Type RJS
RJSD0303
Telecom - Power Cross Protection & Ballast Protection
m
Catalog
Number
Ampere
Rating
Voltage
Rating
Typical
Cold
Resistance
(ohm)
Volt-drop
@100%
In
(Vol)
max.
Melting
I
2
T< 10
mSec
(A
2
Sec)
Melting
I
2
T @10
In
(A
2
Sec)
Peak Surge Current
(Amp)
50 Pulses 1,000V
10 uS x 1000 u S
Maximum
Power
Dissipation
(W)
RJS 100
RJS 125
RJS 160
RJS
Fuses are primarily intended for use in telecommunication circuit
applications requiring low current protection with high surge tolerance.
They are typically used to replace heat coil type devices. They are designed
to be placed between the line input and the surge arresting components
(mov. gas tube, zenor diode, air gaps, etc.)
These fuses will withstand transient surge currents generated by
lightning in accordance with the attached table.
RJS
fuses guard protected circuitry against sustained overload or
short circuit conditions. Such sustained overloads may be generated by
accidental contact between utility cables and phone lines (power line
cross).
RJS
Fuse are used in circuits to obtain compliance with the test
requirements specified in UL 1950/60950 and Bellcor
e GR 1089.
100mA
125mA
160mA
200mA
250mA
300mA
350mA
400mA
500mA
600mA
700mA
750mA
1A
1.25 A
1.5 A
2A
2.5 A
3A
4A
5A
600V
600V
600V
600V
600V
600V
600V
600V
600V
600V
600V
600V
600V
600V
600V
600V
600V
600V
600V
600V
17
11
7
4.8
3.2
2.1
1.7
1.4
0.9
0.6
0.49
0.44
0.26
0.17
0.13
0.08
0.05
0.033
0.022
0.015
2.5
2.1
1.8
1.5
1.3
1.1
1.0
0.9
0.78
0.66
0.61
0.58
0.47
0.40
0.35
0.29
0.24
0.20
0.17
0.15
0.09
0.13
0.21
0.33
0.51
0.80
1.0
1.2
1.9
3.0
3.8
4.3
7.4
12
17
28
44
69
108
169
0.11
0.17
0.26
0.41
0.64
1.00
1.3
1.6
2.4
3.8
4.8
5.5
9.3
15
21
36
56
87
136
212
6
8
10
13
16
20
24
29
36
46
54
58
80
100
120
155
190
230
300
370
0.41
0.43
0.46
0.49
0.53
0.56
0.58
0.60
0.64
0.68
0.70
0.71
0.77
0.82
0.86
0.93
0.99
1.06
1.13
1.20
RJS 200
RJS 250
RJS 300
RJS 350
RJS 400
RJS 500
RJS 600
RJS 700
RJS 750
RJS 1
RJS 1.25
RJS 1.5
RJS 2
RJS 2.5
RJS 3
RJS 4
Electrical Characteristics
Testing Current
100%
135%
200%
500%
1000%
(UL/CSA STD. 248-14)
Blow Time
Minimum
Maximum
4 Hrs.
N/A
N/A
1 Hr
3 sec
20 sec
100 msec
1.5 sec
30 msec
300 msec
Approvals
Safety Agency
Approvals
Interrupting Rating
10,000A, AC@ 125V
200A, AC@ 250V
100A, AC@ 350V
60A, AC@ 600V
Power
Factor
0.7 - 0.8
0.7 - 0.8
Resistive
Resistive
rSc
Intended
Application
General Purpose
Primary Protection
Ballast Protection
Telecom Protection
RJS 5
Consult manufacturer for other ratings
Power Cross (Telecom) Rating
(Fuse Rated 0.1 - 1.5A)
Overload Current Voltage Clearing Time Limit
135% Fuse rating
200% Fuse Rating
2.2A
7A
40A
60A
600V
600V
600V
600V
600V
600V
Less
Less
Less
Less
Less
Less
than
than
than
than
than
than
1 hour
20 seconds
10 minutes
1 seconds
50 msec
20 msec
Double - exponential
Impulse Waveform
Current
r
S
Recognized File no.
