COM-08653
1
4
7
2
5
8
0
3
6
9
#
*
DISCLAIMER:
This document is the result of an obscene amount of
work and research because I really wanted to make
a nice wood case / bezel using Ponoko for a project
I'm working on. Literally everything in this document
might be wrong and if you waste money or injure
somebody based on this document, it's your own
look out. If you can and want to correct any of the
information here, contact andrew@amorrow.com.
COM-08653
Mechanical
51
46
6
R2
Ø 2.3 screw hole (x4)
0.7
8.7
0.7
0.7
1
1
4
59
2
5
8
0
1 2 3 4 5 6 7
3
6
9
#
13
39
57
64
0.7
7.7
7
*
R4
All images except the key callout are actual size
when printed on 8.5x11 with approriate margins.
You can calibrate your printer using the box below.
10mm
(1cm)
28
46
COM-08653
Electrical
PushButtons: Columns + Rows
This is the same information in several different ways.
I've gotten requests to visualize it differently, so why fight it?
1: 3+2
2: 1+2
3: 5+2
4: 3+7
5: 1+7
6: 5+7
7: 3+6
8: 1+6
9: 5+6
*: 3+4
0: 1+4
#: 5+4
1
2
3
4
5
=
=
=
=
=
6
=
3
1
5
3
1
5
&
&
&
&
&
&
2
2
2
7
7
7
7
=3&
8
=1&
9
=5&
*
=3&
0
=1&
#
=5&
6
6
6
4
4
4
Keypad Columns: 3,1,5
Keypad Rows: 2,7,6,4
3
2
7
6
4
1
5
1
4
7
2
5
8
0
3
6
9
#
*
1
4
7
2
5
8
0
1 2 3 4 5 6 7
3
6
9
#
1
4
7
2
5
8
0
1 2 3 4 5 6 7
3
6
9
#
*
*
COM-08653
Arduino information
Thanks to Jim Winburn for additional Arduino related info, and for changing the groupings on the pin layouts.
MUCH more clear now!
Keypad Pin 3
Keypad Pin 1
Keypad Pin 5
Keypad
Keypad
Keypad
Keypad
Pin
Pin
Pin
Pin
2
7
6
4
Arduino digital 2
Arduino digital 3
Arduino digital 4
Arduino
Arduino
Arduino
Arduino
digital
digital
digital
digital
5
6
7
8
Notice the rowPins and colPins below in the sample code example:
// example from Arduino playground: http://www.arduino.cc/playground/Code/Keypad
#include <Keypad.h>
const byte ROWS = 4; //four rows
const byte COLS = 3; //three columns
char keys[ROWS][COLS] = {
{'1','2','3'},
{'4','5','6'},
{'7','8','9'},
{'*','0','#'}
};
byte rowPins[ROWS] = {5, 6, 7, 8}; //connect to the row pinouts of the keypad
byte colPins[COLS] = {2, 3, 4}; //connect to the column pinouts of the keypad
COM-08653
Sources
http://www.sparkfun.com/products/8653
http://www.tenrod.com.au/pdf/accord/keypads.pdf
http://www.accordia.com.tw/html/tel/index.htm (AK-304-BBW)
http://www.accordia.com.tw/html/tel/imagepages/imagepg11.htm
http://www.idpcorp.net/product_expertise/silicone_keypads/stock_keypads/technical_information.html
2-24-2011
