FSB6714: DescriptionTRANS NPN 30V 3-SSOT; Categorysemiconductor Discrete semiconductor; File Size41KB，1 Pages; ManufacturerON Semiconductor; Websitehttp://www.onsemi.cn; Environmental Compliance

Download Datasheet Parametric View All

FSB6714 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	FSB6714	-	-	View	Buy Now

FSB6714 Overview

TRANS NPN 30V 3-SSOT

FSB6714 Parametric

Parameter Name	Attribute value
Transistor type	NPN
Voltage - collector-emitter breakdown (maximum)	30V
Vce saturation value (maximum value) when different Ib,Ic	-
Current - collector cutoff (maximum)	-
DC current gain (hFE) at different Ic, Vce (minimum value)	-
Frequency - Transition	-
Operating temperature	-
Installation type	surface mount
Package/casing	TO-236-3，SC-59，SOT-23-3
Supplier device packaging	3-SSOT

Preview

Download Datasheet

View All

2.92±0.12

3

A

0.95

B

1.40

1.40±0.12

2.20

1

(0.29)

0.95

1.90

1.12 MAX

2

0.508

0.382

0.10

M

A B

1.90

1.00

LAND PATTERN RECOMMENDATION

SEE DETAIL A

0.10

0.00

0.10

M

(0.94)

C

2.51±0.20

GAGE PLANE

NOTES: UNLESS OTHERWISE SPECIFIED

0.178

0.102

0.20

0.43

0.33

(0.56)

A) NO JEDEC REFERENCE AS OF AUGUST 2003

B) ALL DIMENSIONS ARE IN MILLIMETERS.

C) DIMENSIONS ARE EXCLUSIVE OF BURRS,

MOLD FLASH AND TIE BAR EXTRUSIONS.

D) DIMENSIONING AND TOLERANCING PER

ASME Y14.5M - 2009.

E) DRAWING FILE NAME: MKT-MA03BREV3

SEATING

PLANE

SCALE: 50:1
