SUNON
SPECIFICATION FOR APPROVAL
CUSTOMER
MOTOR TYPE
DESCRIPTION
DIMENSIONS
MODEL
SUNON SPEC. NO.
CUSTOMER
APPROVAL NO.
APPROVED BY
CUSTOMER
(AUTHORIZED)
: Sunon Inc./Arris
:
: MagLev Motor Fan
: 50X50X15 mm
: HA50151V4-1Q01U-Q99
: D05061480G-01
: 3660HQ/AREC13362
:
SPEC.NO
DRAWN
D05061480G-01
11.22.2016
1
E11600222
Vickey
2/20
ISSUE DATE
CHECKED
YAN
APPROVED
Sunny
EDITION
E.SPEC
REVISION DATE
02.20.2017
建準電機工業股½有限公司
SUNONWEALTH ELECTRIC MACHINE INDUSTRY CO., LTD.
NO. 30, LN. 296, XINYA RD., QIANZHEN DIST.,
TEL:886-7-8135888
KAOHSIUNG CITY 80673, TAIWAN (R.O.C)
FAX:886-7-8230505/8230606/8231010
URL:http://www.sunon.com
E-mail: sunon@email.sunon.com.tw
建 準 電 機
SUNONWEALTH
Page 1 of 16
D.C.C.
2017.02
21
I. MODEL NUMBERING SYSTEM
HA
Series Code
50
15
1
Voltage
0: 5VDC
1: 12VDC
2: 24VDC
3: 36VDC
4: 48VDC
V
4
- 1Q01U -
Speed
X:Super High
1: High
2: Medium
3: Low
4: Extra Low
Q99
Function Code
Customer Code
Bearing
V: Vapo
B: 2 Ball
Size
Thickness
O: 1 Ball
S: Sleeve
編碼
01~09
10~19
20~29
30~39
40~49
50~59
60~69
70~79
80~89
90~99
尺寸(mm)
01~09
10~19
20~29
30~39
40~49
50~59
60~69
70~79
80~89
90~99
編碼
A0~A9
B0~B9
C0~C9
D0~D9
E0~E9
F0~F9
G0~G9
H0~H9
I0~I9
J0~J9
尺寸(mm)
100~109
110~119
120~129
130~139
140~149
150~159
160~169
170~179
180~189
190~199
編碼
K0~K9
L0~L9
M0~M9
N0~N9
P0~P9
Q0~Q9
R0~R9
S0~S9
T0~T9
U0~U9
尺寸(mm)
200~209
210~219
220~229
230~239
240~249
250~259
260~269
270~279
280~289
290~299
編碼
V0~V9
W0~W9
X0~X9
Y0~Y9
Z0~Z9
尺寸(mm)
300~309
310~319
320~329
330~339
340~349
建 準 電 機
SUNONWEALTH
Page 2 of 16
D.C.C.
2017.02
21
II. SPECIFICATION
1. MECHANICAL CHARACTERISTIC
MOTOR DESIGN
BEARING SYSTEM
DIMENSIONS
MATERIALS OF FRAME
MATERIALS OF FAN BLADE
DIRECTION OF ROTATION
MOUNTING HOLES
WEIGHT
Single phase, 4-poles Brushless DC motor
Vapo bearing system
See Page 6
Thermoplastic PBT of UL 94V-0
Thermoplastic PBT of UL 94V-0
Counter-clockwise viewed from front of fan blade
Diameter 4.3 mm in 4 holes
33 g
2. ELECTRIC CHARACTERISTIC
RATED VOLTAGE
RATED CURRENT
RATED POWER CONSUMPTION
OPERATING VOLTAGE RANGE
STARTING VOLTAGE
OPERATING TEMPERATURE RANGE
STORAGE TEMPERATURE RANGE
12 VDC
20 mA
0.24 WATTS
10.2~13.8 VDC
10.2 VDC (25 deg. C POWER ON/OFF)
-10 to + 70 deg. C
-40 to + 70 deg. C
建 準 電 機
SUNONWEALTH
Page 3 of 16
D.C.C.
2017.02
21
3. PERFORMANCE CHARACTERISTIC
RATED SPEED
AIR FLOW
STATIC PRESSURE
ACOUSTIC NOISE
AIR FLOW V.S. PRESSURE
INSULATION CLASS
INSULATION RESISTANCE
PLASTIC HOUSING
3200 RPM ± 15% at rated voltage
7.7 CFM
0.07 Inch-H
2
O
15.4 dB(A)
See Page 5
UL Class A
10M ohm at 500 VDC between internal stator and
Lead wire (+)
DIELECTRIC STRENGTH
Applied AC 500 V for one minute or AC 600 V for 2
Seconds between housing and lead wire (+)
60,000 Hours at 40 deg. C, 65% humidity, 90% CL.
Automatic Restart
Note: In a situation where the fan is locked by an external
force while the electricity is on, an increase in coil
temperature will be prevented by temporarily turning off the
electrical power to the motor. The fan will automatically
restart when the locked rotor condition is released.
LIFE EXPECTANCY
PROTECTION
Polarity Protection
4. SAFETY
SAFETY
NO.
UL
E77551
CUR
E77551
TUV
CE
建 準 電 機
SUNONWEALTH
Page 4 of 16
D.C.C.
2017.02
21
MODEL : HA50151V4-1Q01U-Q99
PERFORMANCE CURVES
m
3
/min
0
0.08
0.055
0.11
0.165
0.22
2
Static Pressure (Inch-H
2
O)
0.06
1.5
0.04
1
0.02
0.5
0
0
2
4
6
8
0
Air Flow-CFM
mm-H
2
O
