KEMET HIGH GRADE COTS TANTALUM CHIPS - T497 SERIES
FEATURES
Pb-free/RoHS Compliant: Available
Self-healing Mechanism
Various Termination Options
Capacitance: 0.10 to 150
μF
Voltage: 4V to 25V
100% Accelerated Steady State Aging
Surge Current Testing Available
100% Thermal Shock
Low Profile Case Sizes
Customer Defined Performance Options
For custom low leakage and ESR solutions, contact your local KEMET Sales Representative.
OUTLINE DRAWING
DIMENSIONS - INCHES (Millimeters)
KEMET
Size
Code
A
B
C
D
E
F
G
H
X
L
Length
± .38 (.015)
2.54 (.100)
3.81 (.150)
5.08 (.200)
3.81 (.150)
5.08 (.200)
5.59 (.220)
6.73 (.265)
7.24 (.285)
6.93 (.273)
W
Width
± 0.38 (.015)
1.27 (.050)
1.27 (.050)
1.27 (.050)
2.54 (.100)
2.54 (.100)
3.43 (.135)
2.79 (.110)
3.81 (.150)
5.41 (.213)
H
Height
± 0.38 (.015)
1.27 (.050
1.27 (.050)
1.27 (.050)
1.27 (.050)
1.27 (.050)
1.78 (.070)
2.79 (.110)
2.79 (.110)
2.74 (.108)
P
+0.25 (.010)
- 0.13 (.005)
0.76 (.030)
0.76 (.030)
0.76 (.030)
0.76 (.030)
0.76 (.030)
0.76 (.030)
1.27 (.050)
1.27 (.050)
1.19 (.047)
W
2
1.27 ± 0.13 (.050 ± .005)
1.27 ± 0.13 (.050 ± .005)
1.27 ± 0.13 (.050 ± .005)
2.41 + .13, -.25 (.095 + .005, -.010)
2.41 + .13, -.25 (.095 + .005, -.010)
3.30 ± 0.13 (.130 ± .005)
2.67 ± 0.13 (.105 ± .005)
3.68 + 0.13, -0.51 (.145 + .005 - .020)
3.05 ± 0.13 (.120 ± .005)
H
2
Minimum
0.76 (.030)
0.76 (.030)
0.76 (.030)
0.76 (.030)
0.76 (.030)
1.02 (.040)
1.52 (.060)
1.52 (.060)
1.22 (.048)
KEMET ORDERING INFORMATION
T
Tantalum
Series
T497 High Grade
497
D
156 M
006
A
T
6XXX
6110
6115
6210
6215
6410
6415
Standard Features
Surge = None, 100% X-Ray
Surge = 10 Cycles, +25ºC
Surge = 10 Cycles, +25ºC, 100% X-Ray
Surge = 10 Cycles, -55ºC and +85ºC
Surge = 10 Cycles, -55ºC and +85ºC,
100% X-Ray
Performance Options
Case Size
A,B,C,D,E,F,G,H,X
Capacitance Picofarad Code
First two digits represent significant figures.
Third digit specifies number of zeros to follow.
Lead Material
T = 100% Tin
B = Gold
H = SnPb
(5% Pb minimum)
Capacitance Tolerances
M = ±20%; K = ±10%
Voltage
As shown
Note: 006 = 6.3V
Failure Rate
A = Not Applicable
B = 0.1%/1000 Hrs.
C = 0.01%/1000 Hrs.
F3271C 05/06
T497 RATINGS & PART NUMBER REFERENCE
Capacitance
μF
Case
Size
KEMET
Part Number
DC Leakage
VR (μA)
@ 25°C Max.
DF % @
+25°C
120 Hz
Max.
6.0
6.0
8.0
8.0
8.0
8.0
6.0
10.0
10.0
6.0
6.0
6.0
6.0
6.0
6.0
6.0
6.0
6.0
8.0
8.0
8.0
6.0
8.0
8.0
6.0
8.0
10.0
10.0
10.0
10.0
10.0
10.0
6.0
6.0
6.0
6.0
6.0
6.0
6.0
6.0
6.0
6.0
6.0
6.0
8.0
6.0
6.0
6.0
8.0
8.0
6.0
8.0
8.0
8.0
8.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
ESR
Ω
@ +25°C
100 kHz
Max.
