STA60K7.9P thru
STA60K100P
SOLID STATE DEVICES, INC.
14830 Valley View Blvd * La Mirada, Ca 90638
Phone: (562) 404-4474 * Fax: (562) 404-1773
Designer's Data Sheet
FEATURES:
• 7.90-100 Volt Bidirectional
• Smaller than Microsemi 60KS200C Types
• Hermetically Sealed
• Meets all environmental requirements of MIL-PRF-19500
• Custom configurations available
• TX and TXV Screening Available
60,000 WATTS
PEAK PULSE POWER
7.9 - 100 VOLTS
LOW VOLTAGE
BIDIRECTIONAL TRANSIENT
VOLTAGE SUPPRESSOR
APPLICATIONS:
•Protection of Voltage Sensitive Components
•Protection Against Power Interuption
•Lightning Protection
MMAXIMUM
RATINGS
Stand Off Voltage
Steady State Power Dissipation
Peak Pulse Power @ 1.0 msec
Peak Pulse Power and Steady State
Power Derating
Peak Pulse Power and Pulse Width
Peak Pulse Power and Pulse Width
V
RWM
P
D
P
PP
5.6-75
400
V
W
W
60,000
See Graph
See Graph
-65°C to
+
175°C
Note:
SSDI Transient Suppressors offer standard Breakdown Voltage Tolerances of + 10%
(A) and + 5% (B). For other Voltage and Voltage Tolerances, contact SSDI's Marketing
Department
Package shown is standard configuration. SSDI can
custom design your module with terminals that meet
your unique design criteria. Additionally, SSDI can
package these devices with an irregular footprint or offset
mounting positions. This data sheet is meant to serve as
an example of SSDI's Transient Protection Module
Capabilities. For custom configurations, please contact
SSDI's Marketing Department.
PEAK PULSE POWER VS. TEMPERATURE DERATING CURVE
PEAK PULSE POWER
(% Rated 25°C Power)
AMBIENT TEMPERATURE (°C)
NOTE:
All specifications are subject to change without notification.
SCD's for these devices should be reviewed by SSDI prior to release.
DATA SHEET #: T00008C
RMD
STA60K7.9P
thru
STA60K100P
Electrical Characteristics
Part
Number
For 5% Voltage
Tolerance specify
"B" in place of A
SOLID STATE DEVICES, INC.
14830 Valley View Blvd * La Mirada, Ca 90638
Phone: (562) 404-4474 * Fax: (562) 404-1773
Break Down
(note 1)
Max Reverse Stand Off
Peak Pulse Clamping
Nominal
Voltage
Test
Current
Voltage
Reverse
Leakage
Current
Voltage
(max)
@ Current
tp=1ms
(note 4)
Maximum
Continuous
Current
(note 3)
Dynamic
Impedance
(note 2)
Maximum
Termperature
Coefficient
V
BR
Volts
7.9
8.9
9.8
10.7
11.0
12.7
13.5
15.0
16.7
18.0
20.2
22.6
24.5
27.9
30.5
34.0
36.0
39.0
45.0
49.0
51.0
57.0
62.0
68.0
75.0
82.0
91.0
100.0
@I
BRT
A
7.0
6.0
6.0
5.0
5.0
4.0
4.0
3.0
3.0
2.6
2.6
2.0
2.0
2.0
1.6
1.6
1.2
1.2
1.2
1.0
1.0
0.8
0.8
0.8
0.8
0.6
0.6
0.6
V
RWM
Volts
5.6
6.2
6.8
7.5
8.2
9.1
10
11
12
13
15
16
18
20
22
24
27
30
33
36
39
43
47
51
56
62
68
75
I
R
@ V
RWM
mA
60
48
1.6
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
V
C
Volts
14.5
15.0
16.0
17.5
18.5
19.5
21.0
23.0
25.0
27.0
30.0
33.5
36.0
40.0
43.5
47.0
52.0
55.0
60.0
65.0
70.0
78.0
87.0
93.0
103.3
113.5
126.5
138.5
I
PP
A
5120
4800
4360
4000
3720
3480
3160
2720
2560
2280
2080
1880
1720
1560
1400
1280
1200
1080
1000
920
840
760
680
640
560
520
480
440
I
RM
A
28
30
33
38
43
45
48
48
48
50
63
70
75
95
125
175
200
175
250
300
350
450
500
550
625
750
1000
1125
Z
BR
@ I
BRT
Ohms
0.07
0.08
0.09
0.10
0.11
0.11
0.12
0.12
0.13
0.13
0.15
0.16
0.18
0.25
0.40
0.50
0.60
0.70
1.0
1.2
1.4
1.8
2.0
2.2
2.5
3.0
4.0
4.5
TC
% / °C
.03
.03
.03
.05
.05
.05
.05
.05
.06
.06
.06
.06
.06
.06
.06
.06
.06
.06
.06
.07
.07
.07
.07
.08
.08
.08
.08
.09
STA60K7.9P
STA60K8.9P
STA60K9.8P
STA60K10.7P
STA60K11P
STA60K12.7P
STA60K13.5P
STA60K15P
STA60K16.7P
STA60K18P
STA60K20.2P
STA60K22.6P
STA60K24.5P
STA60K27.9P
STA60K30.5P
STA60K34P
STA60K36P
STA60K39P
STA60K45P
STA60K49P
STA60K51P
STA60K57P
STA60K62P
STA60K68P
STA60K75P
STA60K82P
STA60K91P
STA60K100P
PEAK PULSE POWER VS. PULSE WIDTH
PEAK PULSE POWER (KW
)
CURRENT PULSE WAVEFORM
STEADY STATE POWER
STEADY STATE POWER DERATING
(% of 25ºc rated power)
% PEAK VALUE
CASE TEMPERATURE (°C)
PULSE WIDTH
For optional high reliability screening or higher zener voltages, consult SSDI MARKETING Department.
Notes:
1 . All voltages are measured with automated test set using 35 msec test time. Longer or shorter test times will have a corresponding effect on the measured
value due to heating effects.
2 . Dynamic impedance is derived from the AC voltage divided by the AC current with RMS value of 10% of DC test current superimposed on the test
current.
3 . Ratings based on 25° C case temperature.
4 . Pulse width (tp) is delined as the time from rated peak pulse current IPP to the point where peak pulse current decayed to 50% of rated IPP.
