Relays
Part Number: 3570 3572 3563 Series
General Purpose DIP Reed Relays
Product Data Sheet
FEATURES
• Industry standard, 14 pin DIP packages.
• High speed and low drive power.
• Optional diode and electrostatic shield available.
• 10 W Form A, 5 W Form C
• 5, 12 and 24 volt coils available.
• 1A, 2A and 1C contacts available.
• UL File E358613
®
SCHEMATIC
3570.1210
14
13
9
8
14
13
3572.1220
9
8
14
13
3563.1231
9
8
1
+2
1 FORM A
-6
7
1
+2
2 FORM A
-6
7
1
+2
1 FORM C
-6
7
ORDERING INFORMATION
Series
3570.1210. (1 Form A)
3572.1220. (2 Form A)
3563.1231. (1 Form C)
Coil
05
12
24
Options
1 = without diode
2 = electrostatic shield (pin 9)
3 = with diode (pin 2 + pin 6 -)
4 = electrostatic shield + diode
3570.1210.053 = 1 form A, 5 Volt Coil with diode
Part Number Example:
3570.1210.xxx
DIMENSIONS
0.271 (6.9)
MAX
0.271 (6.9)
MAX
0.338
(8.6)
0.767 (19.5) MAX
0.3
(7.62)
0.271 (6.9)
MAX
0.021 (0.53)
0.01
(0.26)
0.1 (2.54)
0.6 (15.24)
0.02
(0.51)
0.125 ± 0.019
(3.175 ± 0.475)
Drawings not to scale.
All dimensions in inches (mm) nominal.
As part of the company policy of continued product improvement, specifications may change without notice. Our sales office will be pleased to help you with the latest information on this product range and
the details of our full design and manufacturing service. All products are supplied to our standard conditions of sale unless otherwise agreed in writing.
Phone: (1) 973 777 6900
www.comus-intl.com
Fax: (1) 973 777 8405
Belgium: + 32 (0)12 390400 - Comus Europe Ltd (Assemtech) UK: +44 (0) 1255 862236 - Germany: +49 (0)911 923 15 943 - Netherlands: +31(0)45 54 39 345 - India: +(91) (44) 43219090
©2015 Copyright Comus International, 454 Allwood Road, Clifton NJ 07012, USA
1 / 2015
An ISO 9001 Certified Company
Relays
Part Number: 3570 3572 3563 Series
General Purpose DIP Reed Relays
Product Data Sheet
COIL DATA-STANDARD TYPE 1 FORM A (at 20˚C)
NOMINAL COIL
VOLTAGE (VDC)
NOMINAL COIL
RESISTANCE
±10%
(Ω)
MAX OPERATE
VOLTAGE (VDC)
MIN RELEASE
VOLTAGE (VDC)
3570.1210
MAX COIL
VOLTAGE (VDC)
5
12
24
NOMINAL COIL
VOLTAGE (VDC)
500
1000
2150
NOMINAL COIL
RESISTANCE
±10%
(Ω)
3.75
9
18
MAX OPERATE
VOLTAGE (VDC)
0.6
1
2
MIN RELEASE
VOLTAGE (VDC)
7
16
32
COIL DATA-STANDARD TYPE 2 FORM A (at 20˚C)
5
12
24
NOMINAL COIL
VOLTAGE (VDC)
3572.1220
MAX COIL
VOLTAGE (VDC)
140
500
2150
NOMINAL COIL
RESISTANCE
±10%
(Ω)
3.75
9
18
MAX OPERATE
VOLTAGE (VDC)
0.6
1
2
MIN RELEASE
VOLTAGE (VDC)
7
16
32
COIL DATA-STANDARD TYPE 1 FORM C (at 20˚C)
5
12
24
Contact Form
Max Switching Power
Max Switching Voltage
Max Switching Current
Max Carry Current
Contact Resistance (Initial)
Operate Time - including bounce (Typical)
Release Time (Typical)
Insulation Resistance @ 100V, 20°C, 40% RH (MIN)
Dielectric Strength (MIN)
Capacitance Between Open Contacts (Typical)
Vibration
Shock Resistance
Operating Temperature
Storage Temperature
Life Expectancy at Specified Load (Typical)
10 W
150 VDC
0.5 A
1A
200
500
2150
3.75
9
18
0.6
1
2
1 / 2 Form A
5W
100 VDC
0.4 A
0.5 A
Max 200 mΩ
1 ms
1.5 ms
10
9
Ω
3563.1231
MAX COIL
VOLTAGE (VDC)
7
16
32
1 Form C
CONTACT RATING
SPECIFICATION
Max 150 mΩ
0.5 ms
0.5 ms
10
10
Ω
Between Open Contacts 200 VDC / peak AC
Between Coil to Contacts & All Other Pins 1500 VDC / peak AC
0.5 pF
20G
50G
-20° +85°C
-40° +100°C
250 x10
6
ops (1 VDC, 10mA)
1.5 pF
20G
50G
-20° +85°C
-40° +100°C
100 x10
6
ops (1 VDC, 10mA)
As part of the company policy of continued product improvement, specifications may change without notice. Our sales office will be pleased to help you with the latest information on this product range and
the details of our full design and manufacturing service. All products are supplied to our standard conditions of sale unless otherwise agreed in writing.
Phone: (1) 973 777 6900
www.comus-intl.com
Fax: (1) 973 777 8405
Belgium: + 32 (0)12 390400 - Comus Europe Ltd (Assemtech) UK: +44 (0) 1255 862236 - Germany: +49 (0)911 923 15 943 - Netherlands: +31(0)45 54 39 345 - India: +(91) (44) 43219090
©2015 Copyright Comus International, 454 Allwood Road, Clifton NJ 07012, USA
1 / 2015
An ISO 9001 Certified Company