12.0
8.0
8.0
4.0
2.2
3.0
2.0
1.1
0.9
8.0
10.0
12.0
8.0
12.0
5.5
8.0
4.5
8.0
3.5
8.0
5.0
5.0
3.5
2.2
3.5
3.5
1.1
1.5
0.9
1.1
1.1
0.9
10.0
10.0
10.0
12.0
8.0
12.0
10.0
8.0
4.5
8.0
5.0
3.5
8.0
4.0
3.5
5.0
3.0
2.5
4.0
2.0
1.5
1.5
1.5
1.1
1.5
1.0
0.9
1.1
1.1
0.9
0.9
4.7
4.7
15.0
33.0
33.0
68.0
68.0
68.0
100.0
1.5
2.2
3.3
3.3
4.7
4.7
6.8
6.8
10.0
10.0
15.0
15.0
22.0
22.0
22.0
33.0
47.0
47.0
68.0
68.0
100.0
150.0
150.0
0.47
1.0
1.5
2.2
2.2
3.3
3.3
4.7
4.7
6.8
6.8
6.8
10.0
10.0
10.0
15.0
15.0
15.0
22.0
22.0
22.0
22.0
33.0
33.0
47.0
47.0
47.0
68.0
100.0
100.0
150.0
4 Volt Rating at 85°C (2.7 Volt Rating at 125°C)
A/1005
T497A475(1)004(2)(3)
1.0
B/1505
T497B475(1)004(2)(3)
1.0
B/1505
T497B156(1)004(2)(3)
1.0
D/1510
T497D336(1)004(2)(3)
2.0
F/2214
T497F336(1)004(2)(3)
2.0
E/2010
T497E686(1)004(2)(3)
3.0
F/2214
T497F686(1)004(2)(3)
3.0
G/2711
T497G686(1)004(2)(3)
3.0
H/2915
T497H107(1)004(2)(3)
4.0
6 Volt Rating at 85°C (4 Volt Rating at 125°C)
A/1005
T497A155(1)006(2)(3)
1.0
A/1005
T497A225(1)006(2)(3)
1.0
A/1005
T497A335(1)006(2)(3)
1.0
B/1505
T497B335(1)006(2)(3)
1.0
A/1005
T497A475(1)006(2)(3)
1.0
D/1510
T497D475(1)006(2)(3)
1.0
B/1505
T497B685(1)006(2)(3)
1.0
D/1510
T497D685(1)006(2)(3)
1.0
B/1505
T497B106(1)006(2)(3)
1.0
E/2010
T497E106(1)006(2)(3)
1.0
B/1505
T497B156(1)006(2)(3)
1.0
D/1510
T497D156(1)006(2)(3)
1.0
D/1510
T497D226(1)006(2)(3)
1.0
E/2010
T497E226(1)006(2)(3)
2.0
F/2214
T497F226(1)006(2)(3)
2.0
E/2010
T497E336(1)006(2)(3)
2.0
F/2214
T497F476(1)006(2)(3)
3.0
G/2711
T497G476(1)006(2)(3)
3.0
F/2214
T497F686(1)006(2)(3)
4.0
H/2915
T497H686(1)006(2)(3)
4.0
G/2711
T497G107(1)006(2)(3)
6.0
G/2711
T497G157(1)006(2)(3)
10.0
H/2915
T497H157(1)006(2)(3)
10.0
10 Volt Rating at 85°C (7 Volt Rating at 125°C)
A/1005
T497A474(1)010(2)(3)
1.0
A/1005
T497A105(1)010(2)(3)
1.0
A/1005
T497A155(1)010(2)(3)
1.0
A/1005
T497A225(1)010(2)(3)
1.0
B/1505
T497B225(1)010(2)(3)
1.0
A/1005
T497A335(1)010(2)(3)
1.0
B/1505
T497B335(1)010(2)(3)
1.0
B/1505
T497B475(1)010(2)(3)
1.0
D/1510
T497D475(1)010(2)(3)
1.0
B/1505
T497B685(1)010(2)(3)
1.0
D/1510
T497D685(1)010(2)(3)
1.0
E/2010
T497E685(1)010(2)(3)
1.0
B/1505
T497B106(1)010(2)(3)
1.0
D/1510
T497D106(1)010(2)(3)
1.0
E/2010
T497E106(1)010(2)(3)
1.0
D/1510
T497D156(1)010(2)(3)
2.0
E/2010
T497E156(1)010(2)(3)
2.0
F/2214
T497F156(1)010(2)(3)
2.0
D/1510
T497D226(1)010(2)(3)
2.0
E/2010
T497E226(1)010(2)(3)
3.0
F/2214
T497F226(1)010(2)(3)
3.0
G/2711
T497G226(1)010(2)(3)
3.0
F/2214
T497F336(1)010(2)(3)
3.0
G/2711
T497G336(1)010(2)(3)
3.0
F/2214
T497F476(1)010(2)(3)
4.0
G/2711
T497G476(1)010(2)(3)
4.0
H/2915
T497H476(1)010(2)(3)
5.0
G/2711
T497G686(1)010(2)(3)
6.0
G/2711
T497G107(1)010(2)(3)
10.0
H/2915
T497H107(1)010(2)(3)
10.0
H/2915
T497H157(1)010(2)(3)
15.0
(1) To complete KEMET part number, insert Capacitance Tolerance: K = ±10%; M = ±20%.
