FMZ
CONNECTOR
1.0mm pitch/Connectors for FFC
Specifications –––––––––––––––––––
• Current rating: 0.5A AC, DC
• Voltage rating: 50V AC, DC
• Temperature range: -25˚C to +85˚C
(including temperature rise in applying
electrical current)
• Contact resistance: Initial value/20m
Ω
max.
After environmental testing/30m
Ω
max.
• Insulation resistance:
800M
Ω
min.
• Withstanding voltage: 500V AC/minute
• Applicable FFC : Conductor pitch/1.0mm
Conductor width/0.7mm
Mating part thickness/
6, 8 to 10, 12 to 16, 20 circuits: 0.3±0.05mm
22, 26, 28, 30 circuits: 0.3
+0.05
mm
0
• Applicable PC board thickness: 0.8 to 1.6mm
Note
:
FFC to be actually used should be checked for applicability.
The FMZ series, a Zero Insertion Force
(ZIF) connector series, was developed to
increase wear resistance and extend the
connector's mating life. It is a very
compact connector with a thickness of
only 4.2mm and a pitch of only 1.0mm and
is thus useful for high density packaging.
The contact has a reliable double-leaf
construction which provides stable
connection.
• Zero insertion force mechanism
• Temporary retention feature
• Compact
• Double-leaf contact
* Compliant with RoHS.
* Refer to "General Instruction and Notice when using
Terminals and Connectors" at the end of this catalog.
* Contact JST for details.
Standards ––––––––––––––––––––––
1
Certified LR20812
Side entry type
0
Recognized E60389
PC board layout (viewed from soldering side) and Assembly layout
Top entry type
4.2
Circuit No.1
1.2
min
3.05
2.0
±0.05
1.0
±0.05
Circuit No.1
3.05
2.0
±0.05
1.0
±0.05
6.5
6.2
min
6.5
φ0.75
±0.05
2.0
±0.05
2.7
Note: 1. Tolerances are non-cumulative:
±
0.05mm for all centers.
2. Hole dimensions differ according to the kind of PC board and piercing method. The dimensions above should serve as a guideline. Contact JST for details.
2.0
±0.05
2.7
4.2
φ0.75
±0.05
1
FMZ CONNECTOR
Connector
Top entry type
B
3.95
Circuits
6
8
9
10
12
13
14
15
16
17
20
22
24
26
28
30
Circuit No.1
3.05
A
1.0
2.35
2.0
4.2
1.0
Model No.
Top entry type Side entry type
06FMZ-BT 06FMZ-ST
08FMZ-BT 08FMZ-ST
09FMZ-BT 09FMZ-ST
10FMZ-BT 10FMZ-ST
12FMZ-BT 12FMZ-ST
13FMZ-BT 13FMZ-ST
14FMZ-BT 14FMZ-ST
15FMZ-BT 15FMZ-ST
16FMZ-BT 16FMZ-ST
17FMZ-BT 17FMZ-ST
20FMZ-BT 20FMZ-ST
22FMZ-BT 22FMZ-ST
24FMZ-ST
−
26FMZ-BT 26FMZ-ST
28FMZ-BT 28FMZ-ST
30FMZ-BT 30FMZ-ST
Dimensions (mm)
A
B
5.0
7.0
8.0
9.0
11.0
12.0
13.0
14.0
15.0
16.0
19.0
21.0
23.0
25.0
27.0
29.0
12.0
14.0
15.0
16.0
18.0
19.0
20.0
21.0
22.0
23.0
26.0
28.0
30.0
32.0
34.0
36.0
Q'ty / box
Top entry type Side entry type
1,440
1,440
960
960
960
960
960
780
780
780
720
720
800
800
600
600
600
600
400
400
400
400
400
400
300
300
300
300
（2.7） 6.5 (
When locked
)
8.0
−
480
480
480
Side entry type
Material and Finish
B
3.5
1.0
JST
Contact: Phosphor bronze, copper-undercoated, tin-plated (reflow treatment)
Housing: Glass-filled PBT, UL94V-0
A
8.0
6.5
（
When locked）
RoHS compliance
This product displays (LF)(SN) on a label.
3.95
Circuit No.1
（6.2）
locked
2.0
When
Lead section dimensions of FFC
±
（N＋1）
0.12
1.0 ×
±
（N−1）
0.1
1.0
±0.15
1.0 ×
1.0
±0.15
（2.7）
4.2
1.0
±0.1
0.7
±0.1
6∼22
circuits:0.30
±0.05
22∼30
circuits:0.30∼0.35
5.0
min
Conductor
Film cover layer
7.5
Reinforcing layer
Base layer
Note: N --- Number of circuits
2
