CXB1310-0000-000F0ZJ435H datasheet, PDF

Datasheet> All Categories > LED optoelectronic/LED> CXB1310-0000-000F0ZJ435H

CXB1310-0000-000F0ZJ435H: DescriptionXLAMP CXA GEN2 LIGHT EMITTING DI; CategoryLED optoelectronic/LED; File Size2MB，25 Pages; ManufacturerCree; Websitehttp://www.cree.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

CXB1310-0000-000F0ZJ435H Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	CXB1310-0000-000F0ZJ435H	-	-	View	Buy Now

CXB1310-0000-000F0ZJ435H Overview

XLAMP CXA GEN2 LIGHT EMITTING DI

CXB1310-0000-000F0ZJ435H Parametric

Parameter Name	Attribute value
type	Chip on Board (COB)
color	white, warm color
CCT（K）	3500K 2nd order MacAdam ellipse
wavelength	-
Configuration	Square
Flux@Current/Temperature-Test	1239 lm (standard)
Current - Test	700mA
Temperature - Test	85°C
Voltage - Forward (Vf) (Typical)	18V
Lumens/Watt at different test currents	98 lm/W
Current - maximum	1.4 A
CRI (high color rendering index)	95
perspective	115°
characteristic	-
size/dimensions	13.35mm length x 13.35mm width
high	1.55mm
Luminous surface (LES)	6.00mm diameter
Lens type	flat

Preview

Download Datasheet

View All

CLD-DS141 Rev 3

Product family data sheet

Cree

XLamp

CXB1310 LED

ProDuCt DEsCriPtion

Cree CXB1310 High Density (HD) LeD

arrays are the next generation of high

lumen density LeD arrays. Incorporating

elements of Cree’s SC5 Technology™

Platform, the CXB1310 HD LeD arrays

deliver the most lumens in the industry

for their light-emitting surface (LeS)

size,

enabling

radically

new

and

differentiated LeD lighting form factors

for applications like tracks, lamps

and downlights. The industry-leading

performance of the CXB1310 HD LeD

arrays allows lighting manufacturers

develop

compact,

cutting-edge

products that deliver high performance

and energy savings.

The

CX Family LeD Design Guide

provides basic information on the

requirements to use the CXB1310 HD

LeD array successfully in luminaire

designs.

fEaturEs

•

Available in 5-step easyWhite

bins

at 4000 K, 5000 K, 5700 K & 6500 K,

3‑step EasyWhite bins at 2200 K,

2700 K, 3000 K, 3500 K, 4000 K &

5000 K and 2‑step EasyWhite bins

at 2700 K, 3000 K, 3500 K & 4000 K

CCT

• Available in 70‑, 80‑, 90‑ and

95‑minimum CRI options

•

Premium Color 2- and 3-step binning

Forward voltage options: 18‑V class

& 36‑V class

• 85 °C binning and characterization

• Maximum drive current: 1400 mA

(18 V), 700mA (36 V)

• 115° viewing angle, uniform

chromaticity profile

•

Top-side solder connections

•

Thermocouple attach point

• NEMA SSL‑3 2011 standard flux bins

•

RoHS and ReACh compliant

•

recognized component

(E349212)

taBLE of ContEnts

Characteristics ............................................2

Operating Limits ..........................................3

Flux Characteristics, easyWhite

Order

Codes and Bins ‑ 18 V

.................................4

Flux Characteristics, Premium Color

Order Codes and Bins ‑ 18 V

......................6

Flux Characteristics, easyWhite

Order

Codes and Bins ‑ 36 V

.................................7

Flux Characteristics, Premium Color

Order Codes and Bins ‑ 36 V

......................9

Relative Spectral Power Distribution,

easyWhite

.............................................. 10

Relative Spectral Power Distribution,

Premium Color ......................................... 11

electrical Characteristics ......................... 12

Relative Luminous Flux ............................ 13

Typical Spatial Distribution...................... 15

Performance Groups - Brightness .......... 15

Performance Groups - Chromaticity .......

