5990260007F Overview

LED YELLOW/GREEN 1206 SMD

5990260007F Parametric

Parameter Name	Attribute value
color	Yellow green
Configuration	-
Lens color	-
Lens transparency	-
millicandela level	54mcd
Lens style/size	Rectangular, with flat top, 2.00mm x 1.60mm
Voltage - Forward (Vf) (Typical)	2.1V
Current - Test	20mA
perspective	140°
Installation type	surface mount
Wavelength - Main	569nm
Wavelength - Peak	-
characteristic	-
Package/casing	1206 (3216 metric)
Supplier device packaging	1206
size/dimensions	3.20mm length x 1.60mm width
Height (maximum value)	0.80mm

Preview

Download Datasheet

View All

MicroLED

SMD LED, Single Color 1206 Package

3.2 mm x 1.6 mm x 0.7 mm

Certifications & Ratings

• RoHS compliant

599 Series

Features & Benefits

• Compatible with automatic placement equipment

• Packaged in 8 mm tape, 7" reel (4000 pcs/reel)

and 20 per strip

• Meets EIA-481-1 pkg. std.

Part Number Guide

RoHS Compliant

Dimensions

inches [mm]

.126 [3.2]

.063

[1.6]

.055

[1.4]

Tolerance

±0.2

mm unless otherwise noted

Package

R 0.008

[R 0.20]

5 9 9 - 0 2

Color



Red



Red-Orange



Orange



Yellow



Yellow-Green



Green

X - 0 0 X F

Packaging Option

20 piece tape

7" reel

4000 pcs/reel

Polarity Mark

.079 [2.0]

3°

.028 [0.7]

.012 [0.3]

–



Blue

Tape

Tolerance

±0.1

mm unless otherwise noted

Soldering

.063

[1.6]

598 Series, pkg 1206

package illustrations scaled at

.059

1mm : 28.125 mm

Feed Direction

.037

[0.94]

.079

[2.0]

.207

[5.25]

.137

[3.47]

Top

of Tape

.069 [1.79]

.157

[4.0]

.061

[1.55]

.069

[1.75]

.315

[8.0]

Polarity Mark

RF-BNS150TS-CE E1 RF-0069NP

2017-10-19.pdf

[1.5]

Direction of

Light Emission

Reflow Profile

Temp °C

250

.173 [4.4]

Hand Soldering

Temperature: 300° C max.

Soldering time: 3 sec max.

(one time only)

time at peak 10 sec (max)

ramp up

3°C/sec (max)

time above 217 °C

60–150 sec

Tpeak = 260 °C

Reel

TL = 217 °C

200

Tsmax = 200 °C

Tolerance

±0.1

mm unless otherwise noted

150

.315 [8.0]

7.01

[178±1.0]

2.362

[60±1.0]

Tsmin=

150 °C

120 sec (max)

Pre-heat: ∆T: 150–200 °C

60 sec

(min)

6 °C/sec (max)

598 Series, pkg 1206

package illustrations scaled at

1mm : 28.125 mm

ramp down

.512

[13±0.5]

Total Time to Peak temp < 8 min.

∆T: 25–260 °C

RF-BNS150TS-CE E1 RF-0069NP

2017-10-19.pdf

Time

Label

www.dialightsignalsandcomponents.com

60 sec

5990260007F Related Products

	5990260007F	5990220007F	5990210007F	5990240007F	5990230007F	5990291007F	5990281007F
Description	LED YELLOW/GREEN 1206 SMD	LED ORANGE-RED 1206 SMD	LED RED 1206 SMD	LED YELLOW 1206 SMD	LED ORANGE 1206 SMD	LED BLUE 1206 SMD	LED GREEN 1206 SMD
color	Yellow green	orange red	red	yellow	orange color	blue	green
millicandela level	54mcd	90mcd	29mcd	126mcd	112mcd	105mcd	340mcd
Lens style/size	Rectangular, with flat top, 2.00mm x 1.60mm	Rectangular, with flat top, 2.00mm x 1.60mm	Rectangular, with flat top, 2.00mm x 1.60mm	Rectangular, with flat top, 2.00mm x 1.60mm	Rectangular, with flat top, 2.00mm x 1.60mm	Rectangular, with flat top, 2.00mm x 1.60mm	Rectangular, with flat top, 2.00mm x 1.60mm
Voltage - Forward (Vf) (Typical)	2.1V	2.1V	2.1V	2.1V	2.1V	3.2V	3.2V
Current - Test	20mA	20mA	20mA	20mA	20mA	20mA	20mA
perspective	140°	140°	140°	140°	140°	140°	140°
Installation type	surface mount	surface mount	surface mount	surface mount	surface mount	surface mount	surface mount
Wavelength - Main	569nm	625nm	633nm	590nm	605nm	470nm	525nm
Package/casing	1206 (3216 metric)	1206 (3216 metric)	1206 (3216 metric)	1206 (3216 metric)	1206 (3216 metric)	1206 (3216 metric)	1206 (3216 metric)
Supplier device packaging	1206	1206	1206	1206	1206	1206	1206
size/dimensions	3.20mm length x 1.60mm width	3.20mm length x 1.60mm width	3.20mm length x 1.60mm width	3.20mm length x 1.60mm width	3.20mm length x 1.60mm width	3.20mm length x 1.60mm width	3.20mm length x 1.60mm width
Height (maximum value)	0.80mm	0.80mm	0.80mm	0.80mm	0.80mm	0.80mm	0.80mm
