Note 1: The backlight life refers to the time until the brightness reduces by half after use at 25°C.
Note 2: Brightness of LCD only (monochrome LCD: when lit white).
Operation Specifications
Part No.
Switching Element
Operating Force
Mechanical Life
Acknowledgment Sound
Multiple Press
Touch
Analog resistive membrane (touch panel)
0.2 to 2.5N
1 million operations
Electric Buzzer
Not possible
HMI Function Specifications
Drawings, bit button, word button, goto screen button, key button, multi-button, keypad, selector switch, potentiometer, numerical input, character input, pilot lamp, picture
display, message display, message switching display, alarm list display, alarm log display, numerical display, bar chart, line chart, pie chart, meter, calendar, bit write
command, word write command, goto screen command, timer, script command, multi-command, system area, start time, Auto Backlight OFF, O/I Link, user communication,
maintenance communication, DM Link Communication, PLC Link Communication (Note 1), alarm log, data log, operation log, data storage area, preventive maintenance,
recipe, text group, global script, user account, project data transfer using external memory, downloading logged data in external memory, USB auto-run function
Note 1: The up-to-date information on the connectable PLC can be obtained from http://www.idec.com/language.
No. of Characters
Character Magnification
Character Attributes
Graphics
Window Display
Functions
Input Specifications
Part Number
Input Points
Input Type
Input Voltage Range
Rated Input Current
Input Impedance
Input Delay Time
Digital Input
Isolation
Input Type
External Load for I/O Interconnection
OFF voltage
ON voltage
Operating Level
OFF current
ON current
Input Points
Input Type
Input Range
Sampling Duration Time
Total Input System Transfer Time
Digital Resolution
Input Error
25°C
Total
Between input terminals
Internal circuit
Digital I/O
When used as digital
input
OFF
ON
ON
OFF
Between input terminals
Internal circuit
*12RA-*
6
Sink
0 to 28.8V DC
4.4 mA
5.5 kΩ
2.5 μs + soft filter setting
5 μs + soft filter setting
Not isolated
Not isolated
Type 1 (IEC 61131-2)
Not needed
Sink type: 5V DC max.
Source type: 15V DC min.
Sink type: 15V DC min.
Source type: 5V DC max.
Sink type: 0.9 mA max.
Source type: –1.0 mA min.
Sink type: 2.7 mA min.
Source type: –3.0 mA max.
2
Voltage input
0 to 10.0 VDC
2 ms maximum
3 ms + sampling time + scan time
0 to 1,000 (10 bits)
±3% of full scale
±5% of full scale
Not isolated
Not isolated
Type 1 (not conforming to IEC 61131-2 digital I/O type)
OFF voltage: 5V maximum
Operation Level
ON voltage: 15V minimum
OFF current: 0.06 mA maximum
ON current: 0.20 mA minimum
External Power for Input
Input Voltage Range
Output Current Capacity
—
—
3 ms + sampling time + scan time
(voltage input)
12 ms + sampling time + scan time
(current input)
Voltage/Current input
0 to 10.0 VDC / 4 to 20 mA
5.2 mA
4.7 kΩ
4.4 mA
5.5 kΩ
Source
Sink
*14KA-*
*14SA-*
analog Input
Isolation
Output Specifications
Part Number
Output Points
Rated Load Voltage
Input Voltage Range
Maximum Load
Current
transistor Output
Inrush Current
Leakage Current
Clamping Voltage
Maximum Lamp Load
Inductive Load
External Current Draw
Isolation
Between output terminal
and internal circuit
Between output terminals
Output Delay
Electrical Life
relay Output
Common
Mechanical Life
Between output terminal
and internal circuit
Between output terminals
(between COMs)
OFF ON
ON OFF
100,000 operations minimum (resistive load
1,800 operations/h)
20 million operations minimum (no load
18,000 operations/h)
2,300V AC, 1 minute
2,300V AC, 1 minute
—
1 point
1 common
Transistor Sink Output
Transistor Source Output
*12RA-*
*14KA-*
4
—
24V DC
20.4 to 28.8V DC
0.3A maximum
1A maximum
1V maximum (voltage between COM and output terminals when output is ON)
1A
0.1 mA maximum
39V ± 1V
8 W maximum
L/R = 10 ms (28.8V DC, 1 Hz)
100 mA maximum, 24V DC
Photocoupler isolated
Not isolated
100μS max.
200μS max.
—
—
—
—
2
Voltage/Current output (Selectable)
0 to 10V DC / 4 to 20mA
2kΩ min (voltage input) / 500 Ω max (current input)
Overshoot may occur under light load conditions. Overshoot can be suppressed by inserting a damping resistor. Damping resistor value: approx. 150Ω including
