New
on
enerati
G
PLC
FT1A Series
- 12 I/O
Key Features
•
•
•
•
•
•
•
Available in 100-240V AC and 24V DC power
Available with/without embedded LCD
10 Amp Relay contacts
USB Mini-B Programming Port
Embedded Real Time Clock
Embedded 2-pt analog inputs (0-10V DC, 10-bit, DC power)
Integrated 4 x 100KHz high-speed counters
General Specifications
Part Numbers
Appearance
LCD Screen
Operating Temperature
Storage Temperature
Rated Power Voltage
Allowable Voltage Range
Rated Power Frequency
Maximum Power Consumption
Weight
24V DC
20.4 to 28.8V DC (Including ripple voltage)
–
4.3W
Approx. 190g
Yes
N/A
Yes
N/A
FT1A-H12RA
FT1A-B12RA
FT1A-H12RC
FT1A-B12RC
0 to +55°C (operating ambient temperature)
–25 to +70°C (no freezing)
100 to 240V AC
85 to 264V AC
50/60Hz (47 to 63Hz)
18VA
Approx. 230g
Function Specifications
Part Numbers
Program Capacity
Note 1
FT1A-H12RA, B12RA
12,000 bytes (3,000 steps)
Points
Digital Input (Terminal No.)
Shared Analog Input (Terminal No.)
6 (I0 to I5)
2 (I6, I7)
4
4 (Q0 to Q3)
–
–
8
FT1A-H12RC, B12RC
8 (I0 to I7)
–
Input
Output Points
10A Relay Output (Terminal No.)
2A Relay Output (Terminal No.)
Transistor Output (Terminal No.)
User Program Storage
RAM
Backup Duration
Backup Function
Battery
Charging Time
Battery Life
Replaceability
Clock Function
Note 3
Control System
Flash ROM (10,000 rewriting life)
Backup data: Internal relay, shift register, counter current value,
data register
Note 2
, clock data (year, month, and day)
Approx. 30 days (typical) at 25°C after backup battery fully charge
Lithium
Approx. 15 hours for charging from 0% to 90% of full charge
5 years
Not possible
Clock accuracy: ±30 sec/month (typical) at 25°C
Stored program system
Specifications con’t on next page
Specifications con’t
Part Numbers
Instruction Words
Processing Time
Internal Relay
Shift Register
Data Register
Counter (adding, reversible)
Timer (1-sec, 100ms,10ms, 1ms)
Input Filter
Catch Input/Interrupt Input
Self-diagnostic Function
Points
High-speed Counter
Maximum Counter Frequency
Counting Range
Operation Mode
Pulse Output (Maximum
frequency: 100kHz)
Pulse Output (Maximum
frequency: 5kHz)
Analog Voltage Input
Points
Points
Points (Terminal No.)
Input voltage Range
Digital Resolution
Points
USB Port
Expansion Communication Ports
Ethernet Port
Memory Cartridge Connectors
SD Memory Card Slots
1. Step is equivalent to 4 bytes.
2. Among data registers D0 to D1999, only D0 to D999 are backed up.
3. Set the calendar/clock using the clock function in WindLDR.
USB Standard
Connector
2 (I6, I7)
0 to 10V DC
0 to 1000
1
USB 2.0
Mini-B type
–
–
1
–
Input Points
Basic Instructions
Advanced Instructions
Basic Instruction
END Processing
FT1A-H12RA, B12RA
42
99
0.95ms (1000 steps)
640μs
1024
128
400m
100
100
Without filter, 3 to 15ms (selectable in increments of 1ms)
4
Keep data, Power failure, Clock error, Watchdog timer, Timer/counter preset value change error,
User program syntax, User program execution, System error, Memory cartridge transfer error
Total 4 points
0 to 4,294,967,295 (32 bit)
Rotary encoder mode and adding counter mode
–
–
–
–
Single/two-phase selectable: 100kHz (2 points) , Single-phase: 100kHz (2 points)
FT1A-H12RC, B12RC
Dimensions (mm)
With LCD
FT1A-H12*A/*C
76
11
A
Mounting Hole Layout
Without LCD
FT1A-B12*A/*C
76
A
11
Dimension Table
A
FT1A-H12RA
FT1A-B12RA
60
60
78
78
B
56
74
90
110.3
90
110.3
FT1A-H12RC
FT1A-B12RC
2-
ø4
.5
74
(76)
5∗
IDEC Corporation
•
1175 Elko Drive
•
Sunnyvale, CA 94089
•
800-262-IDEC (4332)
•
Fax: 408-745-5258
•
www.IDEC.com/usa
©2014 IDEC Corporation. All Rights Reserved.
03/14
PDF only
5∗
B
B
(90)
100
56
