SMPS Capacitors (SK Style)

Commercial Radial Range

PRODUCT OFFERING – C0G, N1500, X7R AND Z5U

AVX SK styles are conformally coated MLC capacitors for input or output filter-

ing in switch mode power supplies. They are specially processed to handle high

currents and are low enough in cost for commercial SMPS application.

ELECTRICAL SPECIFICATIONS

Temperature Coefficient

C0G: A Temperature Coefficient

– 0 ±30 ppm/°C, -55° to +125°C

N1500: 4 Temperature Coefficient – -1500 ±250 ppm/°C

X7R: C Temperature Coefficient

– ±15%, -55° to +125°C

Z5U: E Temperature Coefficient

– +22, -56%, +10° to +85°C

Capacitance Test

(MIL-STD-202 Method 305)

C0G, N1500: 25°C, 1.0±0.2 Vrms (open circuit voltage) at 1KHz

X7R: 25°C, 1.0±0.2 Vrms (open circuit voltage) at 1KHz

Z5U: 25°C, 0.5 Vrms max (open circuit voltage) at 1KHz

Dissipation Factor 25°C

C0G, N1500: 0.15% Max @ 25°C, 1.0±0.2 Vrms (open circuit voltage) at 1KHz

X7R: 2.5% Max @ 25°C, 1.0±0.2 Vrms (open circuit voltage) at 1KHz

Z5U: 3.0% Max @ 25°C, 0.5 Vrms max (open circuit voltage) at 1KHz

Insulation Resistance 25°C

(MIL-STD-202 Method 302)

C0G, N1500, X7R: 100K MΩ or 1000 MΩ-μF, whichever is less.

Z5U: 10K MΩ or 1000 MΩ-μF, whichever is less.

Insulation Resistance 125°C

(MIL-STD-202 Method 302)

C0G, N1500, X7R: 10K MΩ or 100 MΩ-μF, whichever is less.

Z5U: 1 KMΩ or 100 MΩ-μF, whichever is less.

Dielectric Withstanding Voltage 25°C

(Flash Test)

C0G, N1500, X7R: 250% rated voltage for 5 seconds with 50 mA max

charging current. (500 Volt units @ 750 VDC)

Z5U: 200% rated voltage for 5 seconds with 50 mA max charging current.

Life Test

(1000 hrs)

C0G, N1500, X7R: 200% rated voltage at +125°C. (500 Volt units @ 600 VDC)

Z5U: 150% rated voltage at +85°C

Moisture Resistance

(MIL-STD-202 Method 106)

C0G, N1500, X7R, Z5U: Ten cycles with no voltage applied.

Thermal Shock

(MIL-STD-202 Method 107, Condition A)

Immersion Cycling

(MIL-STD-202 Method 104, Condition B)

Resistance To Solder Heat

(MIL-STD-202, Method 210,

Condition B, for 20 seconds)

HOW TO ORDER

Style

Size

See

chart

below

Voltage

25V = 3

50V = 5

100V = 1

200V = 2

500V = 7

Temperature

Coefficient

Z5U = E

X7R = C

C0G = A

N1500 = 4

125

Capacitance

Code

(2 significant

digits + no.

of zeros)

22 nF = 223

220 nF = 224

1 μF = 105

100 μF = 107

Test

Capacitance

Leads

Packaging

Level

Tolerance

A = Tin/Lead

(See Note 1)

A = Standard R = RoHS

C0G, N1500: J = ±5%

B = Hi-Rel*

K = ±10%

Compliant**

M = ±20%

X7R:

K = ±10%

Note 1:

No suffix signifies bulk packaging,

M = ±20%

which is AVX standard packaging.

Z = +80, -20%

SK01, SK

3, SK

4, SK

5, SK

6, SK

Z5U:

M = ±20%

& SK

0 are available taped and reel

Z = +80, -20%

per EIA-468. Use suffix “TR1” if tape &

P = GMV (+100, -0%)

reel is required.

Note: Capacitors with X7R and Z5U dielectrics are not intended for applications

across AC supply mains or AC line filtering with polarity reversal. Contact plant

for recommendations.

Hi-Rel screening for C0G, N1500 and X7R only. Screening consists of 100% Group A

(B Level), Subgroup 1 per MIL-PRF-49470.

RoHS Compliant parts are not available in the Z5U dielectric.

TAPE & REEL QUANTITY

Part

SK01

SK03/SK53

SK04/SK54

SK05/SK55

SK06/SK56

SK07

SK08

SK09/SK59

SK10/SK60

Pieces

2000

1000

500

N/A

500

400

Part

RoHS

Available

Yes

For RoHS compliant products,

please select correct termination style.

SK01

SK03/SK53

SK04/SK54

SK05/SK55

SK06/SK56

SK07

SK08

SK09/SK59

SK10/SK60

Not RoHS Compliant

Performance of SMPS capacitors can be simulated by downloading SpiCalci software program -

http://www.avx.com/download/software/SpiCalci-AVX.zip

Custom values, ratings and configurations are also available.
