Sealed Pushbutton Switches
Key Features
•
IP68 Rated
(1Meter, 60
Minutes)
Normally Open
and Normally
Closed Versions
Various Cap
Options
LED illuminated
flat cap versions
Various cap and
color
illuminations
Leaded options
for ease of
installation
LED illumination
technology for
long-term
reliability
IP68 Sub-Miniature Pushbutton Switches
•
•
•
•
•
•
TE Connectivity’s Sub-Miniature
Pushbutton range is a portfolio of high
quality,IP68 rated switches that comprises various cap styles and LED
illumination options.
These Pushbutton Switches are offered in High Cap, Round Cap, Flat Cap, and
LED Flat Cap actuators. For ease of installation without the need of soldering,
they are also available with 500mm leaded options.
As they are available in 5 different cap colors, including black, Red, Yellow,
Green, and Blue as well as multi-color LED options for the flat cap, these
switches can be used in a wide variety of applications.
Applications
Benefits
•
•
•
•
Industrial Equipment
Instrumentation
Communication Equipment
Control Equipment
•
•
Ease of installation with
available solderable or
500mm leaded terminations
Various colored caps for easy
visibility
SCHEMATIC
POS. 2
Switch Function / Schematic
NO.
POLES
SP
SP
MODEL
NO.
PB6
PB7
SWITCH FUNCTION
POS. 1
POS. 2
POS. 1
OFF
ON
MOM(ON)
MOM(OFF)
OPEN
CLOSE
CLOSE
OPEN
MOM = MOMENTARY
Document #: 0-2329328-1
Version Date: 03-2018
Dimensions in
millimetres (inches)
unless otherwise
specified
Dimensions Shown for
reference purposes only.
Specifications subject to
change
For Email, phone or live chat,
go to: www.te.com/help
Sealed Pushbutton Switches
Specifications
MAX. CURRENT/VOLTAGE
RATING WITH RESISTIVE
LOAD:
INITIAL CONTACT
RESISTANCE:
INSULATION RESISTANCE:
DIELECTRIC STRENGTH:
ELECTRICAL LIFE AT FULL
LOAD:
OPERATING
TEMPERATURE:
PANEL THICKNESS:
TOTAL TRAVEL:
OPERATING FORCE:
CONTACT BOUNCE:
MECHANICAL LIFE:
TORQUE:
DEGREE OF PROTECTION:
MANUAL SOLDERING:
WAVE SOLDERING:
400 mA 32 VAC
–
200 mA 50 VDC
–
125 mA 125 VAC
Without leads: 50mΩmax.
Leaded: 100mΩmax.
*
Resistance of the wire not included
1GΩmin.at 500 VDC
1,500 VAC RMS
500,000 cycles
-30°C to 85°C
1.5 (.059) to 4 (.157)
1.5 (.059)
3 to 6N
10 ms.
1,000,000 cycles
0.5 Nm max. applied to nut
IP68
Use soldering iron of 30 watts, controlled at 350°C
approximately 5 seconds while applying solder
Recommended Soldering Temperature:260 + 5°C
*
Ambient temperature of the soldered surface
of PC board. 110°C Max.
Duration of solder Immersion: Max 5 sec (PCB is 1.6mm)
Materials
CAP:
Polyamide 6/6
PLUNGER:
PB6:PC / PB7: Polyamide 6/6
RUBBER:
Silicone
BUSHING:
POLYAMIDE 6/6
CASE:
Diallyl phthalate (DAP)(UL94V-0)
TERMINAL/CONTACT:
Copper Alloy, Gold over
Silver plated
Hardware
M12 Nut
16.00
(
.630
)
Lock Washer
Ø
15.90
O-Ring
Ø
13.50
(
ø
.532)
14.00
(
.551
)
(
ø
.625)
1.20
(
.047
)
2.50
(
.098
)
1.0 THK
(.039)
Document #: 0-2329328-1
Version Date: 03-2018
Dimensions in
millimetres (inches)
unless otherwise
specified
Dimensions Shown for
reference purposes only.
