CRYSTAL CLOCK OSCILLATORS
Data Sheet 0629H
Rev. B
LVDS HF VCXO
SU-A3DCXXX Series
Description
The
SU-A3DCXXX Series
of voltage controlled crystal oscillators (VCXO) provides high frequency with
LVDS complementary outputs. The outputs can be disabled for test automation or combining multiple clocks.
The device does not use any frequency multiplication, providing exceptionally low Phase Noise and Jitter. It
is packaged in a miniature, FR-4 based 9x14mm SMD package.
Applications and Features
• Wide frequency range – 12.0MHz to 280.000MHz
• Fiber Channel; 10 GbE; Infiniband; Network Processors; SONET/SDH
• High Reliability - NEL HALT/HASS qualified for crystal oscillator start-up conditions
• Extremely Low Phase Noise and Jitter
• High shock resistance, to 1000g
• No Multiplication
• Absolute Pull Range (APR) to ±100 ppm
• SONET ±20 ppm overall free-run stability available
• RoHS Compliant, Lead Free Construction
Creating a Part Number
SU - A 3DC X X X - FREQ
Package Code
Absolute Pull Range, ppm
SU 6 pad 9x14 mm SMD
E ±20
F ±32
Input Voltage
G ±50
A
3.3V±5%
H ±100
9 Customer specific
Enable Option
H
Positive CMOS level
N
N/A
Temperature Range, °C
A 0 to 50
B 0 to 70
C -20 to 70
D -40 to 85
9
Customer specific
357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881
Email:
nelsales@nelfc.com
www.nelfc.com
CRYSTAL CLOCK OSCILLATORS
SU-A3DCXXX Series
LVDS HF VCXO
Continued
Data Sheet 0629H
Rev.
B
Absolute Maximum Ratings
Parameter
Operating Temperature Range
Storage Temperature Range
Supply Voltage
Enable/Disable Voltage
Parameter
Nominal Frequency
Supply Voltage
Supply current
Output Logic Type
Load
Output Levels
Symb
Fo
Vcc
Icc
At receiving end between
the outputs
Differential amplitude
Amplitude error
Offset Voltage
Offset Voltage error
At outputs crossing, room
temperature
20 to 80, 80 to 20 %
Integrated from Phase
Noise, 12 KHz to 20 MHz ,
RMS
100 Hz to 80 KHz, RMS
50 Khz to 80 Mhz
Random
period,
Accumul.,
pk-to-pk
Deterministic
@ 10 Hz
@100 Hz
@1 KHz
@10KHz
@100KHz
@>1MHz
Overall, including initial
calibration, temperature,
aging 10 years, shock and
vibration @ Vc=Vcc/2;
APR 50ppm, or less
Vc to set F at Fo; T, Vcc,
load - nominal, as shipped
Over all conditions, see
part # creation
@ Fmod < 100 Khz
At Vc = Vcc/2, -3dB
CMOS logic 1 or N/C
CMOS logic 0
155.52 MHz,
APR 50ppm
or less
90
247
1.125
45/55
Symbol
To
Tst
Vcc
Ven/dis
Conditions, Note
Code A
Value
-40 to +85
-50 to +90
-0.5 to 4.5
0 to Vcc
MIN
12
3.135
TYP
3.3
80
LVDS
100
330
1.25
50/50
0.5
0.1
MAX
280
3.465
100
110
454
50
1.375
50
55/45
0.7
0.2
1.0
0.3
2.5
17
0
None
-75
-105
-128
-142
-147
-147
±30
Unit
ºC
ºC
V
V
Unit
MHz
V
mA
Ohm
mV
mV
V
mV
%
ns
ps
ps
ps
ps
ps
ps
dBc
dBc/Hz
Electrical Parameters
Vod
Vof
Duty Cycle
(Symmetry)
Rise/Fall Time
Jitter
Integrated
Tr/Tf
J
Wavecrest
characterized
Sub-Harmonics
Phase Noise
£(Δf)
Frequency Stability
ΔF/F
±20
-70
-100
-125
-140
-145
-145
ppm
Control Voltage Range
Setability
Absolute Pull Range
Input Impedance
Modulation Bandwidth
Enable/Disable Option
Pin 2 Enabled
Pin 2 Disabled
Vc
Vcs
APR
Zin
0V
0.4 Vcc
20,32,
50,100
50
20
0.7 Vcc
0
0.5 Vcc
Vcc
0.6 Vcc
V
V
ppm
KOhm
KHz
Vcc
0.3 Vcc
V
357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881
Email:
nelsales@nelfc.com
www.nelfc.com
CRYSTAL CLOCK OSCILLATORS
Rev. B
SU-A3DCXXX Series
LVDS HF VCXO
Electrical Connection
Pin
Connection
1
Vco
2
Enable/Disable
3
Gnd
4
Output
5
Output Complement
6
V
CC
Continued
Environmental and Mechanical Characteristics
Operating temp.
range
Mechanical Shock
Thermal Shock
Vibration
Hermetic Seal
Soldering conditions
see part # table
Per MIL-STD-202, Method 213, Cond. E
Per MIL-STD-883, Method 1011, Cond. A
Per MIL-STD-883, Method 2007, Cond. A
Leak rate less than 1x10-8 atm.cc/s of helium
See MAX reflow profile below
Maximum Reflow Profile
357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881
Email:
nelsales@nelfc.com www.nelfc.com
