P
OLYFUSE
®
R
ESETTABLE
F
USES
No. HVR600
High Voltage
PTC Device, 60 V / 600 V
Standard
UL 1434 1
st
Edition
CSA C22.2 No. 0 CSA TIL No. CA-3A
cULus Recognition
TÜV
Specifications
Packaging
A:
F:
bulk
tape and ammo
Materials
Approvals
Dimensions (mm)
This product line is designed to provide protec-
tion against induced AC power current, direct
power contact and the natural lightning strike.
The HVR600 product line is widely used in the
fi
eld of telecommunications and network-
ing, ISDN and XSDN eguipment. It also helps
equipment manufacturers pass ITU K20, K21 and
telcordia requirements.
Features
Insulating Material: Yellow Epoxy Polymer,
UL 94V0
Round Pins:
Copper alloy, tin plated
Max. Device Surface Temperature in Tripped State
125 °C
Operating / Storage Temperature
-40 ºC to +85 ºC (consider de-rating)
Humidity Ageing
+85 °C, 85 % R.H., 1000 hours, ± 5 % typical
resistance change
Soldering Characteristics
Solderability per MIL-STD-202, Method 208E
Thermal Shock
MIL-STD-202F, Method 107G
+125 °C to -40 °C 10 times, ±5 % typical resistance
change
Solvent Resistance
MIL-STD-202, Method 215F, no change
Marking
“P”, voltage, amperage rating, lot number
Devices are not intended for
continuous use at 250 V / 600 V!
Dimensions (mm)
Model
HVR600P150C
HVR600P150C-RA
HVR600P150C-RB
HVR600P150CF
HVR600P160C
HVR600P160C-RA
HVR600P160C-R1
HVR600P160CF
A
Max
13,5
13,5
13,5
13,5
16,0
16,0
16,0
16,0
B
Max
12,6
12,6
12,6
12,6
12,6
12,6
12,6
12,6
C
typ
5,1
5,1
5,1
5,1
5,1
5,1
5,1
5,1
D
Min
4,7
4,7
4,7
4,7
4,7
4,7
4,7
4,7
E
Max
6,0
6,0
6,0
6,0
6,0
6,0
6,0
6,0
Physical Characteristics
Lead
Material
0.65 dia
0.65 dia
0.65 dia
0.65 dia
0.65 dia
0.65 dia
0.65 dia
0.65 dia
Sn/Cu
Sn/Cu
Sn/Cu
Sn/Cu
Sn/Cu
Sn/Cu
Sn/Cu
Sn/Cu
packaging quantity
bag
ammo
200
200
200
200
200
200
200
200
600
600
600
600
500
500
500
500
Permissible continuous operating current is
≤
100 % at ambient temperature of 20 ºC (68 ºF).
Model
I
hold
cURus
•
•
•
•
•
•
•
•
HVR600P150C
HVR600P150C-RA
HVR600P150C-RB
HVR600P150CF
HVR600P160C
HVR600P160C-RA
HVR600P160C-R1
HVR600P160CF
0.15
0.15
0.15
0.15
0.16
0.16
0.16
0.16
0.30
0.30
0.30
0.30
0.32
0.32
0.32
0.32
600/60
600/60
600/60
600/60
600/60
600/60
600/60
600/60
3
3
3
3
3
3
3
3
5.00 @ 1.00
5.00 @ 1.00
4.50 @ 1.00
5.00 @ 1.00
7.00 @ 1.00
9.50 @ 1.00
9.00 @ 1.00
7.00 @ 1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
6.0
7.0
9.0
6.0
4.0
4.0
4.0
4.0
12.0
10.0
12.0
12.0
10.0
7.0
8.0
10.0
22.0
20.0
22.0
22.0
18.0
16.0
17.0
18.0
* V
int
:Interrupt Voltage
V
op
: Operating Voltage(V dc)
P
d
=
R
min
=
R
1max
=
Caution:
Power dissipated from device when in the tripped state at 20°C still air.
Minimum resistance of device in initial (un-soldered) state.
Maximum resistance of device at 20°C measured one hour after tripping for 20 sec.
Operation beyond the specified rating may result in damage and possible arcing and
fl
ame.
NOTE:
I
hold
= Hold current: maximum current device will pass without tripping in 20 °C still air.
I
trip
= Trip current: minimum current at which the device will trip in 20 °C still air.
I
max
= Maximum fault current device can withstand without damage at rated voltage (V
max
)
Order
Information
Qty.
Order-
Number
Model
Packaging
Specifications are subject
to change without notice.
040706
In our continuing strategy to deliver unparalleled circuit protection solutions,
technical expertise and application leadership, we proudly introduce the
WICKMANN Group and its products to the Littelfuse portfolio.
www.littelfuse.com
TÜV
•
•
•
•
•
•
•
•
I
Trip
(A)
V
max.
I
max.
V
int/AC
/V
op/DC
* (A)
max. time to trip
(s @ A)
P
d max.
(W)
R
min.
( )
Resistance
R
max.
( ) R
I max.
( )
Approvals
P
OLYFUSE
®
R
ESETTABLE
F
USES
No. HVR600
Average time-current curve
A : HVR600P160F
B : HVR600P150F
Agency Specification
Product
HVR600P150C
HVR600P160C
HVR600P150CF
HVR160CF
Lightning
FCC part 68 - 1.0 kV 10/160
μs
800 V 10/560
μs
Telcordia GR - 1089 - 1.0 kV 10/1000
μs
Power Cross
UL60950, 3rd ed. - 600 V ac, 40 A
Telcordia GR - 1089 - 600 V ac, 60 A
select a specific part number for
each application based on the
agency request
Part-numbering system
HVR
P
F: Tape and ammo packaging
Resistance Bin Range (05:0.5 Ohm, 10: 1.0 Ohm)
Rx: Resistance Range (x:A-Z or 1-9)
T: Pre-tripped device
F: Lead free device
C: Coated device
Current Rating
Polyfuse
Voltage Rating
High Voltage Radial Device
Thermal Derating Chart
Model
HVR600P150C
HVR600P160C
HVR600P150CF
HVR600P160CF
Ambient Operation Temperature - I
hold
(A)
-40 °C
0.23
0.24
0.23
0.24
-20 °C
0.21
0.22
0.21
0.22
0 °C
0.18
0.19
0.18
0.19
23 °C
0.15
0.16
0.15
0.16
40 °C
0.12
0.13
0.12
0.13
60 °C
0.10
0.12
0.10
0.12
85 °C
0.06
0.07
0.06
0.07
040706
In our continuing strategy to deliver unparalleled circuit protection solutions,
technical expertise and application leadership, we proudly introduce the
WICKMANN Group and its products to the Littelfuse portfolio.
www.littelfuse.com