Premium Color Performance Groups -

Chromaticity .............................................

Cree easyWhite

Bins Plotted on the

1931 CIE Color Space

..............................

Cree Premium Color Bins Plotted on the

1931 CIE Color Space

..............................

Bin and Order Code Formats ................... 21

Mechanical Dimensions .......................... 21

Thermal Design ........................................ 22

Notes ........................................................ 24

Packaging ................................................. 25

WWW.CREE.Com/XLAmp

, XLamp

and

EasyWhite

are registered trademarks and SC5 Technology™ and the Cree logo are trademarks of Cree, Inc. UL

and the UR logo are registered

trademarks of UL LLC.

Cree, Inc.

4600 Silicon Drive

Durham, NC 27703

USA Tel: +1.919.313.5300

CXB1310-0000-000F0ZJ435H Related Products

	CXB1310-0000-000F0ZJ435H	CXB1310-0000-000F0UK231Q	CXB1310-0000-000F0HM2L7B	CXB1310-0000-000F0ZJ227H	CXB1310-0000-000F0ZJ2L7C	CXB1310-0000-000F0ZJ430H	CXB1310-0000-000F0ZK2L5A	CXB1310-0000-000N0ZJ227H	CXB1310-0000-000N0ZJ430H
Description	XLAMP CXA GEN2 LIGHT EMITTING DI	XLAMP CXA GEN2 LIGHT EMITTING DI	XLAMP CXA GEN2 LIGHT EMITTING DI	Single Color LED,	XLAMP CXA GEN2 LIGHT EMITTING DI	XLAMP CXA GEN2 LIGHT EMITTING DI	XLAMP CXA GEN2 LIGHT EMITTING DI	Single Color LED,	XLAMP CXA GEN2 LIGHT EMITTING DI
type	Chip on Board (COB)	Chip on Board (COB)	Chip on Board (COB)	-	Chip on Board (COB)	-	Chip on Board (COB)	-	-
color	white, warm color	white, warm color	white, warm color	-	white, warm color	-	white, natural	-	-
CCT（K）	3500K 2nd order MacAdam ellipse	3100K 3rd order MacAdam ellipse	3000K 2nd order MacAdam ellipse	-	3000K 2nd order MacAdam ellipse	-	4000K 2nd order MacAdam ellipse	-	-
Configuration	Square	Square	Square	-	Square	-	Square	-	-
Flux@Current/Temperature-Test	1239 lm (standard)	1330 lm (standard)	1529 lm (standard)	-	1100 lm (standard)	-	1286 lm (standard)	-	-
Current - Test	700mA	700mA	700mA	-	700mA	-	700mA	-	-
Temperature - Test	85°C	85°C	85°C	-	85°C	-	85°C	-	-
Voltage - Forward (Vf) (Typical)	18V	18V	18V	-	18V	-	18V	-	-
Lumens/Watt at different test currents	98 lm/W	106 lm/W	121 lm/W	-	87 lm/W	-	102 lm/W	-	-
Current - maximum	1.4 A	1.4 A	1.4 A	-	1.4 A	-	1.4 A	-	-
CRI (high color rendering index)	95	90	80	-	95	-	95	-	-
perspective	115°	115°	115°	-	115°	-	115°	-	-
size/dimensions	13.35mm length x 13.35mm width	13.35mm length x 13.35mm width	13.35mm length x 13.35mm width	-	13.35mm length x 13.35mm width	-	13.35mm length x 13.35mm width	-	-
high	1.55mm	1.55mm	1.55mm	-	1.55mm	-	1.55mm	-	-
Luminous surface (LES)	6.00mm diameter	6.00mm diameter	6.00mm diameter	-	6.00mm diameter	-	6.00mm diameter	-	-
Lens type	flat	flat	flat	-	flat	-	flat	-	-