E20624
Acceptance File no.
LR39772
Waveform Duration Of A/B Seconds
A=Rise Time=T1-T0
(1.25(b-a)
B=Duration=T2-T0
(Peak
Value) Ip
0.9 Ip
0.5 Ip
Operating Temperature
-55°C to +125°C
0.1 Ip
a
TO
b
T1
T2
Time
Environmental Specification
Soldering Techniques & Compatibility
Wave Solder: 260°C, 10 sec max. (MIL-STD-202, Method 210)
Shock
MIL-STD-202, Method 213, Test Condition I
(100 G’s peak for 6 milliseconds)
Vibration
MIL-STD-202, Method 201 (10-55 Hz, 0.06 inch, total
excursion)
Salt Spray
MIL-STD-202, Method 101, Test condition B (48 hrs)
Insulation Resistance
MIL-STD-202, Method 302, Test Condition A
(After Opening) 10,000 ohms minimum
Solderability
MIL-STD-202, Method 208
Resistance to solder Heat
MIL-STD-202, Method 210, Test Condition C (260°C, 20 sec)
Thermal Shock
MIL-STD-202, Method 107, Test Condition B (-65°C to+125°C)
Operating Temperature
-55°C to +125°C
Mechanical Dimensions
Standard Lead
A
B
C
D
0.76"+
/
-0.01"
(19.3+
/
-0.2mm)
0.80"+
/
-0.05
(20.3+
/
-1.27mm)
0.4" Typical
(10.0mm)
0.18" max
(4.6mm)
Short Lead
0.76"+
/
-0.01"
(19.3+
/
-0.2mm)
0.80"+
/
-0.05
(20.3+
/
-1.27mm)
0.11"+
/
-0.01"
(2.8+
/
-0.25mm)
0.18" max
(4.6mm)
Specifications subject to change without notice
C
A
D
RECOMMENDED
PCB HOLE SIZE AND SPACING
1.0mm DIA.
0.80” ( 20.3mm)
B
Physical Specification
Materials
Body: Glass;
Lead Wire: Tin-lead plated Copper, Diameter 0.032"
Marking
On fuse: “bel”, “Type”“Current Rating” “Voltage Rating” “Appropriate
Safety Logos”
On label: Above info; Interrupting Rating plus “c”
Packaging
In bulk : 2,000 pcs per box. (standard Lead) 500 pcs per box. (short Lead)
ORDERING INFORMATION SEE PAGES 67 & 68
Bel Fuse Inc.
206 Van Vorst Street, Jersey City, NJ 07302 • Tel: 201-432-0463 • Fax: 201-432-9542 • E-Mail: belfuse@belfuse.com
Website: www.belfuse.com
35
Type RJS
Telecom - Power Cross Protection & Ballast Protection
RJSC0303
RJS - TIME CURRENT CHARACTERISTIC CURVE
-
100mA
-
125mA
-
160mA
-
200mA
-
250mA
-
300mA
-
350mA
-
400mA
-
500mA
-
600mA
-
750mA
-
1A
-
1.25A
-
1.5A
-
2A
-
2.5A
-
3A
-
4A
-
5A
10000
1000
100
TIME IN SECONDS
10
1
0.1
0.01
0.01
0.1
1
10
100
1000
CURRENT IN AMPERES
NOTE - see important information under “User Guide”on P.08
Corporate Office
Bel Fuse Inc.
206 Van Vorst Street, Jersey City, NJ 07302
Tel: 201-432-0463
Fax: 201-432-9542
E-Mail: belfuse@belfuse.com
Website: www.belfuse.com
Far East Office
Bel Fuse Ltd.
8F/8 Luk Hop Street
San Po Kong
Kowloon, Hong Kong
Tel: 852-2328-5515
Fax: 852-2352-3706
European Office
Bel Fuse Europe Ltd.
Preston Technology Management Centre
Marsh Lane, Preston PR1 8UD
Lancashire, U.K
Tel: 44-1772-556601
Fax: 44-1772-888366
Specifications subject to change without notice
36
