INTERCONNECTS
SERIES 315 & 415• .100” GRID,
SUPER LOW PROFILE SOCKETS • SINGLE AND DOUBLE ROW STRIPS
•
Series 315 and 415 solder mount sockets use
.050
Number of Pins X .100"
.100
.100
MM #0512 receptacles that accept pin
diameters from .015”-.022” . See pages 161
for details
•
Hi-Rel, 4-finger BeCu #12 contact is rated at
3 amps. See page 252 for details
Number of Pins
X .100"
•
.083” Super low profile above the board
utilizes .050” thick insulators
.050
•
Insulators are high temperature thermoplastic,
suitable for all soldering operations
.100
.010
.072 DIA.
(.062) .067
.149
.029 DIA.
.083
.082
ORDERING INFORMATION
Series 315...004
Single Row Socket
315-XX-1_ _-41-004000
Specify number of pins
01-32
.021 DIA.
HOLE
FIG. 1
FIG. 1
Number of Pins X .100" / 2
Series 415...004
Double Row Socket
415-XX-2_ _-41-004000
FIG. 2
.200
.100
Specify number of pins
04-72
.100
Number of Pins
X .100" / 2
.050
PAGE 45.2 | INTERCONNECTS
.100
.010
.072 DIA.
(.062) .067
.149
.029 DIA.
.083
.082
2011/65/EU
RoHS - 2
XX=Plating Code
See Below
13
10
μ”
Au
30
μ”
Au
For
Electrical, Mechanical
& Enviromental Data,
See page 264
.021 DIA.
HOLE
SPECIFY PLATING CODE XX=
93
200
μ”
Sn/Pb
43
200
μ”
Sn
30
μ”
Au
44
200
μ”
Sn
100
μ”
Sn
47
200
μ”
Sn
Au Flash
FIG. 2
Sleeve (Pin)
Contact (Clip)
30
μ”
Au
Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com