(2) To complete KEMET part number, insert Failure Rate: A - Not Applicable; B = 0.1%/1000 Hrs.; C = 0.01%/1000 Hrs.
(3) To complete KEMET part number, insert Lead Material: T = 100% Tin; B = Gold; H= SnPb.
© KEMET Electronics Corporation P.O. Box 5928 Greenville, SC 29606 • (864) 963-6300 • www.kemet.com
T497 RATINGS & PART NUMBER REFERENCE
Capacitance
μF
Case
Size
KEMET
Part Number
DC Leakage
VR (μA)
@ 25°C Max.
DF % @
+25°C
120 Hz
Max.
ESR
Ω
@ +25°C
100 kHz
Max.
15.0
15.0
15.0
20.0
15.0
15.0
8.0
15.0
9.0
5.0
5.0
6.0
4.0
6.0
6.0
4.0
2.5
4.0
2.5
3.0
1.1
3.0
0.9
1.1
0.9
0.9
15.0
14.0
15.0
10.0
15.0
12.0
9.0
9.0
5.0
6.0
4.0
6.0
4.0
5.0
5.0
2.4
3.0
3.0
1.1
2.5
0.9
0.9
0.9
15.0
15.0
7.5
10.0
6.5
6.0
3.5
4.0
2.5
3.0
1.2
2.5
1.4
1.4
1.0
1.4
0.9
0.9
0.10
0.22
0.33
0.68
1.0
1.5
1.5
2.2
3.3
3.3
4.7
4.7
4.7
6.8
10.0
10.0
10.0
15.0
15.0
22.0
22.0
33.0
33.0
47.0
68.0
100.0
0.15
0.47
0.68
0.68
1.0
1.0
1.5
2.2
2.2
3.3
3.3
4.7
4.7
6.8
6.8
6.8
10.0
15.0
15.0
22.0
22.0
33.0
47.0
0.33
0.47
0.68
1.0
1.5
2.2
2.2
3.3
4.7
6.8
6.8
10.0
10.0
15.0
15.0
22.0
22.0
33.0
15 Volt Rating at 85°C (10 Volt Rating at 125°C)
A/1005
T497A104(1)015(2)(3)
1.0
6.0
A/1005
T497A224(1)015(2)(3)
1.0
6.0
A/1005
T497A334(1)015(2)(3)
1.0
6.0
A/1005
T497A684(1)015(2)(3)
1.0
6.0
A/1005
T497A105(1)015(2)(3)
1.0
6.0
A/1005
T497A155(1)015(2)(3)
1.0
6.0
B/1505
T497B155(1)015(2)(3)
1.0
6.0
A/1005
T497A225(1)015(2)(3)
1.0
6.0
B/1505
T497B335(1)015(2)(3)
1.0
6.0
D/1510
T497D335(1)015(2)(3)
1.0
6.0
B/1505
T497B475(1)015(2)(3)
1.0
6.0
D/1510
T497D475(1)015(2)(3)
1.0
6.0
E/2010
T497E475(1)015(2)(3)
1.0
6.0
D/1510
T497D685(1)015(2)(3)
1.0
6.0
D/1510
T497D106(1)015(2)(3)
2.0
6.0
E/2010
T497E106(1)015(2)(3)
2.0
6.0
F/2214
T497F106(1)015(2)(3)
2.0
6.0
E/2010
T497E156(1)015(2)(3)
2.0
6.0
F/2214
T497F156(1)015(2)(3)
2.0
6.0
F/2214
T497F226(1)015(2)(3)
3.0
8.0
G/2711
T497G226(1)015(2)(3)
4.0
6.0
F/2214
T497F336(1)015(2)(3)
5.0
6.0
H/2915
T497H336(1)015(2)(3)
5.0
8.0
G/2711
T497G476(1)015(2)(3)
10.0
8.0
H/2915
T497H686(1)015(2)(3)
10.0
8.0
H/2915
T497H107(1)015(2)(3)
15.0
10.0
20 Volt Rating at 85°C (13 Volt Rating at 125°C)
A/1005
T497A154(1)020(2)(3)
1.0
8.0
A/1005
T497A474(1)020(2)(3)
1.0
8.0
A/1005
T497A684(1)020(2)(3)
1.0
6.0
B/1505
T497B684(1)020(2)(3)
1.0
6.0
A/1005
T497A105(1)020(2)(3)
1.0
6.0
B/1505
T497B105(1)020(2)(3)
1.0
6.0
B/1505
T497B155(1)020(2)(3)
1.0
6.0
B/1505
T497B225(1)020(2)(3)
1.0
6.0
D/1510
T497D225(1)020(2)(3)
1.0
6.0
D/1510
T497D335(1)020(2)(3)
1.0
6.0
E/2010
T497E335(1)020(2)(3)
1.0
6.0
E/2010
T497E475(1)020(2)(3)
1.0
6.0
F/2214
T497F475(1)020(2)(3)
1.0
6.0
