BCM53101
®
Brief
SUMMARY OF BENEFITS
•
Enables next-generation six Fast Ethernet + one Gigabit
Ethernet switches with enhanced L2+ features
SEVEN-PORT MANAGED 10/100 ROBOSWITCH™
FEATURES
•
Highly integrated, 65 nm process, seven-port 10/100 Switch
integrating:
•
Five 10/100 MACs with five integrated 10/100 PHYs
•
One 10/100 MAC with MII/RvMII/RMII interface
•
One 10/100/1000 MAC with RGMII/MII/RvMII/RMII interface
Performance
•
2K MAC
•
2 KB max frame size
Virtual Local-Area Network (VLAN)
•
4K-entry port-based and 802.1Q VLAN (full 4K range)
•
VLAN based rate limiting
Quality of Service (QoS)
•
4 CoS queues – Port, 802.1p, and DiffServ
Security
•
IEEE 802.1x support for secure user authentication
BroadSync™ HD
•
Supports IEEE 802.1 Audio Video Bridging (AVB) draft standard
Traffic control and network resiliency
•
Ingress rate limiting and egress rate shaping
•
Spanning Tree Protocol/Rapid Spanning Tree Protocol/Multiple
Spanning Tree Protocol
•
Port mirroring
•
Full MIB counter set supported
•
IPv4 IGMP/IPv6 MLD snooping
•
Redirect reserved multicast MAC addresses to CPU
Low-Power Consumption
•
Less than 0.7W full power
•
Green features including auto power down, sleep, and deep sleep
modes
Technology and physical specifications
•
State-of-the-art 65 nm LP, 6-layer metal technology
•
1.2V core and 2.5V/3.3V I/O
•
High level of integration provides for cost-effective designs
•
Utilizes field-proven 10BASE-T/100BASE-TX Fast Ethernet
transceivers, lowering overall system interoperability and
reliability risks.
VLAN feature insures proper layer-2 isolation and security
•
•
•
•
•
•
•
Highly flexible 4K-entry VLAN implementation with support
for full 4K range
•
802.1Q-based VLAN and flexible priority queues mapped to
selectable protocols such as 802.1p, DiffServ, and COS enable
the switch to be designed into a variety of applications for
multimedia and data traffic.
•
802.1x port and MAC-based network security to keep the
network running efficiently
Enables multicast switching with IGMP and MLD snooping
without expensive L3 multicast routing
BroadSync™ HD enabled for guaranteed QoS and
bandwidth, latency, and time-sync for audio/visual traffic
between networked electronic devices
•
•
WAN port allows for one of the ports to be specified for WAN
connectivity
•
•
Significant power savings with innovative green modes and
65 nm LP process technology
BCM53101 Applications
OVERVIEW
Packet Buffer
L2 Tables
Memory Manager
4 COS SP/WRR
L2 Processing
EMAC
GMAC
EMAC
EMAC
EMAC
EMAC
EMAC
EPHY
EPHY
EPHY
EPHY
EPHY
RGMII/MII/RvMII/RMII MII/RvMII/RMII
TRD[1:0]
TRD[1:0]
TRD[1:0]
TRD[1:0]
TRD[1:0]
BCM53101 Block Diagram
Optimized for L2 switching, the BCM53101 is a feature-enhanced
seven-port switch to the industry-leading BCM5325E RoboSwitch™.
This device combines all the functions of a high-speed switch system,
including packet buffers, PHY transceivers, MACs, address
management, and a non-blocking switch fabric, into a 65 nm LP process.
The BCM53101 contains five full-duplex 10BASE-T/100BASE-TX
Fast Ethernet transceivers connected to the five on-chip 10/100 MACs.
In addition, a sixth 10/100 MAC is available through the MII/RvMII
interface. The BCM53101 also features a 10/100/1000 MAC, which can
be used to connect to an external CPU via the RGMII/MII/RvMII
interface.
The BCM53101 also integrates several gigabit-class features such as 4K-
entry VLAN, 2K-entry MAC addresses, ingress rate limiting and egress
rate shaping, port mirroring, IGMP/MLD snooping, and trap reserved
MAC addresses to CPU, among others.
The BCM53101 is designed from the ground up for lower power
consumption. The power-efficient on-chip PHYs help lower power
consumption by over 50% compared to its predecessor, the BCM5325E.
Fabricated using 65 nm LP process, the device consumes less than 0.7W.
Additionally, the BCM53101 incorporates several green modes such as
auto-power down, sleep mode, and a deep sleep mode (needs external
CPU).
