414-41-224-41-117000 datasheet, PDF

Datasheet> All Categories > The connector> The connector> 414-41-224-41-117000

414-41-224-41-117000: DescriptionCONN SKT DBL; CategoryThe connector The connector; File Size361KB，1 Pages; ManufacturerMill-Max; Websitehttps://www.mill-max.com; Environmental Compliance

Download Datasheet Parametric View All

414-41-224-41-117000 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	414-41-224-41-117000	-	-	View	Buy Now

414-41-224-41-117000 Overview

CONN SKT DBL

414-41-224-41-117000 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Mill-Max
Reach Compliance Code	compliant
Connector type	BOARD CONNECTOR
Contact to complete cooperation	GOLD (10) OVER NICKEL (100)
Contact completed and terminated	MATTE TIN (200) OVER NICKEL (150)
Contact material	NOT SPECIFIED
JESD-609 code	e3
Manufacturer's serial number	414

Preview

Download Datasheet

View All

INTERCONNECTS

SERIES 329, 340, 406, 414, 429 • 2,54 GRID SURFACE MOUNT

HEADERS AND SOCKETS • SINGLE AND DOUBLE ROW STRIPS

2,54

Number of Pins X 2,54

•

Series 329 and 429 pin interconnects feature

•

0,46 DIA.

3,07

7,06

2,79

•

0,46

1,60 DIA.

FIG. 1

5,08

2,54

•

Number of Pins

X 2,54 / 2

0,46 DIA.

space saving, pad style SMT termination using

MM #2956-X pins. See page 218 for details

Series 429 and 414 combine for a mated

height of 8,20

Series 340, 406 and 414 surface mount sockets

use MM #4078, #0668 and #1434 receptacles.

See pages 162, 164 and 167 for details

Series 340, 406 and 414 receptacles use Hi-Rel,

4- nger BeCu #30 contacts rated at 3 amps.

Receptacles accept 0,38 - 0,64 diameter pins

See page 253 for details

Insulators are high temperature thermoplastic,

suitable for all soldering operations

3,07

7,06

ORDERING INFORMATION

Series 329...560

2,54

2,79

0,97 DIA.

0,46

FIG. 1

Series 429...560

Single Row Surface Mount Pin Header

329 10 1_ _ 00 560000

02-64

FIG. 2

Specify number of pins

FIG. 2

SPECIFY PLATING CODE XX=

Pin Plating

Double Row Surface Mount Pin Header

429 10 2_ _ 00 560000

04-72

Specify number of pins

0,25µm Au

Series 414...117

FIG. 3

0,38-0,64

0,25 * 0,46

Number of Pins X 2,54

2,54

5,08

2,29

2,79

FIG. 3

Series 340...780

Double Row Surface Mount Socket

414 XX 2_ _ 41 117000

04-72

Specify number of pins

2,11

4,37

2,79

FIG. 4

Series 406...068

3,3

Single Row Surface Mount Socket

340 XX 1_ _ 30 780100

02-64

Specify number of pins

1,42

1,17

Footprint

2,54

Double Row Surface Mount Socket

406 43 2 _ _ 30 068000

04-20

3,18

Coplanarity 0,13. For pin counts >24 positions, consult

Technical Support.

Ordering Information:

Number of Pins

X 2,54 / 2

406-43-2XX-30-068001

Available on 44mm wide tape, 355 parts per 330mm reel

RoHS - 2

5,08

2,34

1,35 DIA.

0,74 DIA.

2,54

2,79

3,71

2011/65/EU

XX=Plating Code

See Below

For

Electrical, Mechanical

& Enviromental Data,

See page 264

2,54

FIG. 5

SPECIFY PLATING CODE XX=

Sleeve (Pin)

Contact (Clip)

5,08µm Sn/Pb

5,08µm Sn 5,08µm Sn 5,08µm Sn

2,54µm Sn/Pb

0,25µm Au 0,76µm Au 2,54µm Sn

Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com

PAGE 49 | INTERCONNECTS

FIG. 4

FIG. 5

Specify number of pins

Tape and Reel Packaging

Recommended Resources
