CONDUCTIVE POLYMER ALUMINUM SOLID ELECTROLYTIC CAPACITORS (HYBRID TYPE)
PEV
PEV
SERIES
UPGRADE
Load Life : 105℃ 10000 hours (Hybrid Type) , Chip Type
・
High Voltage ∼63Vdc), Ultra Low ESR, High Ripple Current, Miniaturized.
（
・
AEC-Q200.
RoHS
compliance
◆SPECIFICATIONS
Items
Category Temperature Range
Rated Voltage Range
Capacitance Tolerance
Leakage Current(MAX)
Dissipation Factor(MAX)
Characteristics
−55∼＋105℃
25∼63Vdc
±20％
（20℃，
120Hz）
The value is shown in
“STANDARD SIZE”
table (After 2 minutes)
The value is shown in "STANDARD SIZE" table (20℃, 120Hz)
After applying rated voltage with rated ripple current for 10000 hours at 105℃,
the capacitors shall meet the following requirements.
Capacitance Change
Within ±30% of the initial value.
Not more than 200% of the initial specified value.
Not more than 200% of the initial specified value.
Not more than the initial specified value.
(tanδ)
Endurance
Dissipation Factor
E.S.R.
Leakage Current
After applying rated voltage for 2000 hours at 85℃ and humidity of 85%,
the capacitors shall meet the following requirements.
Capacitance Change
Biased Humidity
Dissipation Factor
E.S.R.
Leakage Current
Within ±30% of the initial value.
Not more than 200% of the initial specified value.
Not more than 200% of the initial specified value.
Not more than the initial specified value.
Low Temperature Characteristics
Impedance Ratio MAX）
（
Z
（−55℃） （＋20℃）
/Z
≦2.0
Z
（−25℃） （＋20℃）
/Z
≦1.5
（100kHz）
◆PART NUMBER
□□□
Rated Voltage
PEV
Series
□□□□□
Capacitance
Ｍ
Capacitance Tolerance
□□□
Option
D×L
Case Size
◆MULTIPLIER FOR RIPPLE CURRENT
Frequency
（Hz）
Coefficient
◆MARKING
100k≦
1.00
51A
68
H EV
120
0.05
1k
0.30
10k
0.70
Lot No.
Capacitance
Series
※
Rated voltage code
※Voltage code
Rated Voltage
(Vdc)
Voltage code
25
E
35
V
50
H
63
J
Negative
CONDUCTIVE POLYMER ALUMINUM SOLID ELECTROLYTIC CAPACITORS (HYBRID TYPE)
PEV
(mm)
◆DIMENSIONS
L MAX
A
1±0.2
φD＋0.5MAX
C
φD
6.3
L
8
A1
B1
C
W1
P
6.3 6.1 6.6 6.6 2.7 0.5∼0.8 1.8
B
1±0.2
6.6 6.6 2.7 0.5∼0.8 1.8
P
8 10.5 8.3 8.3 2.9 0.8∼1.1 3.1
C
10 10.5 10.3 10.3 3.2 0.8∼1.1 4.5
0.3MAX
W
1
0.5MAX
※
Vibration proof package is also available for φ8 and φ10. For details, please refer to chip aluminum electrolytic capacitors section.
◆STANDARD SIZE
Rated Voltage
（Vdc)
Capacitance
(μF)
Size
φD×L (mm)
(tanδ）
Leakage Current
(120Hz，
20℃)
(μA/2min)
E.S.R.(mΩ,max)
20℃, 100kHz −40℃, 10kHz
Rated Ripple Current
(mA r.m.s./105℃, 100kHz)
56
100
25
220
330
47
68
35
150
270
22
33
50
68
100
10
22
63
33
56
6.3×6.1
6.3×8
8×10.5
10×10.5
6.3×6.1
6.3×8
8×10.5
10×10.5
6.3×6.1
6.3×8
8×10.5
10×10.5
6.3×6.1
6.3×8
8×10.5
10×10.5
0.14
0.14
0.14
0.14
0.12
0.12
0.12
0.12
0.10
0.10
0.10
0.10
0.08
0.08
0.08
0.08
14.0
25.0
55.0
82.5
16.4
23.8
52.5
94.5
11.0
16.5
34.0
50.0
6.3
13.8
20.8
35.3
50
30
27
20
60
35
27
20
80
40
30
28
120
80
40
30
75
45
41
30
90
53
41
30
120
60
45
42
180
120
60
45
1300
2000
2300
2500
1300
2000
2300
2500
1100
1600
1800
2000
1000
1500
1700
1800
