The ECOC-2522 is a SMD CMOS SC-Cut OCXO. The 25.4 x 22.0 x
12.2 mm SMD package is ideal for Cellular, Radar, Test &
Measurement and IOT applications.
ECX-2520 SMD HCMOS TCXO
ECOC-2522
SMD OCXO
OPERATING CONDITIONS / ELECTRICAL CHARACTERISTICS
PARAMETERS
Frequency Range
0 ~ +50°C (F Opt)
-20 ~ +70°C (G Opt)
-40 ~ +75°C (H Opt)
CONDITIONS
MIN
ECOC-2522
TYP
MAX
UNITS
MHz
ppb
ppb
ppb
ppb
ppb
ppm
Watts
Watts
V
V
ppb
ppb
ppb
2.000
Frequency Stability
SC Cut
25.4 x 22 mm Footprint
Extended Temp Range
RoHS Compliant
Supply Voltage ±5%
Warm-Up @+25°C
(≤ 3 minutes)
Load Change (±10%)
At turn on
Steady State
3.3 Option
5.0 Option
100.000
± 5.0
± 10.0
±30.0
±20.0
±100.0
±0.2
3.6
1.4
3.465
5.25
±1.0
±100
±500
Power Consumption
Power Consumption
Supply Voltage
Supply Voltage
Aging
Waveform
Output voltage Level
Output Load
Rise & Fall time
Duty Cycle
Waveform
Peak Power
Output Load
Spurious Response
Phase Noise
@ 1 Hz Offset
@ 10 Hz Offset
@ 100 Hz Offset
@ 1,000 Hz Offset
@ 10,000 Hz Offset
@ 100 KHz Offset
@ 1 MHz Offset
Control Voltage Range
3.135
4.75
3.3
5.0
Daily (after 30
days)
Yearly
10-Years
Frequency Pull Range
VC Port Impedance
Storage Temperature
CMOS
V
OL:
10%V
dd
max./V
OH:
90%V
dd
min.V DC
15
pF
10%V
dd –
90%V
dd
5
ns
@ ½ V
dd
45/55
%
Sinewave
2.0
dBm
50
Ω
-70
dBc
@ 10 MHz Carrier, Vdd 3.3V
-90
dBc/Hz
-120
dBc/Hz
-135
dBc/Hz
-145
dBc/Hz
-150
dBc/Hz
-150
dBc/Hz
-150
dBc/Hz
Positive Slope
0
Vdd/2
Vdd
V
±0.7
ppm
10
kΩ
-40
+100
°C
Rev.2016
15351 West 109
th
Street
|
Lenexa, KS 66219
|
Phone: 913.782.7787
|
Fax: 913.782.6991
|
www.ecsxtal.com
ECOC-2522
SMD OCXO
PART NUMBERING GUIDE: Example ECOC-2522-10.000-3-F-C
ECOC -
SERIES
FREQUENCY
VOLTAGE
STABILITY /TEMP
OUTPUT
2522
25.4 x 22 mm OCXO
10.000 MHz
3 = +3.3V
5 = +5.0V
F = ±5 ppb
G = ±10 ppb
H = ±30 ppb
0 ~ +50°C
-20 ~ +70°C
-40 ~ +75°C
C = CMOS
S = Sinewave
DIMENSIONS (mm)
PAD CONNECTIONS
1
Voltage Control
2
V Ref
3
Supply Voltage
4
Output
5
Ground
FREQUENCY MHz
10.000
12.800
13.000
16.384
20.000
38.400
38.800
40.000
100.000
SOLDER PROFILE
Peak solder Temp +260°C Max 10 sec Max.
2 Cycles Max.
MSL 1, Lead Finish Au
Figure 1)
Top, Side, Bottom and suggested Land pattern.
