Bolt connection terminal block - RTO 8 - 3049343
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
Bolt connection terminal block, nom. voltage: 1000 V, nominal current: 125 A, connection method: Bolt
connection, length: 84 mm, width: 20.3 mm, color: gray, mounting: NS 35/7,5, NS 35/15, nom. voltage: 1000 V
Your advantages
Four bridge shafts per terminal block
Terminal point always freely accessible
Key Commercial Data
Packing unit
GTIN
GTIN
4046356140058
25 pc
Technical data
General
Note
Number of positions
Number of levels
Number of connections
Potentials
Nominal cross section
Color
Insulating material
Flammability rating according to UL 94
Rated surge voltage
Degree of pollution
Overvoltage category
Insulating material group
Note: the BE-RT... path extension is to be used for non-insulated cable
lugs (see accessories).
1
1
2
1
35 mm²
gray
PA
V0
8 kV
3
III
I
10/25/2018 Page 1 / 6
https://www.phoenixcontact.com/pi/products/3049343
Bolt connection terminal block - RTO 8 - 3049343
Technical data
General
Maximum power dissipation for nominal condition
Maximum load current
Nominal current I
N
Nominal voltage U
N
Open side panel
Result of surge voltage test
Surge voltage test setpoint
Result of power-frequency withstand voltage test
Power frequency withstand voltage setpoint
Result of the test for mechanical stability of terminal points (5 x
conductor connection)
Result of tight fit on support
Tight fit on carrier
Setpoint
Result of voltage-drop test
Requirements, voltage drop
Result of temperature-rise test
Short circuit stability result
Conductor cross section short circuit testing
Short-time current
Result of thermal test
Proof of thermal characteristics (needle flame) effective duration
Oscillation, broadband noise test result
Test specification, oscillation, broadband noise
Test spectrum
Test frequency
ASD level
Acceleration
Test duration per axis
Test directions
Shock test result
Test specification, shock test
Shock form
Acceleration
Shock duration
Number of shocks per direction
Test directions
Relative insulation material temperature index (Elec., UL 746 B)
Temperature index of insulation material (DIN EN 60216-1 (VDE
0304-21))
Static insulating material application in cold
4.06 W
125 A (with 35 mm² conductor cross section)
125 A
1000 V
Yes
Test passed
9.8 kV
Test passed
2.2 kV
Test passed
Test passed
NS 35
10 N
Test passed
≤ 3.2 mV
Test passed
Test passed
35 mm²
4.2 kA
Test passed
30 s
Test passed
DIN EN 50155 (VDE 0115-200):2008-03
Service life test category 1, class B, body mounted
f
1
= 5 Hz to f
2
= 150 Hz
0.02 g²/Hz
0,8 g
5h
X-, Y- and Z-axis
Test passed
DIN EN 50155 (VDE 0115-200):2008-03
Half-sine
5g
30 ms
3
X-, Y- and Z-axis (pos. and neg.)
130 °C
130 °C
-60 °C
10/25/2018 Page 2 / 6
https://www.phoenixcontact.com/pi/products/3049343
Bolt connection terminal block - RTO 8 - 3049343
Technical data
General
Behavior in fire for rail vehicles (DIN 5510-2)
Flame test method (DIN EN 60695-11-10)
Oxygen index (DIN EN ISO 4589-2)
NF F16-101, NF F10-102 Class I
NF F16-101, NF F10-102 Class F
Surface flammability NFPA 130 (ASTM E 162)
Specific optical density of smoke NFPA 130 (ASTM E 662)
Smoke gas toxicity NFPA 130 (SMP 800C)
Calorimetric heat release NFPA 130 (ASTM E 1354)
Fire protection for rail vehicles (DIN EN 45545-2) R22
Fire protection for rail vehicles (DIN EN 45545-2) R23
Fire protection for rail vehicles (DIN EN 45545-2) R24
Fire protection for rail vehicles (DIN EN 45545-2) R26
Test passed
V0
>32 %
2
2
passed
passed
passed
28 MJ/kg
HL 1 - HL 3
HL 1 - HL 3
HL 1 - HL 3
HL 1 - HL 3
Dimensions
Width
End cover width
Length
Height NS 35/7,5
Height NS 35/15
20.3 mm
2.2 mm
84 mm
62.2 mm
69.7 mm
Connection data
Note
Connection method
Connection in acc. with standard
Conductor cross section flexible min.
Conductor cross section flexible max.
Min. AWG conductor cross section, flexible
Max. AWG conductor cross section, flexible
Cable lug connection according to standard
Min. cross section for cable lug connection
Max. cross section for cable lug connection
Hole diameter, min.
Cable lug width, max.
Bolt diameter
Cable lug connection according to standard
Hole diameter, min.
Cable lug width, max.
Bolt diameter
Cable lug connection according to standard
Min. cross section for cable lug connection
Max. cross section for cable lug connection
Connection bolts
Bolt connection
IEC 60947-7-1
2.5 mm²
35 mm²
14
2
DIN 46234
2.5 mm²
35 mm²
8.4 mm
16 mm
8 mm
DIN 46235
8.4 mm
14 mm
8 mm
DIN 46237
2.5 mm²
6 mm²
10/25/2018 Page 3 / 6
https://www.phoenixcontact.com/pi/products/3049343
Bolt connection terminal block - RTO 8 - 3049343
Technical data
Connection data
Hole diameter, min.
Cable lug width, max.
Bolt diameter
Screw thread
Tightening torque, min
Tightening torque max
8.4 mm
14 mm
8 mm
M8
6 Nm
10 Nm
Standards and Regulations
Connection in acc. with standard
Flammability rating according to UL 94
Fire protection for rail vehicles (DIN EN 45545-2) R22
Fire protection for rail vehicles (DIN EN 45545-2) R23
Fire protection for rail vehicles (DIN EN 45545-2) R24
Fire protection for rail vehicles (DIN EN 45545-2) R26
CUL
IEC 60947-7-1
V0
HL 1 - HL 3
HL 1 - HL 3
HL 1 - HL 3
HL 1 - HL 3
Environmental Product Compliance
China RoHS
Environmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values
Drawings
Circuit diagram
Approvals
Approvals
Approvals
UL Recognized / VDE Zeichengenehmigung / cUL Recognized / ABS / IECEE CB Scheme / EAC / cULus Recognized
Ex Approvals
ATEX / IECEx / EAC Ex
Approval details
10/25/2018 Page 4 / 6
https://www.phoenixcontact.com/pi/products/3049343
Bolt connection terminal block - RTO 8 - 3049343
Approvals
UL Recognized
Nominal voltage UN
Nominal current IN
B
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm
C
600 V
115 A
FILE E 60425
600 V
115 A
VDE Zeichengenehmigung
Nominal voltage UN
Nominal current IN
mm²/AWG/kcmil
http://www2.vde.com/de/Institut/Online-Service/
VDE-gepruefteProdukte/Seiten/Online-Suche.aspx
1000 V
125 A
2.5-35
40022553
cUL Recognized
Nominal voltage UN
Nominal current IN
B
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm
C
600 V
115 A
FILE E 60425
600 V
115 A
ABS
http://www.eagle.org/eagleExternalPortalWEB/
10-HG580261-PDA
IECEE CB Scheme
http://www.iecee.org/
DE1-50525
EAC
EAC-Zulassung
cULus Recognized
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm
