MOTION SENSOR
(AREA REFLECTIVE TYPE)
MA MOTION
SENSOR Series
7. The open collector output system
makes for easy load drive.
These sensors provide a continuous
output during detection because the
output system makes it easy to drive the
load.
They achieve an output performance of
30V, Built-in oscillation circuit type:
100 mA, External triggering type: 10 mA
(Thin short type: 100 mA). Also, the thin
short type is available in a PNP open
collector type in addition to a NPN open
collector type.
New
FEATURES
Thin short type
(Mounting direction: V type)
1. Now even more miniature.
The new thin type cuts 35% from the
thickness of the previous short type.
Device installing is now easier than ever.
Existing short type
W10 x H20 x D19.5 mm
W.394 x H.787 x D.768 inch
Thin short type
W10 x H20 x D12.7 mm
W.394
x
H.787
x
D.500 inch
Short type
(Mounting direction: H type)
*“W” and “H” are detection value measurements.
Middle type
(Mounting direction: H type)
Long type
(Mounting direction: H type)
Long type
(Mounting direction: V type)
What is area reflective type?
The sensor emits a ray of light toward the
human body and detects the distance and
determine whether there is a person within
a given distance of the sensor. If the
sensor detects a person, it sets an output
non-contact switch to ON.
Reflected beam
Output
Non-contact
switch
Light beam
Compliance with RoHS Directive
2. Certain detection unaffected by the
reflectance of the object
The sensor can provide stable
detection that is not affected by the
condition (color or material of the clothing)
or parts (skin, hair, etc.) of the object
being monitored. (Reflectance 18% to
90%). Excellent performance even when
the detection surface is dirty.
3. Only connecting DC power supply
for operating
Built-in oscillation circuit type obviates the
hitherto existing need for start signal
input.
4. Use in adjacent positions is possible
These sensors can be located in adjacent
positions, because the timing of the
external trigger signals can be adjusted
so that the beam frequency of each
adjacent sensor will not interfere with the
other.
5. Battery drive possible
By applying longer interval for the trigger
signal, you can reduce the total power
consumption.
6. Can be used with a number of
different supply voltages.
1) The 5V DC type (4.5 to 6.5V DC)
2) The free-ranging power type (6.5 to
27V DC)
They support the DC power supplies of
electronic products and equipment in
general.
*The thin short type is only available for 5V DC.
APPLICATIONS
1. Water-based product market
• Automatic lighting of wash basin units
• Toilets
• Automatic water flow from faucets
2. Stores and financial instructions
• Automatic doors
• Automatic lighting
• Cash dispensing machines
• Automatic teller machines
• Visitor detecting sensors
3. Amusement market
• Automatic lighting for game display
4. Medical field
• Non-contact switch
5. Others
• Automatic ticket gates
• Seat-taking sensors
• Detection of passengers getting on and
off a bus
09/2009
ORDERING INFORMATION
AM
MA Motion Sensor
A: Thin short type MA Motion sensor
B: MA Motion sensor
Detection distance type (shape)
1: Short type
2: Middle type
3: Long type
Triggering function
1: External triggering type
4: Built-in oscillation circuit type (Internal trigger)
Classification by output method & mounting direction
0: NPN open collector/H type
5: NPN open collector/V type
6: PNP open collector/V type
Operating voltage
2: Free-ranging power type (6.5 to 27V DC)
9: The DC 5V type (4.5 to 6.5V DC)
Rated detection distance
Part No.
Detection
distance
Thin short type
Short type
Middle type
Long type
02
—
03
—
04
—
05
06
07
(Middle type
does not
need 08)
cm
inch
08
09
(Short type
does not
need 10)
10
11
12
13
14
15
16
17
18
19
(Long type
does not
need 20)
20
5
10
15
—
—
—
—
—
—
—
—
—
—
—
—
—
1.969
3.937
5.906
5
6
7
8
9
10
—
—
—
—
—
—
—
—
—
—
—
—
—
1.969 2.362 2.756 3.150 3.543 3.937
20
30
40
50
60
70
80
—
—
—
—
—
—
—
—
—
—
—
—
7.874 11.811 15.748 19.685 23.622 27.559 31.496
30
40
50
60
70
80
90
100
110
120
130
140
150
160
170
180
190
200
—
11.811 15.748 19.685 23.622 27.559 31.496 35.433 39.37 43.307 47.244 51.181 55.118 59.055 62.992 66.929 70.866 74.803 78.74
DETECTION DISTANCE TYPE
(distance limited)
1. Thin short type (V type)
Mounting
direction
Type
(shape)
Operating
voltage
Output method
NPN open
collector output
4.5 to 6.5 V DC
Rated detection
distance
5 cm
1.969 inch
10 cm
3.937 inch
15 cm
5.906 inch
Part No.
Built-in oscillation circuit type
External triggering type
AMA145905
AMA1459
AMA145915
AMA115905
AMA1159
AMA115915
Packing quantity
Inner
Outer
20 pcs.
200 pcs.
5 cm
1.969 inch
AMA146905
AMA116905
PNP open
10 cm
3.937 inch
AMA1469
AMA1169
collector output
15 cm
5.906 inch
AMA146915
AMA116915
Note: If you plan to use multiple sensors side-by-side, or you wish to keep the current consumption small, inquire for details about external trigger type, which is suitable for
such applications.
V type
Thin short
type
2. Short type (H type)
Mounting
direction
Type (shape)
Rated operating
voltage
Rated detection
distance
5 cm
6 cm
7 cm
8 cm
9 cm
10 cm
5 cm
6 cm
7 cm
8 cm
1.969 inch
2.362 inch
2.756 inch
3.150 inch
3.543 inch
3.937 inch
1.969 inch
2.362 inch
2.756 inch
3.150 inch
Part No.
Built-in oscillation circuit type
External triggering type
AMB140905
AMB110905
AMB140906
AMB110906
AMB140907
AMB110907
AMB140908
AMB110908
AMB140909
AMB110909
AMB1409
AMB1109
AMB140205
AMB110205
AMB140206
AMB110206
AMB140207
AMB110207
AMB140208
AMB110208
Packing quantity
Inner
Outer
4.5 to 6.5 V DC
H type
Short type
20 pcs.
200 pcs.
6.5 to 27 V DC
9 cm
3.543 inch
AMB140209
AMB110209
10 cm
3.937 inch
AMB1402
AMB1102
Note: If you plan to use multiple sensors side-by-side, or you wish to keep the current consumption small, inquire for details about external trigger type, which is suitable for
such applications.
09/2009
2) Short type
Short type*
1
Items
Minimum
Rated detection distance
Typical
Maximum
Measuring tolerance
Typical
5 cm
1.969 inch
45 mm
1.772 inch
50 mm
1.969 inch
55 mm
2.165 inch
10%
6 cm
2.362 inch
54 mm
2.126 inch
60 mm
3.362 inch
66 mm
2.598 inch
7 cm
2.756 inch
63 mm
2.480 inch
70 mm
2.756 inch
77 mm
3.031 inch
15%
8 cm
3.150 inch
72 mm
2.835 inch
80 mm
3.150 inch
88 mm
3.465 inch
20%
9 cm
3.543 inch
81 mm
3.189 inch
90 mm
3.543 inch
99 mm
3.898 inch
10 cm
3.937 inch
90 mm
3.543 inch
100 mm
3.937 inch
110 mm
4.331 inch
25%
Measured
conditions
with a standard
reflection board
Reflection rate:
90 to 18%
See the drawing
(Fig. 1) on the
next page.
Brightness
Usable
of sensor
Maximum
30,000 lx
ambient
surface
brightness
(Resistance Brightness
to ambient
of reflection Maximum
30,000 lx
light)*
2
surface
Notes: *1. After receipt of order, average rated detection distance to 15 cm
5.906 inch
is possible. Please inquire.
*2. Install so that light from direct light sources does not enter the sensor (within 30x of the sensor light beam).
3) Middle type (Measuring conditions: ambient temp.: 25xC
77xF;
operating voltage: 5 V DC type 5V, Free-ranging power type 24V DC)
Items
Minimum
Rated detection distance
Typical
Maximum
Measuring tolerance
Typical
20 cm
7.874 inch
190 mm
7.480 inch
200 mm
7.874 inch
210 mm
8.268 inch
30 cm
11.811 inch
285 mm
11.220 inch
300 mm
11.811 inch
315 mm
12.402 inch
3%
40 cm
15.748 inch
380 mm
14.961 inch
400 mm
15.748 inch
420 mm
16.535 inch
Middle type*
1
50 cm
19.685 inch
475 mm
18.701 inch
500 mm
19.685 inch
525 mm
20.669 inch
5%
60 cm
23.622 inch
570 mm
22.441 inch
600 mm
23.622 inch
630 mm
24.803 inch
70 cm
27.559 inch
665 mm
26.181 inch
700 mm
27.559 inch
735 mm
28.937 inch
80 cm
31.496 inch
760 mm
29.921 inch
800 mm
31.496 inch
840 mm
33.071 inch
Measured
conditions
with a standard
reflection board
10%
Reflection rate:
90 to 18%
See the drawing
(Fig. 1) on the
next page.
