3312 SL001 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Wire/cable> 3312 SL001

3312 SL001: DescriptionCABLE 12COND 28AWG SHLD 1000'; CategoryWire/cable; File Size221KB，3 Pages; ManufacturerAlpha Wire; Websitehttp://www.alphawire.com/zh-CN/; Environmental Compliance

Download Datasheet Parametric View All

3312 SL001 Overview

CABLE 12COND 28AWG SHLD 1000'

3312 SL001 Parametric

Parameter Name	Attribute value
Cable type	multi-core
Number of conductors	12
Wire gauge	28 AWG
Number of wire strands	7/36
conductor material	Copper, tin plated
Sheath (insulation) material	Polyvinyl chloride (PVC)
Sheath (insulation) diameter	0.206"（5.23mm）
Shield type	braided wire
length	1000.0'（304.8m）
Casing color	slate color
grade	-
characteristic	-
Voltage	600V
Operating temperature	-55°C ~ 105°C
use	communication, control
Sheath (insulation) thickness	0.0180"（0.457mm）
conductor insulation	Polyvinyl chloride (PVC)
shielding material	Copper, tin plated
Shielding range	90%

Preview

Download Datasheet

View All

Alpha Wire | 711 Lidgerwood Avenue, Elizabeth, NJ 07207

Tel: 1-800-52 ALPHA (25742), Web: www.alphawire.com

Customer Specification

PART NO. 3312

Construction

Diameters (In)

1) Component 1

a) Conductor

b) Insulation

(1) Color Code

Cond

2) Cable Assembly

a) Twists:

b) Core Wrap

3) Shield

4) Jacket

a) Color(s)

Color

BLACK

WHITE

RED

GREEN

12 X 1 COND

28 (7/36) AWG TC

0.010" Wall, Nom. PVC

Alpha Wire Color Code F

Cond

12 Components Cabled

6.0 Twists/foot (min)

Clear Mylar Tape, 25% Overlap, Min.

TC BRAID Shield,90% Coverage, Min.

0.018" Wall, Nom.,PVC

SLATE

ALPHA WIRE-* P/N 3312

CE ROHS

* = Factory Code

0.206 (0.218 Max.)

Color

ORANGE

BLUE

WHITE/BLACK

RED/BLACK

Cond

Color

GREEN/BLACK

ORANGE/BLACK

BLUE/BLACK

BLACK/WHITE

0.015

0.035

b) Print

Applicable Specifications

1) Military

a) Component 1

2) CE:

MIL-W-16878/Type B

EU Low Voltage Directive 2006/95/EC

105°C / 600 VRMS

Environmental

1) CE: EU Directive 2011/65/EU(RoHS2):

This product complies with European Directive 2011/65/EU (RoHS Directive) of the European

Parliament and of the Council of 8 June 2011. No Exemptions are required for RoHS

Compliance on this item. Consult Alpha Wire's web site for RoHS C of C.

2) REACH Regulation (EC 1907/2006):

This product does not contain Substances of Very High Concern (SVHC) listed on the European

Union's REACH candidate list in excess of 0.1% mass of the item. For up-to-date information,

please see Alpha's REACH SVHC Declaration.

3) California Proposition 65:

The outer surface materials used in the manufacture of this part meet the requirements of

California Proposition 65.

Properties

Physical & Mechanical Properties

1) Temperature Range

2) Bend Radius

3) Pull Tension

Electrical Properties

1) Voltage Rating

2) Capacitance

3) Ground Capacitance

4) Inductance

5) Conductor DCR

6) OA Shield DCR

-55 to 105°C

10X Cable Diameter

21.8 Lbs, Maximum

(For Engineering purposes only)

600 V

RMS

35 pf/ft @1 kHz, Nominal Conductor to Conductor

63 pf/ft @1 kHz, Nominal

0.22 µH/ft, Nominal

66 Ω/1000ft @20°C, Nominal

3.8 Ω/1000ft @20°C, Nominal

Other

Packaging

a) 1000 FT

b) 100 FT

Flange x Traverse x Barrel (inches)

12 x 10 x 5 Continuous length

6.5 x 4 x 2.5 Continuous length

[Spool dimensions may vary slightly]

www.alphawire.com

Alpha Wire | 711 Lidgerwood Avenue, Elizabeth, NJ 07207

Tel: 1-800-52 ALPHA (25742)

Although Alpha Wire (“Alpha”) makes every reasonable effort to ensure their accuracy at the time of publication, information and specifications

described herein are subject to errors or omissions and to changes without notice, and the listing of such information and specifications does not

ensure product availability.

Alpha provides the information and specifications herein on an “AS IS” basis, with no representations or warranties, whether express, statutory or

implied. In no event will Alpha be liable for any damages (including consequential, indirect, incidental, special, punitive, or exemplary) whatsoever,

even if Alpha had been advised of the possibility of such damages, whether in an action under contract, negligence or any other theory, arising out

of or in connection with the use, or inability to use, the information or specifications described herein.

ALPHA WIRE - CONFIDENTIAL AND PROPRIETARY

Notice to persons receiving this document and/or technical information. This document is confidential and is the exclusive property of ALPHA WIRE,

and is merely on loan and subject to recall by ALPHA WIRE at any time. By taking possession of this document, the recipient acknowledges and

agrees that this document cannot be used in any manner adverse to the interests of ALPHA WIRE, and that no portion of this document may be

copied or otherwise reproduced without the prior written consent of ALPHA WIRE. In the case of conflicting contractual provisions, this notice shall

EU/China ROHS CERTIFICATE OF COMPLIANCE

To Whom It May Concern:

Alpha Wire Part Number: 3312

3312 , RoHS-Compliant Commencing With 7/1/2005 Production

Note: all colors and put-ups

This document certifies that the Alpha part number cited above is manufactured in accordance with Directive 2011/65/EU of the European

Parliament, better known as the RoHS Directive (commonly known as RoHS 2), with regards to restrictions of the use of certain hazardous

substances used in the manufacture of electrical and electronic equipment. This certification extends to amending Directive 2015/863/EU which

expanded the list of restricted substances to 10 items (commonly known as RoHS 3) The reader is referred to these Directives for the specific

definitions and extents of the Directives. No Exemptions are required for RoHS Compliance on this item. Additionally, Alpha certifies that the listed

part number is in compliance with China RoHS “Marking for Control of Pollution by Electronic Information Products” standard SJ/T 11364-2014.

Substance

Lead

Mercury

Cadmium

Hexavalent Chromium

Polybrominated Biphenyls (PBB)

Polybrominated Diphenyl Ethers (PBDE) ,

Including Deca-BDE

Bis(2-ethylhexyl) phthalate (DEHP)

Butyl benzyl phthalate (BBP)

Dibutyl phthalate (DBP)

Diisobutyl phthalate (DIBP)

0.1% by weight (1000 ppm)

Maximum Control Value

0.1% by weight (1000 ppm)

0.01% by weight (100 ppm)

0.1% by weight (1000 ppm )

0.1% by weight (1000 ppm)

The information provided in this document and disclosure is correct to the best of Alpha Wire's knowledge, information and belief at the date of its

release. The information provided is designed only as a general guide for the safe handling, storage, and any other operation of the product itself or

the one that it will become part of. The intent of this document is not to be considered a warranty or quality specification. Regulatory information is

for guidance purposes only. Product users are responsible for determining the applicability of legislation and regulations based on their individual

usage of the product.

Authorized Signatory for the Alpha Wire:

Dave Watson, Director of Engineering & QA

Alpha Wire

711 Lidgerwood Ave.

Elizabeth, NJ 07207

Tel: 1-908-925-8000

10/26/2018
