AVS477M06F24B-F

Description
CAP ALUM 470UF 20% 6.3V SMD
CategoryPassive components
File Size456KB,6 Pages
ManufacturerCornell Dubilier
Environmental Compliance
Download Datasheet Parametric View All

AVS477M06F24B-F Overview

CAP ALUM 470UF 20% 6.3V SMD

AVS477M06F24B-F Parametric

Parameter NameAttribute value
capacitance470µF
Tolerance±20%
Voltage - Rated6.3V
ESR (equivalent series resistance)1.2 ohms @ 120Hz
Service life at different temperatures2000 hours at 85°C
Operating temperature-40°C ~ 85°C
polarizationpolarization
gradeAEC-Q200
applicationAutomotive, bypass, decoupling
Ripple current @ low frequency380mA @ 120Hz
Ripple current @ high frequency646mA @ 10kHz
lead spacing-
size/dimensions0.315" diameter (8.00mm)
Height - Installation (maximum)0.402"(10.20mm)
Surface mount pad dimensions0.327" long x 0.327" wide (8.30mm x 8.30mm)
Installation typesurface mount
Package/casingRadial, Can - SMD
General Purpose Filtering, Bypassing, Power Supply Decoupling
Type AVS
SMT Aluminum Electrolytic Capacitors - General Purpose, 85°C
Type AVS Capacitors are the best value for filter and bypass applications
not requiring wide temperature performance or high ripple current.
Their vertical cylindrical cases facilitate automatic mounting and reflow
soldering and Type AVS offers a significant cost savings over tantalum
capacitors.
Highlights
Specifications
+85°C, 2000 Hour Load Life
Capacitance Range: 0.1
µ
F to 1500
µ
F
Voltage Range: 4.0 Vdc to 100 Vdc
AEC-Q200 Compliant
-40°C to +85°C
4.0, 6.3, 10, 16, 25, 35, 63, & 100 Vdc
0.1
µF
to 1500
µF
See Ratings Table
±20% @ 120 Hz and +20°C
0.01 CV or 3
µA
@ +20°C, after two minutes (whichever is greater)
Frequency
50/60 Hz
0.7
120 Hz
1.0
1 kHz
1.3
10 kHz & up
1.7
Operating Temperature:
Rated voltage:
Capacitance:
D.F. (@ 20°C):
Capacitance Tolerance:
Leakage Current:
Ripple Current Multipliers:
Load Life:
2000 h @ 85°C
Capacitance: ±20%
DF: <200% of limit
DCL: <100% of limit
W.V. (Vdc)
-25°C / +20°C
-40°C / +20°C
4.0
7.0
15.0
6.3
4.0
8.0
10.0
3.0
6.0
Maximum Impedance Ratio @ 120 Hz
16.0
2.0
4.0
25.0
2.0
4.0
Shelf Life:
1000 h @ 85°C
Capacitance: ±20%
DF: <200% of limit
RoHS Compliant
DCL: <100% of limit
35.0
2.0
3.0
50.0
2.0
3.0
63.0
3.0
4.0
100.0
3.0
4.0
AVS Series Marking
Capacitance
(µF)
Outline Drawing
0.3 mm
K
A
I
D
H
P
I
220
vs
6 = 6.3 Vdc
16 = 16 Vdc
25 = 25 Vdc,
Series
Voltage
Case Dimensions
Case
Code
A
B
C
D
X
E
F
G
3
4
5
Lot No.
D ± 0.5
L
5.4 +.1,-.2
5.4 +.1,-.2
5.4 +.1,-.2
5.4 +.1,-.2
7.9 ±.3
6.2 ±.3
10.2 ±.3
10.2 ±.3
A ± 0.2
3.3
4.3
5.3
6.6
6.6
8.3
8.3
10.3
H (max)
4.5
5.5
6.5
7.8
7.8
9.5
10.0
12.0
I (ref)
1.5
1.8
2.2
2.6
2.6
3.4
3.4
3.5
L
W
W
0.55 ± 0.1
0.65 ± 0.1
0.65 ± 0.1
0.65 ± 0.1
0.65 ± 0.1
0.65 ± 0.1
0.90 ± 0.2
0.90 ± 0.2
P (ref)
0.6
1.0
1.5
1.8
1.8
2.2
3.1
4.6
K
0.35 + 0.15/-0.20
0.35 + 0.15/-0.20
0.35 + 0.15/-0.20
0.35 + 0.15/-0.20
0.35 + 0.15/-0.20
0.35 + 0.15/-0.20
0.70 ± 0.20
0.70 ± 0.20
6.3
6.3
8
8
10
CDE Cornell Dubilier • 1605 E. Rodney French Blvd. • New Bedford, MA 02744 • Phone: (508) 996-8561 • Fax: (508) 996-3830 • www.cde.com