Brightness
Usable
of sensor
Maximum
30,000 lx
ambient
surface
brightness
(Resistance Brightness
to ambient
of reflection Maximum
30,000 lx
light)*
2
surface
Notes: *1. After receipt of order, average rated detection distance to 110 cm
43.307 inch
is possible. Please inquire.
*2. Install so that light from direct light sources does not enter the sensor (within 30x of the sensor light beam).
4) Long type (Measuring conditions: ambient temp.: 25xC
77xF;
operating voltage: 5 V DC type 5V, Free-ranging power type 24V DC)
Items
30 cm
11.811 inch
285 mm
Minimum
11.220 inch
300 mm
Typical
11.811 inch
315 mm
Maximum
12.402 inch
Typical
Long type
40 cm
50 cm
60 cm
70 cm
80 cm
90 cm
15.748 inch 19.685 inch 23.622 inch 27.559 inch 31.496 inch 35.433 inch
100 cm
39.37 inch
110 cm
43.307 inch
Measured
conditions
Rated detection distance
Measuring tolerance
Usable
ambient
brightness
(Resistance
to ambient
light)*
380 mm
475 mm
570 mm
665 mm
760 mm
855 mm
950 mm
1045 mm
14.961 inch 18.701 inch 22.441 inch 26.181 inch 29.921 inch 33.661 inch 37.402 inch 41.142 inch
400 mm
500 mm
600 mm
700 mm
800 mm
900 mm
1000 mm
1100 mm with a standard
15.748 inch 19.685 inch 23.622 inch 27.559 inch 31.496 inch 34.433 inch 39.37 inch 43.307 inch
reflection board
420 mm
525 mm
630 mm
735 mm
840 mm
945 mm
1050 mm
1155 mm
16.535 inch 20.669 inch 24.803 inch 28.937 inch 33.071 inch 37.205 inch 41.339 inch 45.472 inch
Reflection rate:
3%
5%
90 to 18%
30,000 lx
See the drawing
(Fig. 1) on the
next page.
Brightness
of sensor
Maximum
surface
Brightness
of reflection Maximum
surface
Items
120 cm
47.244 inch
1140 mm
Minimum
44.882 inch
1200 mm
Typical
47.244 inch
Maximum 1260 mm
49.606 inch
Typical
5%
30,000 lx
Long type
130 cm
140 cm
150 cm
160 cm
170 cm
180 cm
190 cm
51.181 inch 55.118 inch 49.055 inch 62.992 inch 66.929 inch 70.866 inch 74.803 inch
200 cm
78.74 inch
Measured
conditions
Rated detection distance
Measuring tolerance
1235 mm
1330 mm
1425 mm
1520 mm
1615 mm
1710 mm
1805 mm
1900 mm
48.622 inch 52.362 inch 56.102 inch 59.842 inch 63.583 inch 67.323 inch 71.063 inch 74.803 inch
1300 mm
1400 mm
1500 mm
1600 mm
1700 mm
1800 mm
1900 mm
2000 mm with a standard
51.181 inch 55.118 inch 59.055 inch 62.992 inch 66.929 inch 70.866 inch 74.803 inch 78.74 inch
reflection board
1365 mm
1470 mm
1575 mm
1680 mm
1785 mm
1890 mm
1995 mm
2100 mm
53.740 inch 57.874 inch 62.008 inch 66.142 inch 70.275 inch 74.409 inch 78.543 inch 82.677 inch
Reflection rate:
10%
15%
90 to 18%
See the drawing
(Fig. 1) on the
next page.
Brightness
Usable
of sensor
Maximum
30,000 lx
ambient
surface
brightness
(Resistance Brightness
to ambient
of reflection Maximum
30,000 lx
light)*
surface
Note: * Install so that light from direct light sources does not enter the sensor (within 30x of the sensor light beam).
09/2009
京公网安备 11010802033920号
EEWORLD