Specifications subject to
change
For Email, phone or live chat,
go to: www.te.com/help
Sealed Pushbutton Switches
Bushing Type
B2
7.30
(.287)
10.70
(.421)
Panel Cut-Out
THICKNESS 1.5 to 4.0mm
12.90
-0.03
+.002
(.508
-.001
+0.05
Ø
17.50
)
(.689)
5.00
(.197)
1.20
(.047)
Ø
13.60
-0.10
+.000
(.534
-.004
+0.00
)
Cap Options
Flat
Ø
12.00
Round
without LED
(.472)
2.0
(.078)
Ø
12.00
High
without LED
2.59
(.102)
Ø
12.00
(.472)
(.472)
4.7
(.185)
Termination Options
M1
Solder Lug (PB6)
M1
Solder Lug (PB7)
M1
Solder Lug (PB6, with LED)
3.50
(.138)
2.80
(.110)
0.40
(.016)
5.08
(.200)
3.40
(.134)
2.80
(.110)
5.08
(.200)
0.40
(.016)
3.40
(.134) 0.40
(.016)
0.50
(.020)
2.80
(.110)
5.00
(.197)
0.20
(.008)
0.40
(.016)
5.08
(.200)
M2
Solder Lug (PB6)
5.50
(.217)
2.80
(.110)
0.40
(.016)
5.08
(.200)
M3
Solder Lug (PB6)
M4
PC Thru-hole (PB6)
8.20
(.323)
2.80
(.110)
5.08
(.200)
0.40
(.016)
3.50
(.138)
1.00
(.039)
5.08
(.200)
0.40
(.016)
Document #: 0-2329328-1
Version Date: 03-2018
Dimensions in
millimetres (inches)
unless otherwise
specified
Dimensions Shown for
reference purposes only.
Specifications subject to
change
For Email, phone or live chat,
go to: www.te.com/help
Sealed Pushbutton Switches
Wire Option
Code
12.70
(.500)
WIRE LENGTH
DIM ''L"
500+10 (19.7+ .394)
500+10 (19.7+ .394)
S500
500mm Lead
Ø
10.50
S500
Wire Length
Y500
(.413)
Code
DIM “L”
S500 500+10
NON - LED
(19.7 + .394)
DESCRIPTION
WIRE
.394)
Y100 500+10 (19.7 +
COLOR
TERMINAL 1
TERMINAL 2
BLACK
BLACK
WITH LED
DESCRIPTION
TERMINAL 1
TERMINAL 2
LED+
LED-
WIRE COLOR
BLACK
BLACK
RED
GREEN
Y500
500mm Lead with Heat Shrink
10.0
(.394)
*Multi-wire lead AWG20, section 0.6mm , UL approved
PB6 M1
Ø
17.50
(.689)
Ø
12.00
1.20
(.047)
2.80
(.110)
3.50
(.138)
5.00
(.197)
12.90
(.508)
5.08
(.200)
10.70
(.421)
(.472)
2.0
(.078)
0.40
(.016)
PB7 M1
Ø
17.50
(.689)
Ø
12.00
1.20
(.047)
10.70
(.421)
2.80
(.110)
(.472)
2.0
(.078)
5.00
(.197)
3.40
(.134)
13.40
(.527)
5.08
(.200)
0.40
(.016)
PB6 M1
with LED
Ø
17.50
(.689)
Ø
12.00
1.20
(.047)
0.50
(.020)
2.80
(.110)
0.40
(.016)
3.40
(.134)
10.70
(.421)
5.00
(.197)
0.40
(.016)
(.472)
2.0
(.078)
5.00
(.197)
15.10
(.595)
5.08
(.200)
.
Document #: 0-2329328-1
Version Date: 03-2018
Dimensions in
millimetres (inches)
unless otherwise
specified
Dimensions Shown for
reference purposes only.
Specifications subject to
change
For Email, phone or live chat,
go to: www.te.com/help
Sealed Pushbutton Switches
How To Order
Model NO.
Bushing
Cap Shape
Cap
Contact
Termination Material Seal
Color
LED Color
Wire
Model NO.
PB6
OFF-MOM (ON)
PB7
ON -MON(OFF)
Bushing
B2
Threaded bushing
Cap Shape & Appearance
FM
Flat Cap Matte (with and without LED)
RS
Round Cap Shiny (without LED)
HS
High Cap Shiny (without LED)
*Only flat cap available with LED
Wire
S500
500mm Lead
Y500
500mm Heat Shrink Lead
LED Color
L00
Without LED
L01
White
L03
Red
L05
Yellow
L06
Green
L07
Blue
Seal
A
Sealed
Contact Material
& Finish
C
Gold Over , Gold over Silver
*Only flat cap available with LED
Cap Color
2
Black
3
Red
5
Yellow
6
Green
7
Blue
Termination
M1
3.50 High, Solder Lug (PB6 only, Non-LED)
3.40 High, Solder Lug (with LED and PB7 Non-LED)
M2
5.50 High, Solder Lug, (PB6 only, Non-LED)
M3
8.20 High, Solder Lug, (PB6 only, Non-LED)
M4
3.50 High, PC Thru-Hole, (PB6 only, Non-LED)
Document #: 0-2329328-1
Version Date: 03-2018
Dimensions in
millimetres (inches)
unless otherwise
specified
Dimensions Shown for
reference purposes only.
Specifications subject to
change
For Email, phone or live chat,
go to: www.te.com/help
