D5V0H1U2LP
1 CHANNEL UNIDIRECTIONAL TVS
Product Summary
ADVANCE INFORMATION
V
BR (Min)
6.2V
I
PP (Max)
30A
C
T (Typ)
190pF
Features
Low Profile Package (0.53mm Max) and Ultra-Small PCB Footprint
Area (1.08mm * 0.68mm Max) Suitable for Compact Portable
Electronics
Provides ESD Protection per IEC 61000-4-2 Standard:
Air ±30kV, Contact ±30kV
1 Channel of ESD Protection
Low Channel Input Capacitance
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Note 3)
Description
This new generation TVS is designed to protect sensitive electronics
from the damage due to ESD. The combination of small size and high
ESD surge capability makes it ideal for use in portable applications
such as cellular phones, digital cameras, and MP3 players.
Applications
Cellular Handsets
Portable Electronics
Computers and Peripheral
Mechanical Data
X1-DFN1006-2
Case: X1-DFN1006-2
Case Material: Molded Plastic, ―Green‖ Molding Compound. UL
Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminals: NiPdAu over Copper Leadframe. Solderable per MIL-
STD-202, Method 208
e4
Weight: 0.001 grams (Approximate)
Pin 2
Pin 1
Bottom View
Device Schematic
Ordering Information
(Note 4)
Product
D5V0H1U2LP-7B
Notes:
Compliance
Standard
Marking
P2
Reel Size (inches)
7
Tape Width (mm)
8
Quantity Per Reel
10,000/Tape & Reel
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"
and Lead-free.
3. Halogen- and Antimony-free "Green‖ products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
4. For packaging details, go to our website at http://www.diodes.com/products/packages.html.
Marking Information
P2
P2 = Product Type Marking Code
Bar Denotes Pin 1 or Cathode Side
D5V0H1U2LP
Document number: DS37544 Rev. 1 - 2
1 of 4
www.diodes.com
November 2016
© Diodes Incorporated
D5V0H1U2LP
Maximum Ratings
(@T
A
= +25° unless otherwise specified.)
C,
Characteristic
Symbol
P
PP
I
PP
V
ESD_CONTACT
V
ESD_AIR
Value
420
30
±30
±30
Unit
W
A
kV
kV
Conditions
8/20µs, per Figure 3
8/20µs, per Figure 3
IEC 61000-4-2 Standard
IEC 61000-4-2 Standard
ADVANCE INFORMATION
Peak Pulse Power Dissipation
Peak Pulse Current
ESD Protection – Contact Discharge
ESD Protection – Air Discharge
Thermal Characteristics
Characteristic
Package Power Dissipation (Note 5)
Thermal Resistance, Junction to Ambient (Note 5)
Operating and Storage Temperature Range
Symbol
P
D
R
θJA
T
J
, T
STG
Value
250
500
-65 to +150
Unit
mW
C/W
C
Electrical Characteristics
Characteristic
Reverse Working Voltage
Reverse Current (Note 6)
Reverse Breakdown Voltage
Reverse Clamping Voltage
Capacitance
Notes:
(@T
A
= +25° unless otherwise specified.)
C,
Symbol
V
RWM
I
R
V
BR
V
CL
C
T
Min
—
—
6.2
—
—
—
Typ
—
0.1
—
—
—
190
Max
5.5
1.0
7.4
9.0
14.0
—
Unit
V
A
V
V
pF
—
V
R
= V
RWM
= 5.0V
I
R
= 1mA
I
PP
= 5A, t
p
= 8/20μs
I
PP
= 30A, t
p
= 8/20μs
V
R
= 0V, f = 1MHz
Test Conditions
5. Device mounted on FR-4 PCB pad layout (2oz copper) as shown on Diodes Incorporated’s suggested pad layout, which can be found on our website at
http://www.diodes.com/package-outlines.html.
6. Short duration pulse test used to minimize self-heating effect.
250
225
P
D
, POWER DISSIPATION (mW)
Note 5
100
200
175
150
125
100
75
50
25
0
0
25
50
75
100
125
150
T
A
, AMBIENT TEMPERATURE (°
C)
Figure 1 Power Derating Curve
175
PEAK PULSE DERATING % OF
PEAK POWER OR CURRENT
75
50
25
0
0
25
50
75 100 125 150 175 200
T
A
, AMBIENT TEMPERATURE
(
o
C)
(癈 )
Figure 2 Pulse Derating Curve
D5V0H1U2LP
Document number: DS37544 Rev. 1 - 2
2 of 4
www.diodes.com
November 2016
© Diodes Incorporated
D5V0H1U2LP
200
f=1MHz
ADVANCE INFORMATION
I
PP
, PEAK PULSE CURRENT (%I
pp
)
100
C
J
, JUNCTION CAPACITANCE (pF)
0
20
40
60
180
160
140
50
120
100
0
t, TIME (
s)
Figure 3 Typical 8 x 20祍 Pulse Waveform
Figure 3 Typical 8 × 20µs Pulse Waveform
80
0
2
3
4
5
V
R
, REVERSE VOLTAGE (V)
Figure 4 Typical Junction Capacitance
1
6
Package Outline Dimensions
Please see http://www.diodes.com/package-outlines.html for the latest version.
A
A1
D
R
E
b
X1-DFN1006-2
Dim
Min
Max
Typ
A
0.47
0.53
0.50
A1
0
0.05
0.03
b
0.45
0.55
0.50
D
0.95 1.075
1.00
E
0.55 0.675
0.60
e
-
-
0.40
L
0.20
0.30
0.25
R
0.05
0.15
0.10
All Dimensions in mm
L
e
Suggested Pad Layout
Please see http://www.diodes.com/package-outlines.html for the latest version.
X1
X
Y
Dimensions
C
G
X
X1
Y
G
C
Value (in mm)
0.70
0.30
0.40
1.10
0.70
D5V0H1U2LP
Document number: DS37544 Rev. 1 - 2
3 of 4
www.diodes.com
November 2016
© Diodes Incorporated
D5V0H1U2LP
