Fuse modular terminal block - UK 5-HESI N - 3000539
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
Fuse modular terminal block, fuse type: Glass / ceramics / ..., number of positions: 1, connection method:
Screw connection, cross section: 0.2 mm²- 6 mm², AWG: 24 - 10, nominal current: 6.3 A, nom. voltage: 500 V,
width: 8.2 mm, fuse type: G / 5 x 20, mounting type: NS 35/7,5, NS 35/15, NS 32, color: black
Key Commercial Data
Packing unit
GTIN
GTIN
4046356676045
50 pc
Technical data
General
Note
Number of levels
Number of connections
Nominal cross section
Color
Insulating material
Flammability rating according to UL 94
Maximum power dissipation for nominal condition
Fuse
Fuse type
Rated surge voltage
Degree of pollution
Overvoltage category
Insulating material group
Maximum power dissipation
For terminal marking, please use marking material with 8.2 mm pitch.
For lever marking, please use marking material with 6.2 mm pitch.
1
2
4 mm²
black
PA
V0
1.6 W
G / 5 x 20
Glass / ceramics / ...
6 kV
3
III
I
max. 1.6 W (With single arrangement of the fuse terminal block in the
event of overload)
10/27/2018 Page 1 / 5
https://www.phoenixcontact.com/pi/products/3000539
Fuse modular terminal block - UK 5-HESI N - 3000539
Technical data
General
max. 1.6 W (With interconnected arrangement of several fuse terminal
blocks in the event of overload)
max. 4 W (With single arrangement of the fuse terminal block in the
event of a short-circuit)
max. 2.5 W (With interconnected arrangement of several fuse terminal
blocks in the event of a short-circuit)
Connection in acc. with standard
Maximum load current
Nominal current I
N
Nominal voltage U
N
Open side panel
Number of positions
Shock protection test specification
Back of the hand protection
Finger protection
Oscillation, broadband noise test result
Test specification, oscillation, broadband noise
Test spectrum
Test frequency
ASD level
Acceleration
Test duration per axis
Test directions
Shock test result
Test specification, shock test
Shock form
Acceleration
Shock duration
Number of shocks per direction
Test directions
Relative insulation material temperature index (Elec., UL 746 B)
Temperature index of insulation material (DIN EN 60216-1 (VDE
0304-21))
Static insulating material application in cold
IEC 60947-7-3
6.3 A (the current is determined by the fuse used)
6.3 A
500 V (As a fuse terminal block)
Yes
1
DIN EN 50274 (VDE 0660-514):2002-11
guaranteed
guaranteed
Test passed
DIN EN 50155 (VDE 0115-200):2008-03
Service life test category 1, class B, body mounted
f
1
= 5 Hz to f
2
= 150 Hz
1.857 (m/s ) /Hz
0,8 g
5h
X-, Y- and Z-axis
Test passed
DIN EN 50155 (VDE 0115-200):2008-03
Half-sine
5g
30 ms
3
X-, Y- and Z-axis (pos. and neg.)
130 °C
130 °C
-60 °C
2 2
Dimensions
Width
Length
Height NS 35/7,5
Height NS 35/15
Height NS 32
8.2 mm
58 mm
50 mm
57.6 mm
55 mm
Connection data
10/27/2018 Page 2 / 5
https://www.phoenixcontact.com/pi/products/3000539
Fuse modular terminal block - UK 5-HESI N - 3000539
Technical data
Connection data
Conductor cross section solid min.
Conductor cross section solid max.
Conductor cross section flexible min.
Conductor cross section flexible max.
Conductor cross section AWG min.
Conductor cross section AWG max.
Conductor cross section flexible, with ferrule without plastic sleeve min.
Conductor cross section flexible, with ferrule with plastic sleeve min.
Conductor cross section flexible, with ferrule with plastic sleeve max.
Cross section with insertion bridge, solid max.
Cross section with insertion bridge, stranded max.
2 conductors with same cross section, solid min.
2 conductors with same cross section, solid max.
2 conductors with same cross section, stranded min.
2 conductors with same cross section, stranded max.
2 conductors with same cross section, stranded, ferrules without plastic
sleeve, min.
2 conductors with same cross section, stranded, ferrules without plastic
sleeve, max.
2 conductors with same cross section, stranded, TWIN ferrules with
plastic sleeve, min.
2 conductors with same cross section, stranded, TWIN ferrules with
plastic sleeve, max.
Cross section with insertion bridge, solid max.
Cross section with insertion bridge, stranded max.
Connection method
Stripping length
Internal cylindrical gage
Screw thread
Tightening torque, min
Tightening torque max
0.2 mm²
6 mm²
0.2 mm²
4 mm²
24
10
0.25 mm²
0.25 mm²
2.5 mm²
4 mm²
4 mm²
0.2 mm²
1.5 mm²
0.2 mm²
1.5 mm²
0.25 mm²
1.5 mm²
0.5 mm²
2.5 mm²
4 mm²
4 mm²
Screw connection
8 mm
A4
M3
0.6 Nm
0.8 Nm
Conductor cross section flexible, with ferrule without plastic sleeve max. 4 mm²
Standards and Regulations
Connection in acc. with standard
Flammability rating according to UL 94
IEC 60947-7-3
V0
Environmental Product Compliance
REACh SVHC
China RoHS
Lead 7439-92-1
Environmentally Friendly Use Period = 50
For details about hazardous substances go to tab “Downloads”,
Category “Manufacturer's declaration”
10/27/2018 Page 3 / 5
https://www.phoenixcontact.com/pi/products/3000539
Fuse modular terminal block - UK 5-HESI N - 3000539
Drawings
Circuit diagram
Approvals
Approvals
Approvals
UL Recognized / cUL Recognized / EAC / cULus Recognized
Ex Approvals
Approval details
UL Recognized
Nominal voltage UN
Nominal current IN
mm²/AWG/kcmil
B
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm
C
600 V
16 A
26-10
FILE E 60425
600 V
16 A
26-10
cUL Recognized
Nominal voltage UN
Nominal current IN
mm²/AWG/kcmil
B
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm
C
600 V
16 A
26-10
FILE E 60425
600 V
16 A
26-10
EAC
EAC-Zulassung
cULus Recognized
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm
