General Chip Inductor
CIL Series- CIL10 (1608/ EIA 0603)
CIL Series has ferrite body and 100% Ag internal conductor.
Also, the CIL series Inductors have excellent Q characteristics
and free of cross talk.
FEATURES
Magnetic shielding eliminates crosstalk, thus permitting higher mounting density.
Excellent solderability and high heat resistance for either flow or reflow soldering.
Monolithic structure for high reliability
APPLICATION
Resonance circuits, PLL circuits, Noise suppression, etc.
SPECIFICATION
Operating temperature range –40 to +85°C
Storage temperature range
–10 to +40°C
PRODUCT IDENTIFICATION
CI
(1)
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
L
(2)
10
(3)
N
(4)
47N
(5)
K
(6)
N
(7)
C
(8)
Chip Inductor
L:Ordinary type
Dimension
Material Code (N,J,Y,S)
Inductance(47N:0.047uH,2R2:2.2uH)
Tolerance(K:±10%, M:±20%)
Thickness option(N:Standard, A:Thinner than standard, B:Thicker than standard)
Packaging(C:paper tape, E:embossed tape)
CIL10J3R3
CIL10J3R9
CIL10J4R7
CIL10Y5R6
CIL10Y6R8
CIL10Y8R2
CIL10Y100
CIL10Y120
CIL10S150
CIL10S180
CIL10S220
CIL10S270
CIL10S330
0.80±0.15
0.80±0.15
0.80±0.15
0.80±0.15
0.80±0.15
0.80±0.15
0.80±0.15
0.80±0.15
0.80±0.15
0.80±0.15
0.80±0.15
0.80±0.15
0.80±0.15
3.3±20%,10%
3.9±20%,10%
4.7±20%,10%
5.6±20%,10%
6.8±20%,10%
8.2±20%,10%
10.0±20%,10%
12.0±20%,10%
15.0±20%,10%
18.0±20%,10%
22.0±20%,10%
27.0±20%,10%
33.0±20%,10%
35
35
35
35
35
35
35
35
20
20
20
20
20
10
10
10
4
4
4
2
2
1
1
1
1
0.4
38
36
33
22
20
18
17
15
14
13
11
10
9
1.55
1.70
2.10
1.55
1.70
2.10
2.55
2.75
1.70
1.85
2.10
2.75
2.95
15
15
15
5
5
5
5
5
1
1
1
1
1
4.Characteristics data
(1) Impedance Characteristics
(2) Q Characteristics
(3) DC Bias Characteristics
(4) Temperature Characteristics
■
NOTICE :All specifications are subject to change without previous notice. Please contact with
product representatives or engineers to check specifications.
