RH3B-ULAC24V

Description
RELAY GEN PURPOSE 3PDT 10A 24V
CategoryTopical application    Mechanical and electrical/engineering/automation
File Size3MB,10 Pages
ManufacturerIDEC
Environmental Compliance
Download Datasheet Parametric View All

RH3B-ULAC24V Online Shopping

Suppliers Part Number Price MOQ In stock
RH3B-ULAC24V - - View Buy Now

RH3B-ULAC24V Overview

RELAY GEN PURPOSE 3PDT 10A 24V

RH3B-ULAC24V Parametric

Parameter NameAttribute value
Relay typeUniversal
Coil typeNo latch
coil current70mA
coil voltage24VAC
Contact shape3PDT(3 Form C)
Rated contact (current)10A
switching voltage120VAC, 30VDC - Max
Turn-on voltage (maximum value)19.2 VAC
Shut-off voltage (minimum value)7.2 VAC
operating hours25ms
release time25ms
characteristicLED indicator
Installation typePlugable
Terminal typePlug-in, QC - 0.187" (4.7mm)
Operating temperature-25°C ~ 70°C
Contact materialSilver Cadmium Oxide (AgCdO)
Coil power-
Coil resistance103 Ohms
Relays & Sockets
RH Series Compact Power Relays
Key features
• SPDT through 4PDT, 10A contacts
• Compact power type relays
• Miniature power relays with a large capacity
• 10A contact capacity
• Compact size saves space
RH
Switches & Pilot Lights
Signaling Lights
Part Number Selection
Part Number
Contact
Standard
SPDT
With Indicator
With Check Button
With Indicator and Check Button
Top Bracket Mounting
With Diode (DC coil only)
With Indicator and Diode (DC coil only)
DPDT
Standard
With Indicator
With Check Button
With Indicator and Check Button
Top Bracket Mounting
With Diode (DC coil only)
With Indicator and Diode (DC coil only)
3PDT
Standard
With Indicator
With Check Button
With Indicator and Check Button
Top Bracket Mounting
With Diode (DC coil only)
With Indicator and Diode (DC coil only)
4PDT
Standard
With Indicator
With Check Button
With Indicator and Check Button
Top Bracket Mounting
With Diode (DC coil only)
With Indicator and Diode (DC coil only)
PCB terminal relays are designed to mount directly to a circuit board without any socket.
Model
Blade
Terminal
RH1B-U
0
RH1B-UL
0
RH1B-UC
0
RH1B-ULC
0
RH1B-UT
0
RH1B-UD
0
RH1B-ULD
0
RH2B-U
0
RH2B-UL
0
RH2B-UC
0
RH2B-ULC
0
RH2B-UT
0
RH2B-UD
0
RH2B-ULD
0
RH3B-U
0
RH3B-UL
0
RH3B-UC
0
RH3B-ULC
0
RH3B-UT
0
RH3B-UD
0
RH3B-ULD
0
RH4B-U
0
RH4B-UL
0
RH4B-UC
0
RH4B-ULC
0
RH4B-UT
0
RH4B-UD
0
RH4B-ULD
0
PCB Terminal
RH1V2-U
0
RH1V2-UD
0
RH2V2-U
0
RH2V2-UL
0
RH2V2-UD
0
RH2V2-ULD
0
RH3V2-U
0
RH3V2-UL
0
RH4V2-U
0
RH4V2-UL
0
RH4V2-UD
0
Coil Voltage Code
(Standard Stock in bold)
Relays & Sockets
AC6V, AC12V,
AC24V,
AC110V,
AC120V,
AC220V,
AC240V
DC6V,
DC12V, DC24V,
DC48V, DC110V
DC6V,
DC12V, DC24V,
DC48V, DC110V
DC12V, DC24V,
DC48V, DC110V
Timers
AC6V, AC12V,
AC24V, AC110-120V,
AC220-240V
DC6V,
DC12V, DC24V,
DC48V, DC100-110V
DC6V,
DC12V, DC24V,
DC48V, DC100-110V
Contactors
AC6V, AC12V,
AC24V,
AC110V,
AC120V,
AC220V,
AC240V
DC6V,
DC12V, DC24V,
DC48V, DC110V
DC6V, DC12V, DC24V, DC48V, DC110V
Terminal Blocks
AC6V, AC12V,
AC24V,
AC110V,
AC120V,
AC220V,
AC240V
DC6V,
DC12V, DC24V,
DC48V,
DC110V
DC6V, DC12V, DC24V, DC48V, DC110V
Circuit Breakers
Ordering Information
When ordering, specify the Part No. and coil voltage code:
(example)
RH3B-U
Part No.
AC120V
Coil Voltage Code
1705151135
800-262-IDEC
(4332)
USA & Canada
