A-MO 4/4 F50: DescriptionCONN MOD PLUG 4P4C UNSHIELDED; CategoryThe connector; File Size216KB，1 Pages; ManufacturerASSMANN WSW components; Environmental Compliance

Download Datasheet Parametric Compare View All

A-MO 4/4 F50 Overview

CONN MOD PLUG 4P4C UNSHIELDED

A-MO 4/4 F50 Parametric

Parameter Name	Attribute value
Connector type	plug
Cable type	Flat oval cable, stranded conductors
Number of pins/contacts	4p4c（RJ9，RJ10，RJ22）
characteristic	-
shield	No shielding
grade	-
Intrusion protection	-
Termination	IDC
length	0.533"（13.54mm）
color	translucent - transparent
Wire gauge	-
Contact plating	gold
Contact plating thickness	50.0µin（1.27µm）
Contact material	copper alloy
Rated current	2A
Rated voltage	250V
Shell material	Polycarbonate (PC)
shielding material	-

Preview

Download Datasheet

View All

1

4

A

2

3

5

6

7

A

B

C

D

E

F

Scale

FREE

TOLERANCE

Drawn

Date

26.05.2014

F

Name

Customer-No.

G

Ray

X.X

±0.2

X.XX ±0.10

X.XXX ±0.050

Approved

12.06.2016

G

DIM

Angle

TOL

±2°

TOL

Ray

ASSMANN WSW-No.

A-MO 4/4-F50

2

1

Id.

Update drawing

Drawn

Modification

12.06.2016

26.05.2014

Date

Ray

Name

Drawing-No.

H

RoHS compliant

Unit: mm

ASS 6446 CO

rev01

H

1

2

3

4

5

Replace

Sheet

6

7

A-MO 4/4 F50 Related Products

	A-MO 4/4 F50
Description	CONN MOD PLUG 4P4C UNSHIELDED
Connector type	plug
Cable type	Flat oval cable, stranded conductors
Number of pins/contacts	4p4c（RJ9，RJ10，RJ22）
shield	No shielding
Termination	IDC
length	0.533"（13.54mm）
color	translucent - transparent
Contact plating	gold
Contact plating thickness	50.0µin（1.27µm）
Contact material	copper alloy
Rated current	2A
Rated voltage	250V
Shell material	Polycarbonate (PC)