D/1510
T497D685(1)020(2)(3)
2.0
6.0
E/2010
T497E685(1)020(2)(3)
2.0
6.0
F/2214
T497F685(1)020(2)(3)
2.0
6.0
F/2214
T497F106(1)020(2)(3)
2.0
6.0
F/2214
T497F156(1)020(2)(3)
3.0
6.0
G/2711
T497G156(1)020(2)(3)
3.0
6.0
G/2711
T497G226(1)020(2)(3)
4.0
6.0
H/2915
T497H226(1)020(2)(3)
4.0
6.0
H/2915
T497H336(1)020(2)(3)
6.0
8.0
H/2915
T497H476(1)020(2)(3)
10.0
8.0
25 Volt Rating at 85°C (17 Volt Rating at 125°C)
A/1005
T497A334(1)025(2)(3)
1.0
6.0
A/1005
T497A474(1)025(2)(3)
1.0
6.0
B/1505
T497B684(1)025(2)(3)
1.0
6.0
B/1505
T497B105(1)025(2)(3)
1.0
6.0
D/1510
T497D155(1)025(2)(3)
1.0
6.0
D/1510
T497D225(1)025(2)(3)
1.0
6.0
E/2010
T497E225(1)025(2)(3)
1.0
6.0
E/2010
T497E335(1)025(2)(3)
1.0
6.0
F/2214
T497F475(1)025(2)(3)
2.0
6.0
F/2214
T497F685(1)025(2)(3)
2.0
6.0
G/2711
T497G685(1)025(2)(3)
2.0
6.0
F/2214
T497F106(1)025(2)(3)
2.0
6.0
G/2711
T497G106(1)025(2)(3)
3.0
6.0
G/2711
T497G156(1)025(2)(3)
4.0
6.0
H/2915
T497H156(1)025(2)(3)
4.0
6.0
G/2711
T497G226(1)025(2)(3)
6.0
6.0
H/2915
T497H226(1)025(2)(3)
6.0
6.0
H/2915
T497H336(1)025(2)(3)
10.0
8.0
(1) To complete KEMET part number, insert Capacitance Tolerance: K = ±10%; M = ±20%.
(2) To complete KEMET part number, insert Failure Rate: A - Not Applicable; B = 0.1%/1000 Hrs.; C = 0.01%/1000 Hrs.
(3) To complete KEMET part number, insert Lead Material: T = 100% Tin; B = Gold; H= SnPb.
© KEMET Electronics Corporation P.O. Box 5928 Greenville, SC 29606 • (864) 963-6300 • www.kemet.com
T497 RATINGS & PART NUMBER REFERENCE
COMPONENT MARKING
Polarity
Indicator (+)
Rated
Voltage
686
4
K
518
Picofarad
Code
KEMET ID
Print Week Code
1st Digit = Year
2nd & 3rd Digits = Week
“518” = 18th Week of 2005
PACKAGING SPECIFICATIONS
Tape and Reel Dimensions
KEMET
Case Codes
Tape
Width - mm
Part
A
B
C
D
E
F
G
H
X
1005
1505
2005
1510
2010
2214
2711
2915
2824
8
12
12
12
12
12
12
12
12
4
4
4
4
4
8
8
8
8
Pitch
mm ± 0.1
Sprocket
4
4
4
4
4
4
4
4
4
Reel Quantity
180mm
(7” dia)
2500
2500
2500
2500
2500
1000
500
500
500
330mm
(13” dia)
9500
9500
9500
9500
9500
3500
2500
2500
2500
LAND PATTERN DIMENSIONS FOR REFLOW SOLDER
Size Code
KEMET
A
B
C
D
E
F
G
H
X
EIA
1005
1505
2005
1510
2010
2214
2711
2915
2824
Z
3.42
4.65
5.72
4.65
5.72
6.43
7.57
8.08
8.08
Pad Dimensions (mm)
G
0.18
1.45
2.72
1.45
2.72
3.23
3.35
3.86
3.28
X
1.85
1.85
1.85
2.87
2.87
3.89
3.25
3.89
3.07
Y (Ref)
1.73
1.73
1.73
1.73
1.73
1.73
2.24
2.24
2.54
C (ref)
1.78
3.05
4.32
3.05
4.32
4.83
5.46
5.97
5.66
© KEMET Electronics Corporation P.O. Box 5928 Greenville, SC 29606 • (864) 963-6300 • www.kemet.com
Embedded System
京公网安备 11010802033920号
EEWORLD
