FFPF60SB60DS
March 2008
STEALTH
TM
II Rectifier
FFPF60SB60DS
Features
• High Speed Switching, t
rr
< 25ns @ I
F
= 4A
• High Reverse Voltage and High Reliability
• RoHS compliant
tm
4A, 600V STEALTH
TM
II Rectifier
The FFPF60SB60DS is STEALTH
TM
II rectifier with soft recovery
characteristics. It is silicon nitride passivated ion-implanted epi-
taxial planar construction.
This device is intended for use as freewheeling of boost diode in
switching power supplies and other power swithching applica-
tions. Their low stored charge and hyperfast soft recovery mini-
mize ringing and electrical noise in many power switching circuits
reducing power loss in the switching transistors.
Applications
• General Purpose
• Switching Mode Power Supply
• Boost Diode in continuous mode power factor corrections
• Power switching circuits
1 2 3
TO220F
1. Cathode 2. Anode(Cathode) 3. Anode
Absolute Maximum Ratings
T
C
= 25
o
C unless otherwise noted
Symbol
V
RRM
V
RWM
V
R
I
F(AV)
I
FSM
T
J
, T
STG
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
Average Rectified Forward Current
Non-repetitive Peak Surge Current
60Hz Single Half-Sine Wave
Operating and Storage Temperature Range
@ T
C
= 100 C
o
Parameter
Ratings
600
600
600
4
40
-65 to +150
Units
V
V
V
A
A
o
C
Thermal Characteristics
Symbol
R
θJC
Parameter
Maximum Thermal Resistance, Junction to Case
Ratings
8.7
Units
o
C/W
Package Marking and Ordering Information
Device Marking
FFPF60SB60DS
Device
FFPF60SB60DSTU
Package
TO220F
Reel Size
-
Tape Width
-
Quantity
50
©2008 Fairchild Semiconductor Corporation
FFPF60SB60DS Rev. A
1
www.fairchildsemi.com
FFPF60SB60DS
Typical Performance Characteristics
Figure 1. Typical Forward Voltage Drop
vs. Forward Current
50
Figure 2. Typical Reverse Current
vs. Reverse Voltage
40
10
Forward Current, I
F
[A]
T
C
= 125 C
o
10
Reverse Current , I
R
[
µ
A
]
T
C
= 125 C
o
75 C
25 C
o
o
1
T
C
= 75 C
o
1
0.1
0.01
T
C
= 25 C
o
0.1
0
1
2
3
4
Forward Voltage, V
F
[V]
5
1E-3
10
100
200
300
400
Reverse Voltage, V
R
[V]
500
600
Figure 3. Typical Junction Capacitance
50
Reverse Recovery Time, t
rr
[ns]
Typical Capacitance
at 0V = 43 pF
Figure 4. Typical Reverse Recovery Time
vs. di/dt
60
40
Capacitances , Cj [pF]
50
30
40
T
C
= 125 C
o
20
30
T
C
= 75 C
o
10
20
T
C
= 25 C
o
0
0.1
1
10
Reverse Voltage, V
R
[V]
100
10
100
200
300
400
di/dt
[
A/
µ
s
]
500
600
Figure 5. Typical Reverse Recovery
Current vs. di/dt
7
6
5
T
C
= 125 C
o
Figure 6. Forward Current Derating Curve
9
Average Forward Current, I
F(AV)
[A]
Reverse Recovery Current, I
rr
[A]
6
4
3
2
1
100
T
C
= 25 C
o
T
C
= 75 C
o
3
200
300
400
di/dt
[
A/
µ
s
]
500
600
0
25
50
75
100
125
o
Case temperature, T
C
[
C
]
150
FFPF60SB60DS Rev. A
3
www.fairchildsemi.com
FFPF60SB60DS
