PIN
RECEPTACLES
FOR .025” - .037” DIAMETER PINS AND .025” SQUARE PINS
0401/6401
.076 DIA.
.067 DIA.
X401-0-15-XX-47-XX-04-0
Press-fit in .064 mounting hole
.032
.028 .090
.230
.260
1303
Basic Part
Number
Length
A
.066 DIA.
.072 DIA.
.064 DIA.
.059 DIA.
1303-0-15-XX-47-XX-04-0
Press-fit in .061 mounting hole
.016
.030
.031 .088
.146
8303
.066 DIA.
.072 DIA.
.064 DIA.
.165
8303-0-15-XX-47-XX-04-0
Press-fit in .061 mounting hole
.016
.030
.031 .088
.146
.165
.061 DIA.
0401-0
6401-0
.340
.540
.059 DIA.
.025 DIA.
A
.022 DIA.
.125
.020 DIA.
.800
4095
.065 DIA.
.072 DIA.
.063 DIA.
KNURL
.059 DIA.
4095-0-15-XX-47-XX-04-0
Press-fit in .061 mounting hole
.016
.025
.028
.250
.280
.030
4014
.065 DIA.
.072 DIA.
.063 DIA.
KNURL
.059 DIA.
4014-0-15-XX-47-XX-04-0
Press-fit in .061 mounting hole
.016
.025
.028
.228
.030
8806
8806-0-18-XX-47-XX-40-0
Surface mount
Also available on 12mm wide carrier tape:
4,000 parts per 13” reel
See page 194.9 for Tape & Reel details
.100 DIA.
.084 DIA.
.258
.020
.083
.115
.051 DIA.
.060
.059
.080
P.C.B. Layout
.069
.025 DIA.
.635
.024 DIA.
.662
.010
.095
P.C.B. PAD
.095
0722
0722-0-33-XX-47-XX-10-0
6839
Wire crimp termination. Accepts wire
sizes 22 AWG Max. / 28 AWG Min.
.086
.061 DIA.
.200
.284
(.518)
.047 DIA.
.020 DIA.
HOLE
.035 DIA.
HOLE
.234
.125 .146
6839-0-40-XX-47-XX-10-0
Double Ended Receptacle
6368
.064 DIA.
MAX.
.061 DIA.
.069 DIA.
.088 DIA.
6368-0-33-XX-47-XX-10-0
4119
.078 DIA.
Wire crimp termination. Accepts wire
sizes 22 AWG Max. / 26 AWG Min.
4119-0-15-XX-47-XX-04-0
Press-fit in .083 mounting hole
.083
.068 DIA.
.278
.102 DIA.
.083
.086 DIA.
.075
.110
.127
.151
.078 DIA.
.067 DIA.
.183
.219
.059
.497
.029 DIA.
HOLE
.077 DIA.
.031
.326
(.175)
.146 .165
.023 DIA.
.406
.068 DIA.
.083
.035 DIA.
HOLE
PAGE 180 | PIN RECEPTACLES
SPECIFICATIONS:
Shell Material:
Brass Alloy 360, 1/2 Hard
Contact Material:
Beryllium Copper Alloy 172, HT
Dimensions: Inches
Tolerances On:
Lengths:
± .005
2011/65/EU
ORDER CODE: XXXX - X - XX - XX -
47
- XX - XX - 0
BASIC PART #
SPECIFY SHELL FINISH:
01
200
μ”
TIN/LEAD OVER NICKEL
80
200
μ”
TIN OVER NICKEL (RoHS)
15
10
μ”
GOLD OVER NICKEL (RoHS)
SPECIFY CONTACT FINISH:
01
200
μ”
TIN/LEAD OVER NICKEL
80
200
μ”
TIN OVER NICKEL (RoHS)
27
30
μ”
GOLD OVER NICKEL (RoHS)
Diameters: ± .002
Angles:
±2°
RoHS - 2
SELECT CONTACT:
#47
CONTACT (DATA ON PAGE 256)
(For alternate contact choices, see group D on page 248)
Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com
