dropout voltage is the voltage difference between the input and the output at which the output voltage drops 2% below its nominal value.
11. Test condition: WL-CSP is mounted on PCB (compliant with JEDEC standard).
12. AP7350 is available with 2 options: built-in discharge (AP7350D) and non-discharge (AP7350).
AP7350
Document number: DS38432 Rev. 2 - 2
4 of 13
www.diodes.com
January 2018
© Diodes Incorporated
