BZX84C6V8 TR datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > semiconductor> Discrete semiconductor> BZX84C6V8 TR

BZX84C6V8 TR: DescriptionDIODE ZENER 6.8V 350MW SOT23; Categorysemiconductor Discrete semiconductor; File Size402KB，3 Pages; ManufacturerCentral Semiconductor; Environmental Compliance

Download Datasheet Parametric View All

BZX84C6V8 TR Overview

DIODE ZENER 6.8V 350MW SOT23

BZX84C6V8 TR Parametric

Parameter Name	Attribute value
Voltage - Zener (nominal) (Vz)	6.8V
Tolerance	±5%
Power - Max	350mW
Impedance (max) (Zzt)	15 Ohms
Current at different Vr - Reverse leakage current	2µA @ 4V
Voltage at different If - Forward (Vf	900mV @ 10mA
Operating temperature	-65°C ~ 150°C
Installation type	surface mount
Package/casing	TO-236-3，SC-59，SOT-23-3
Supplier device packaging	SOT-23

Preview

Download Datasheet

View All

BZX84C2V4

THRU

BZX84C47

SURFACE MOUNT

SILICON ZENER DIODE

350mW, 2.4 THRU 47 VOLTS

w w w. c e n t r a l s e m i . c o m

DESCRIPTION:

The CENTRAL SEMICONDUCTOR BZX84C2V4

Series are surface mount silicon Zener diodes. These

high quality voltage regulating diodes are designed

for use in industrial, commercial, entertainment and

computer applications.

MARKING CODE: SEE ELECTRICAL

CHARACTERISTICS TABLE

SOT-23 CASE

MAXIMUM RATINGS:

(TA=25°C)

Power Dissipation

Operating and Storage Junction Temperature

Thermal Resistance

SYMBOL

TJ, Tstg

UNITS

°C

°C/W

350

-65 to +150

357

ELECTRICAL CHARACTERISTICS:

(TA=25°C), VF=0.9V MAX @ IF=10mA (for all types)

ZENER

VOLTAGE

VZ @ IZT

MIN

BZX84C2V4

BZX84C2V7

BZX84C3V0

BZX84C3V3

BZX84C3V6

BZX84C3V9

BZX84C4V3

BZX84C4V7

BZX84C5V1

BZX84C5V6

BZX84C6V2

BZX84C6V8

BZX84C7V5

BZX84C8V2

BZX84C9V1

BZX84C10

2.2

2.5

2.8

3.1

3.4

3.7

4.0

4.4

4.8

5.2

5.8

6.4

7.0

7.7

8.5

9.4

NOM

2.4

2.7

3.0

3.3

3.6

3.9

4.3

4.7

5.1

5.6

6.2

6.8

7.5

8.2

9.1

MAX

2.6

2.9

3.2

3.5

3.8

4.1

4.6

5.0

5.4

6.0

6.6

7.2

7.9

8.7

9.6

10.6

TEST

CURRENT

IZT

5.0

MAXIMUM

ZENER

IMPEDENCE

ZZT @ IZT

100

ZZK @ IZK

600

500

480

400

150

100

150

1.0

MAXIMUM

REVERSE

CURRENT

μA

5.0

3.0

2.0

1.0

3.0

2.0

1.0

0.7

0.5

0.2

1.0

2.0

4.0

5.0

6.0

7.0

MAXIMUM

ZENER

VOLTAGE

TEMP.

CURRENT

COEFF.

IZM

ΘV

104

% / °C

-0.06

-0.05

-0.03

0.02

0.03

0.04

0.05

0.06

0.07

TYPE

MARKING

CODE

Tolerance Code

Tolerance

±1%

±2%

Part Number Identification

B Z X 84 C 4V 7

Nominal Value Code(i.e. 4.7 Volts)

Tolerance Code

Device Series

R7 (20-November 2009)
