SMBJ10CHE3/52 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> SMBJ10CHE3/52

SMBJ10CHE3/52: DescriptionTVS DIODE 10V 18.8V DO214AA; CategoryDiscrete semiconductor diode; File Size110KB，5 Pages; ManufacturerVishay; Websitehttp://www.vishay.com; Environmental Compliance

Download Datasheet Parametric View All

SMBJ10CHE3/52 Overview

TVS DIODE 10V 18.8V DO214AA

SMBJ10CHE3/52 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Vishay
Reach Compliance Code	unknown
ECCN code	EAR99
Breakdown voltage nominal value	12.35 V
Maximum clamping voltage	18.8 V
Diode type	TRANS VOLTAGE SUPPRESSOR DIODE
polarity	BIDIRECTIONAL
Maximum repetitive peak reverse voltage	10 V
surface mount	YES

Preview

Download Datasheet

View All

SMBJ5.0A thru SMBJ188A

www.vishay.com

Vishay General Semiconductor

Surface Mount T

RANS

ORB®

Transient Voltage Suppressors

FEATURES

•

Low profile package

Ideal for automated placement

Glass passivated chip junction

Available in uni-directional and bi-directional

Available

600 W peak pulse power capability with a

10/1000 μs waveform, repetitive rate (duty

cycle): 0.01 %

Excellent clamping capability

Very fast response time

Low incremental surge resistance

Meets MSL level 1, per J-STD-020, LF maximum peak

of 260 °C

AEC-Q101 qualified available

- Automotive ordering code: base P/NHE3 or P/NHM3

Material categorization: for definitions of compliance

please see

www.vishay.com/doc?99912

SMB (DO-214AA)

•

PRIMARY CHARACTERISTICS

(bi-directional)

(uni-directional)

PPM

FSM

(uni-directional only)

max.

Polarity

Package

6.4 V to 231 V

5.0 V to 188 V

600 W

100 A

150 °C

Uni-directional, bi-directional

SMB (DO-214AA)

TYPICAL APPLICATIONS

Use in sensitive electronics protection against voltage

transients induced by inductive load switching and lighting

on ICs, MOSFET, signal lines of sensor units for consumer,

computer, industrial, and telecommunication.

MECHANICAL DATA

Case:

SMB (DO-214AA)

Molding compound meets UL 94 V-0 flammability rating

Base P/N-E3 - RoHS-compliant, commercial grade

Base P/N-M3 - halogen-free, RoHS-compliant, commercial

grade

Base P/NHE3 - RoHS-compliant and AEC-Q101 qualified

Base P/NHM3 - halogen-free, RoHS-compliant, and

AEC-Q101 qualified

Terminals:

matte tin plated leads, solderable per

J-STD-002 and JESD 22-B102

E3, M3, HE3, and HM3 suffix meets JESD 201 class 2

whisker test

Polarity:

for uni-directional types the band denotes cathode

end, no marking on bi-directional types

DEVICES FOR BI-DIRECTION APPLICATIONS

For bi-directional devices use CA suffix (e.g. SMBJ10CA).

Electrical characteristics apply in both directions.

MAXIMUM RATINGS

= 25 °C unless otherwise noted)

PARAMETER

Peak pulse power dissipation with a 10/1000 μs waveform

(1)(2)

(fig. 1)

Peak pulse current with a 10/1000 μs waveform

(1)

Peak forward surge current 8.3 ms single half sine-wave uni-directional only

(2)

Operating junction and storage temperature range

Notes

(1)

Non-repetitive current pulse, per fig. 3 and derated above T = 25 °C per fig. 2

(2)

Mounted on 0.2" x 0.2" (5.0 mm x 5.0 mm) copper pads to each terminal

SYMBOL

PPM

FSM

, T

STG

VALUE

600

See next table

100

-55 to +150

UNIT

°C

Revision: 14-Jul-17

Document Number: 88392

For technical questions within your region:

DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com

THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT

ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT

www.vishay.com/doc?91000
